MC10173
Quad 2-Input Multiplexer/
Latch
The MC10173 is a quad two channel multiplexer with latch. It
incorporates common clock and common data select inputs. The select
input determines which data input is enabled. A high (H) level enables
data inputs D00, D10, D20, and D30 and a low (L) level enables data
inputs D01, D11, D21, D31. Any change on the data input will be
reflected at the outputs while the clock is low. The outputs are latched
on the positive transition of the clock. While the clock is in the high
state, a change in the information present at the data inputs will not
affect the output information.
•
P
D
= 275 mW typ/pkg (No Load)
•
t
pd
= 2.5 ns typ
•
t
r
, t
f
= 2.0 ns typ (20%–80%)
LOGIC DIAGRAM
SELECT 9
1 Q0
PLCC–20
FN SUFFIX
CASE 775
A
WL
YY
WW
http://onsemi.com
MARKING
DIAGRAMS
16
CDIP–16
L SUFFIX
CASE 620
1
16
PDIP–16
P SUFFIX
CASE 648
1
1
10173
AWLYYWW
MC10173P
AWLYYWW
MC10173L
AWLYYWW
D00 6
D01 5
D10 4
D11 3
2 Q1
= Assembly Location
= Wafer Lot
= Year
= Work Week
DIP PIN ASSIGNMENT
D20 13
D21 12
15 Q2
Q0
Q1
D11
D10
D30 11
D31 10
CLOCK 7
14 Q3
D01
V
CC
= PIN 16
V
EE
= PIN 8
D00
CLOCK
V
EE
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
V
CC
Q2
Q3
D20
D21
D30
D31
SELECT
TRUTH TABLE
SELECT
H
L
X
CLOCK
L
L
H
Q0
n+1
D00
D01
Q0
n
Pin assignment is for Dual–in–Line Package.
