IQ24050SKC05NRS-G datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> IQ24050SKC05NRS-G

IQ24050SKC05NRS-G: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, SIXTEENTH BRICK PACKAGE-8; CategoryPower/power management The power supply circuit; File Size448KB，1 Pages; ManufacturerSYNQOR; Websitehttp://www.synqor.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

IQ24050SKC05NRS-G Overview

DC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, SIXTEENTH BRICK PACKAGE-8

IQ24050SKC05NRS-G Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	MODULE
package instruction	,
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V
Minimum input voltage	18 V
Nominal input voltage	24 V
JESD-30 code	R-XDMA-P8
JESD-609 code	e3
length	36.47 mm
Maximum load regulation	0.3%
Number of functions	1
Output times	1
Number of terminals	8
Maximum output voltage	5.5 V
Minimum output voltage	4.5 V
Nominal output voltage	5 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	260
Maximum seat height	13.33 mm
surface mount	NO
technology	HYBRID
Terminal surface	MATTE TIN OVER NICKEL
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Maximum total power output	25 W
Fine-tuning/adjustable output	YES
width	26.31 mm
Base Number Matches	1

Preview

Download Datasheet

View All

IQ24xxxSKXxxx

PART NUMBERING SYSTEM

The part numbering system for SynQor’s dc-dc converters follows the format

shown in the example below.

Technical

Specification

ORDERING INFORMATION

The tables below show the valid model numbers and ordering options for

converters in this product family. When ordering SynQor converters, please

ensure that you use the complete 15 character part number consisting of

the 12 character base part number and the additional characters for options.

Add “-G” to the model number for 6/6 RoHS compliance.

Model Number

IQ24012SKw20xyz

IQ24015SKw16xyz

IQ24018SKw14xyz

IQ24025SKw10xyz

IQ24033SKw08xyz

IQ24050SKw05xyz

IQ24070SKw04xyz

IQ24120SKw02xyz

IQ24150SKw02xyz

Input

Voltage

24V

Output

Voltage

1.2V

1.5V

1.8V

2.5V

3.3V

12V

15V

Max Output

Current

20A

16A

14A

10A

3.5A

1.7A

2 4 0 12 S K C 2 0

N R S - G

6/6 RoHS

Options

Output Current

(see

Ordering Information)

Thermal Design

Performance Level

Package Size

Output Voltage

Input Voltage

Product Family

The first 12 characters comprise the base part number and the last 3

characters indicate available options. The “-G” suffix indicates 6/6 RoHS

compliance.

The following options must be included in place of the

w x y z

spaces in the

model numbers listed above.

Options Description

Enable

Thermal Design

Pin Style

Logic

C - Encased

V - Encased with Flanged

Baseplate

N - Negative R - 0.180"

Feature Set

S - Standard

Application Notes

A variety of application notes and technical white papers can be downloaded

in pdf format from our

website.

RoHS Compliance:

The EU led RoHS (Restriction of Hazardous

Substances) Directive bans the use of Lead, Cadmium, Hexavalent

Chromium, Mercury, Polybrominated Biphenyls (PBB), and Polybrominated

Diphenyl Ether (PBDE) in Electrical and Electronic Equipment. This SynQor

product is 6/6 RoHS compliant. For more information please refer to

SynQor’s RoHS addendum available at our

RoHS Compliance / Lead

Free Initiative web page

or e-mail us at

rohs@synqor.com.

Not all combinations make valid part numbers, please contact SynQor for

availability.

See the

Product Summary web page

for more options.

PATENTS

SynQor holds the following U.S. patents, one or more of which apply to

each product listed in this document. Additional patent applications may

be pending or filed in the future.

5,999,417

6,894,468

6,222,742

6,896,526

7,269,034

7,787,261

6,545,890

6,927,987

7,272,021

8,023,290

6,577,109

7,050,309

7,272,023

8,149,597

6,594,159

7,072,190

7,558,083

6,731,520

7,085,146

7,564,702

Contact SynQor for further information:

7,119,524

7,765,687

Phone:

Toll Free:

Fax:

E-mail:

Web:

Address:

978-849-0600

888-567-9596

978-849-0602

power@synqor.com

www.synqor.com

155 Swanson Road

Boxborough, MA 01719

USA

Phone 1-888-567-9596

Warranty

SynQor offers a two (2) year limited warranty. Complete warranty

information is listed on our website or is available upon request from

SynQor.

Information furnished by SynQor is believed to be accurate and reliable.

However, no responsibility is assumed by SynQor for its use, nor for any

infringements of patents or other rights of third parties which may result

from its use. No license is granted by implication or otherwise under any

patent or patent rights of SynQor.

Doc.# 005-0005309 Rev. E

05/03/12

Page 30

Product # IQ24xxxSKXxxx

www.synqor.com

IQ24050SKC05NRS-G Related Products

	IQ24050SKC05NRS-G	IQ24120SKC02NRS-G
Description	DC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, SIXTEENTH BRICK PACKAGE-8	DC-DC Regulated Power Supply Module, 1 Output, 24W, Hybrid, ROHS COMPLIANT, SIXTEENTH BRICK PACKAGE-8
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Parts packaging code	MODULE	MODULE
Contacts	8	8
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V	36 V
Minimum input voltage	18 V	18 V
Nominal input voltage	24 V	24 V
JESD-30 code	R-XDMA-P8	R-XDMA-P8
JESD-609 code	e3	e3
length	36.47 mm	36.47 mm
Maximum load regulation	0.3%	0.3%
Number of functions	1	1
Output times	1	1
Number of terminals	8	8
Maximum output voltage	5.5 V	13.2 V
Minimum output voltage	4.5 V	10.8 V
Nominal output voltage	5 V	12 V
Package body material	UNSPECIFIED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	260	260
Maximum seat height	13.33 mm	13.33 mm
surface mount	NO	NO
technology	HYBRID	HYBRID
Terminal surface	MATTE TIN OVER NICKEL	MATTE TIN OVER NICKEL
Terminal form	PIN/PEG	PIN/PEG
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	10	10
Maximum total power output	25 W	24 W
Fine-tuning/adjustable output	YES	YES
width	26.31 mm	26.31 mm
