MB95F374LPMC1-G-SNE2 datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> MB95F374LPMC1-G-SNE2

Preview

MB95F374LPMC1-G-SNE2: DescriptionMicrocontroller, 8-Bit, FLASH, F2MC-8 CPU, 16.25MHz, CMOS, PQFP64, LQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size3MB，80 Pages; ManufacturerCypress Semiconductor; Environmental Compliance

Download Datasheet Parametric Compare View All

MB95F374LPMC1-G-SNE2 Overview

Microcontroller, 8-Bit, FLASH, F2MC-8 CPU, 16.25MHz, CMOS, PQFP64, LQFP-64

MB95F374LPMC1-G-SNE2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	LFQFP, QFP64,.47SQ,20
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Is Samacsys	N
Has ADC	YES
Address bus width
bit size	8
CPU series	F2MC-8
maximum clock frequency	32.5 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G64
JESD-609 code	e3
length	10 mm
Number of I/O lines	55
Number of terminals	64
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP64,.47SQ,20
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3 V
Certification status	Not Qualified
RAM (bytes)	496
rom(word)	20480
ROM programmability	FLASH
Maximum seat height	1.7 mm
speed	16.25 MHz
Maximum slew rate	44.9 mA
Maximum supply voltage	3.3 V
Minimum supply voltage	2 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

View All

MB95F314E/F314L/F316E/F316L/F318E/F318L

MB95F374E/F374L/F376E/F376L/F378E/F378L

New 8FX MB95310L/370L Series

8-bit Microcontrollers

MB95310L/370L is a series of general-purpose, single-chip microcontrollers. In addition to a compact instruction set, the

microcontrollers of this series contain a variety of peripheral resources.

Features

MC-8FX CPU core

Instruction set optimized for controllers

■

External interrupt

■

Multiplication and division instructions

16-bit arithmetic operations

Bit test branch instructions

Bit manipulation instructions, etc.

Interrupt by edge detection (rising edge, falling edge, and both

edges can be selected)

Can be used to wake up the device from different low power

consumption (standby) modes

8/10-bit A/D converter

8-bit or 10-bit resolution can be selected

Clock



Selectable main clock source

❐

■

LCD controller (LCDC)

■

Main OSC clock (up to 16.25 MHz, maximum machine clock

frequency: 8.125 MHz)

External clock (up to 32.5 MHz, maximum machine clock

frequency: 16.25 MHz)

Main CR clock (1/8/10/12.5 MHz

2%,

maximum machine

clock frequency: 12.5 MHz)

Main PLL clock (up to 16.25 MHz, maximum machine clock

frequency: 16.25 MHz)

40 SEG



4 COM

(MB95F314E/F314L/F316E/F316L/F318E/F318L)

32 SEG



4 COM

(MB95F374E/F374L/F376E/F376L/F378E/F378L)

Internal divider resistor

With blinking function

Low power consumption (standby) modes

■

Selectable subclock source

❐

Sub-OSC clock (32.768 kHz)

❐

External clock (32.768 kHz)

❐

Sub-CR clock (Typ: 100 kHz, Min: 50 kHz, Max: 200 kHz)

8/16-bit composite timer

8/16-bit PPG

16-bit reload timer

Event counter

Time-base timer

Watch prescaler

Stop mode

Sleep mode

Watch mode

Time-base timer mode

Timer

■

I/O port

■

MB95F314E/F314L/F316E/F316L/F318E/F318L (maximum

no. of I/O ports: 71)

General-purpose I/O ports (N-ch open drain): 3

General-purpose I/O ports (CMOS I/O): 68

MB95F374E/F374L/F376E/F376L/F378E/F378L (maximum

no. of I/O ports: 55)

General-purpose I/O ports (N-ch open drain): 3

General-purpose I/O ports (CMOS I/O): 52

■

UART-SIO

■

Capable of clock-asynchronous (UART) serial data transfer

and clock-synchronous (SIO) serial data transfer

Full duplex double buffer

On-chip debug

■

1-wire serial control

Serial writing supported (asynchronous mode)

Built-in wake-up function

Hardware/software watchdog timer

■

Built-in hardware watchdog timer

Built-in software watchdog timer

Cypress Semiconductor Corporation

Document Number: 002-07519 Rev. *A

•

198 Champion Court

•

San Jose

CA 95134-1709

•

408-943-2600

Revised April 06, 2016

MB95F374LPMC1-G-SNE2 Related Products

	MB95F374LPMC1-G-SNE2	MB95F378LPMC2-G-SNE2
Description	Microcontroller, 8-Bit, FLASH, F2MC-8 CPU, 16.25MHz, CMOS, PQFP64, LQFP-64	Microcontroller, 8-Bit, FLASH, F2MC-8 CPU, 16.25MHz, CMOS, PQFP64, LQFP-64
Is it Rohs certified?	conform to	conform to
package instruction	LFQFP, QFP64,.47SQ,20	LQFP, QFP64,.55SQ
Reach Compliance Code	compliant	compliant
Has ADC	YES	YES
bit size	8	8
CPU series	F2MC-8	F2MC-8
maximum clock frequency	32.5 MHz	32.5 MHz
DAC channel	NO	NO
DMA channel	NO	NO
JESD-30 code	S-PQFP-G64	S-PQFP-G64
JESD-609 code	e3	e3
length	10 mm	12 mm
Number of I/O lines	55	55
Number of terminals	64	64
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C
PWM channel	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	LQFP
Encapsulate equivalent code	QFP64,.47SQ,20	QFP64,.55SQ
Package shape	SQUARE	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
power supply	3 V	3 V
Certification status	Not Qualified	Not Qualified
RAM (bytes)	496	2032
rom(word)	20480	61440
ROM programmability	FLASH	FLASH
Maximum seat height	1.7 mm	1.7 mm
speed	16.25 MHz	16.25 MHz
Maximum slew rate	44.9 mA	44.9 mA
Maximum supply voltage	3.3 V	3.3 V
Minimum supply voltage	2 V	2 V
Nominal supply voltage	3 V	3 V
surface mount	YES	YES
technology	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL
Terminal surface	Tin (Sn)	Tin (Sn)
Terminal form	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.65 mm
Terminal location	QUAD	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
width	10 mm	12 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER
Base Number Matches	1	1
