SPECIFICATIONS
Current rating:
Voltage rating:
Contact material:
Contact plating:
Contact resistance:
Housing material:
Insulation resistance:
Temperature range:
5 amps
250VAC max.
Brass
Tin 100µ” over nickel 50µ”
6 milliohms max.
Nylon, UL94V-2
5,000 megohms at 1,500VAC min.
0°C to +75°C
A
B
C
D
E
Recommended Hole Dimensions
F
RoHS compliant
Rev.
Description
Date
Approved
G
Dimensions
Pos. A
B
2
3.96 7.82
3
7.92 11.78
Top Entry
Side Entry
Bottom Entry
4 11.88 15.74
5 15.84 19.70
6 19.80 23.66
7 23.76 27.62
8 27.72 31.58
9 31.68 35.54
10 35.64 39.50
11 39.60 43.46
12 43.56 47.42
13 47.52 51.38
14 51.48 55.34
15 55.44 59.30
16 59.40 63.26
Series
Pitch
Type
Mounting
Positions
Color
Plating
DBHR
X
X
X
XX
XX
XX
DBHR receptacle 1=.100” T=Top
Blank=None
2-22
BK=Black TN=Tin
with board hooks 2=.156” S=Side
H=Hook
WT=White GD=Gold
B=Bottom HR=Hook & Ramp
R=Locking Ramp (not with L)
Drawing
Name
Date
Central Components Manufacturing
Approved Howard
08/10/99
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
Checked Lizzy
08/10/99
DBHR-2-T-HR-15-WT-TN
Drawn Tina
08/10/99 Part No.:
0.0 ± 0.35
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
C
D
E
F
Description: PC board connector, 3.96mm pitch
