MC100EP16VSMNR4 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> MC100EP16VSMNR4

MC100EP16VSMNR4: Description3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size154KB，12 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn

Download Datasheet Parametric Compare View All

MC100EP16VSMNR4 Overview

3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing

MC100EP16VSMNR4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	ON Semiconductor
Parts packaging code	DFN
package instruction	VSON, SOLCC8,.08,20
Contacts	8
Reach Compliance Code	compli
ECCN code	EAR99
Other features	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Differential output	YES
Number of drives	1
Input properties	DIFFERENTIAL
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	GENERAL PURPOSE
JESD-30 code	S-XDSO-N8
JESD-609 code	e0
length	2 mm
Nominal negative supply voltage	-4.5 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	UNSPECIFIED
encapsulated code	VSON
Encapsulate equivalent code	SOLCC8,.08,20
Package shape	SQUARE
Package form	SMALL OUTLINE, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	240
power supply	-4.5 V
Certification status	Not Qualified
Maximum receive delay	0.28 ns
Number of receiver bits	1
Maximum seat height	1 mm
Maximum slew rate	48 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	3 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	ECL
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
maximum transmission delay	0.28 ns
width	2 mm

Preview

Download Datasheet

View All

MC100EP16VS

3.3V / 5V ECL Differential

Receiver/Driver with

Variable Output Swing

Description

The MC100EP16VS is a differential receiver with variable output

amplitude. The device is functionally equivalent to the 100EP16 with

an input pin that controls the amplitude of the outputs.

The V

CTRL

input pin controls the output amplitude of the EP16VS

and is referenced to V

. (See Figure 4.) The operational range of the

CTRL

input is from

≤

(max output amplitude) to V

(min

output amplitude). (See Figure 3.) A variable resistor between the V

and V

pins, with the wiper driving V

CTRL

, can control the output

amplitude. Typical application circuits and a V

CTRL

Voltage vs.

Output Amplitude graph are described in this data sheet. When left

open, the V

CTRL

pin will be internally pulled down to V

and operate

as a standard EP16, with 100% output amplitude.

The V

pin, an internally generated voltage supply, is available to

this device only. For single−ended input conditions, the unused

differential input is connected to V

as a switching reference voltage.

may also rebias AC coupled inputs. When used, decouple V

and V

via a 0.01

capacitor and limit current sourcing or sinking

to 0.5 mA. When not used, V

should be left open.

Features

http://onsemi.com

MARKING

DIAGRAMS*

SOIC−8

D SUFFIX

CASE 751

KEP62

ALYW

TSSOP−8

DT SUFFIX

CASE 948R

KP62

ALYWG

•

220 ps Propagation Delay

Maximum Frequency

4 GHz Typical (See Graph)

The 100 Series Contains Temperature Compensation

PECL Mode Operating Range: V

= 3.0 V to 5.5 V

with V

= 0 V

NECL Mode Operating Range: V

= 0 V

with V

−3.0

V to

−5.5

Open Input Default State

Q Output Will Default LOW with Inputs Open or at V

Pb−Free Packages are Available

DFN8

MN SUFFIX

CASE 506AA

= Assembly Location

= Wafer Lot

= Year

= Work Week

= Date Code

= Pb−Free Package

(Note: Microdot may be in either location)

*For additional marking information, refer to

Application Note AND8002/D.

ORDERING INFORMATION

See detailed ordering and shipping information in the package

dimensions section on page 9 of this data sheet.

