CRG04
TOSHIBA Rectifier Silicon Diffused Type
CRG04
General-Purpose Rectifier Applications
•
•
•
•
Repetitive peak reverse voltage: V
RRM
= 600 V
Average forward current: I
F (AV)
= 1.0 A
Average forward voltage: V
FM
= 1.1V(Max)
2.6
±
0.1
3.5
±
0.2
②
Unit: mm
0.65
±
0.2
0.16
①
0.98
±
0.1
0 ~ 0.1
①
ANODE
②
CATHODE
Suitable for high-density board assembly due to the use of a small
surface-mount package, S−FLAT
TM
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Repetitive Peak Reverse Voltage
Average Forward Current
Peak One Cycle Surge Forward
Current (Non−Repetitive)
Junction Temperature
Storage Temperature Range
Symbol
V
RRM
I
F (AV)
I
FSM
T
j
T
stg
Rating
600
1.0(Note1)
15.0 (50Hz)
−40
to 150
−40
to 150
Unit
V
A
A
°C
°C
0.9
±
0.1
+ 0.2
1.6
−
0.1
Note 1: Ta=66°C
Device mounted on a ceramic board
board size: 50 mm
×
50 mm
soldering land: 2 mm
×2
mm
board thickness: 0.64 mm
Half-sine waveform:
α
=180°
JEDEC
JEITA
TOSHIBA
―
―
3-2A1A
Weight: 0.013 g (typ.)
Note 2: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly
even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute
maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Symbol
V
FM(1)
Peak forward voltage
V
FM(2)
V
FM(3)
Repetitive peak reverse current
I
RRM
Test Condition
I
FM
= 0.1 A (Pulse test)
I
FM
= 0.7 A (Pulse test)
I
FM
= 1.0 A (Pulse test)
V
RRM
= 600 V (Pulse test)
Device mounted on a ceramic board
Board size: 50 mm
×
50 mm
Soldering land: 2 mm
×
2 mm
Board thickness: 0.64 mm
Device mounted on a glass-epoxy board
Board size: 50 mm
×
50 mm
Soldering land: 6 mm
×
6 mm
Board thickness: 1.6 mm
―
Min
⎯
⎯
⎯
⎯
Typ.
0.84
0.95
0.98
⎯
Max
⎯
⎯
1.1
10
Unit
V
V
V
μA
⎯
⎯
65
°C/W
Thermal resistance
R
th (j-a)
⎯
⎯
130
R
th (j-ℓ)
⎯
⎯
20
°C/W
1
2008-02-01
0.65
±
0.2
CRG04
Marking
Abbreviation Code
G4
Part No.
CRG04
Standard Soldering Pad
Unit: mm
1.2
1.2
2.8
Handling Precaution
The absolute maximum ratings are rated values and must not be exceeded during operation, even for an instant. The
following are the general derating methods that we recommend when you design a circuit with a device.
V
RRM
: We recommend that the worst case voltage, including surge voltage, be no greater than 80% of the maximum
rating of V
RRM
for a DC circuit and be no greater than 50% of that of V
RRM
for an AC circuit.
V
RRM
has a temperature coefficient of 0.1%/℃. Take this temperature coefficient into account designing a device
at low temperature.
I
F(AV)
: We recommend that the worst case current be no greater than 80% of the maximum rating of I
F(AV)
. Carry out
adequate heat design. If you can’t design a circuit with excellent heat radiation, set the margin by using an
allowable Ta max-I
F (AV)
curve.
This rating specifies the non-repetitive peak current in one cycle of a 50-Hz sine wave, condition angle 180. Therefore,
this is only applied for an abnormal operation, which seldom occurs during the lifespan of the device.
We recommend that a device be used at Tj below 120℃ under the worst load and heat radiation conditions.
Thermal resistance between junction and ambient fluctuates depending on the device’s mounting condition. When using
a device, design a circuit board and a soldering land size to match the appropriate thermal resistance value.
Please refer to the Rectifiers databook for further information.
2
2008-02-01
CRG04
