SMT Power Inductors - LPO4815 Series
LPO4815 power inductors share the
same footprint as our LPO4812 series
(4,6 x 4,8 mm), but their 0,3 mm extra
height allows them to handle up to
35% more current. A rugged ceramic
case completely protects the winding
and provides an ideal surface for pick
and place handling.
The small footprint and high efficiency of the LPO4815
make this series well suited for battery powered equip-
ment like cameras, phones, PDAs and other handheld
devices.
Coilcraft
Designer’s Kit C176
contains samples of all
values shown. To order, contact Coilcraft or purchase
on-line at
http://order.coilcraft.com.
L
2
Part number
1
LPO4815-102MX_
LPO4815-152MX_
LPO4815-222MX_
LPO4815-332MX_
LPO4815-392MX_
LPO4815-472MX_
LPO4815-682MX_
LPO4815-103KX_
LPO4815-123KX_
LPO4815-153KX_
LPO4815-223KX_
LPO4815-333KX_
LPO4815-393KX_
LPO4815-473KX_
LPO4815-683KX_
LPO4815-104KX_
LPO4815-154KX_
LPO4815-224KX_
(µH)
1.0 ±20%
1.5 ±20%
2.2 ±20%
3.3 ±20%
3.9 ±20%
4.7 ±20%
6.8 ±20%
10.0 ±10%
12.0 ±10%
15.0 ±10%
22.0 ±10%
33.0 ±10%
39.0 ±10%
47.0 ±10%
68.0 ±10%
100.0 ±10%
150.0 ±10%
220.0 ±10%
DCR
3
SRF
4
max
typ
Isat
5
Irms
6
(Ohms) (MHz) (A)
(A)
0.036
0.085
0.088
0.12
0.13
0.15
0.18
0.23
0.31
0.36
0.46
0.71
0.83
1.20
1.40
2.15
3.15
4.30
230
200
150
115
105
95
72
60
50
45
35
30
25
25
20
15
12
10
1.6
1.5
1.1
0.90
0.86
0.77
0.65
0.50
0.45
0.42
0.37
0.28
0.26
0.22
0.20
0.15
0.13
0.11
1.9
1.7
1.5
1.3
1.2
1.1
1.0
0.85
0.80
0.75
0.70
0.65
0.60
0.55
0.45
0.36
0.30
0.27
1. When ordering, please specify
packaging
code:
LPO4815-224KXC
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape (3500 parts per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 4191A or equivalent.
5. DC current at which the inductance drops 10% (typ) from its value
without current.
6. Average current for a 40°C temperature rise from 25°C ambient.
7. Operating and storage temperature range
−40°C
to +85°C.
8. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Specifications subject to change without notice.
Please check our website for latest information.
Document 354-1
Revised 04/12/04
Document 354-2
SMT Power Inductors - LPO4815 Series
Typical L vs Frequency
1000
220 µH
100
Typical L vs Current
1000
220 µH
100
Inductance (µH)
10 µH
10
Inductance (µH)
47 µH
47 µH
10 µH
10
1 µH
1
1 µH
1
0.1
0.01
0.1
1
10
0.1
0.01
0.1
1
10
Frequency (MHz)
Current (A)
0.059 max
1,5
0.181 max
4,6
0.031 ±0.005
0,787 ±0,127
Dash number
0.190 max
4,83
XXX
X
Internal code
0.107 typ
2,72
0.181 min
4,6
0.035 typ
0,89
Recommended
Land Pattern
0.193
min
4,9
Terminations:
Platinum/palladium/silver
Tape and reel:
1000/7″ reel; 3500/13″ reel 12 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Please check our website for latest information.
Document 354-2
Revised 12/14/04