Semiconductor Components Industries, LLC, 2008

August, 2008

−

Rev. 6

Publication Order Number:

MC100EP16VS/D

3H MG

MC100EP16VSMNR4 Related Products

	MC100EP16VSMNR4	MC100EP16VS	MC100EP16VSDR2	MC3100EP16VSDTG	MC3100EP16VSDT	MC100EP16VSMNR4G
Description	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing	3.3V / 5V ECL Differential Receiver/Driver with Variable Output Swing
Is it lead-free?	Contains lead	-	-	Lead free	Contains lead	Lead free
Is it Rohs certified?	incompatible	-	incompatible	conform to	incompatible	conform to
Maker	ON Semiconductor	-	ON Semiconductor	ON Semiconductor	ON Semiconductor	-
Parts packaging code	DFN	-	SOIC	SOIC	SOIC	DFN
package instruction	VSON, SOLCC8,.08,20	-	SOP, SOP8,.25	TSSOP, TSSOP8,.19	TSSOP, TSSOP8,.19	LEAD FREE, DFN-8
Contacts	8	-	8	8	8	8
Reach Compliance Code	compli	-	_compli	compli	compli	compli
ECCN code	EAR99	-	EAR99	EAR99	EAR99	EAR99
Other features	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE	-	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE	CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Differential output	YES	-	YES	YES	YES	YES
Number of drives	1	-	1	1	1	1
Input properties	DIFFERENTIAL	-	DIFFERENTIAL	DIFFERENTIAL	DIFFERENTIAL	DIFFERENTIAL
Interface integrated circuit type	LINE TRANSCEIVER	-	LINE TRANSCEIVER	LINE TRANSCEIVER	LINE TRANSCEIVER	LINE TRANSCEIVER
Interface standards	GENERAL PURPOSE	-	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
JESD-30 code	S-XDSO-N8	-	R-PDSO-G8	S-PDSO-G8	S-PDSO-G8	S-XDSO-N8
JESD-609 code	e0	-	e0	e3	e0	e4
length	2 mm	-	4.9 mm	3 mm	3 mm	2 mm
Nominal negative supply voltage	-4.5 V	-	-4.5 V	-4.5 V	-4.5 V	-4.5 V
Number of functions	1	-	1	1	1	1
Number of terminals	8	-	8	8	8	8
Maximum operating temperature	85 °C	-	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-	-40 °C	-40 °C	-40 °C	-40 °C
Package body material	UNSPECIFIED	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	UNSPECIFIED
encapsulated code	VSON	-	SOP	TSSOP	TSSOP	VSON
Encapsulate equivalent code	SOLCC8,.08,20	-	SOP8,.25	TSSOP8,.19	TSSOP8,.19	SOLCC8,.08,20
Package shape	SQUARE	-	RECTANGULAR	SQUARE	SQUARE	SQUARE
Package form	SMALL OUTLINE, VERY THIN PROFILE	-	SMALL OUTLINE	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	240	-	240	260	240	260
power supply	-4.5 V	-	-4.5 V	-4.5 V	-4.5 V	-4.5 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum receive delay	0.28 ns	-	0.28 ns	0.28 ns	0.28 ns	0.28 ns
Number of receiver bits	1	-	1	1	1	1
Maximum seat height	1 mm	-	1.75 mm	1.1 mm	1.1 mm	1 mm
Maximum slew rate	48 mA	-	48 mA	48 mA	48 mA	48 mA
Maximum supply voltage	5.5 V	-	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	3 V	-	3 V	3 V	3 V	3 V
Nominal supply voltage	3.3 V	-	3.3 V	3.3 V	3.3 V	3.3 V
surface mount	YES	-	YES	YES	YES	YES
technology	ECL	-	ECL	ECL	ECL	ECL
Temperature level	INDUSTRIAL	-	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	TIN LEAD	-	Tin/Lead (Sn80Pb20)	MATTE TIN	TIN LEAD	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	NO LEAD	-	GULL WING	GULL WING	GULL WING	NO LEAD
Terminal pitch	0.5 mm	-	1.27 mm	0.65 mm	0.65 mm	0.5 mm
Terminal location	DUAL	-	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	30	-	30	40	30	40
maximum transmission delay	0.28 ns	-	0.28 ns	0.28 ns	0.28 ns	0.28 ns
width	2 mm	-	3.9 mm	3 mm	3 mm	2 mm
