BZY97C30: DescriptionZener Diode, 30V V(Z), 6.67%, 1.5W, Silicon, Unidirectional, DO-204AM, PLASTIC, DO-41, 2 PIN; CategoryDiscrete semiconductor diode; File Size255KB，6 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

BZY97C30 Overview

Zener Diode, 30V V(Z), 6.67%, 1.5W, Silicon, Unidirectional, DO-204AM, PLASTIC, DO-41, 2 PIN

BZY97C30 Parametric

Parameter Name	Attribute value
Parts packaging code	DO-41
package instruction	O-PALF-W2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-204AM
JESD-30 code	O-PALF-W2
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
polarity	UNIDIRECTIONAL
Maximum power dissipation	1.5 W
Certification status	Not Qualified
Nominal reference voltage	30 V
surface mount	NO
technology	ZENER
Terminal form	WIRE
Terminal location	AXIAL
Maximum voltage tolerance	6.67%
Working test current	25 mA
Base Number Matches	1

Preview

Download Datasheet

View All

VISHAY

BZY97 Series

Vishay Semiconductors

Zener Diodes

Features

• Silicon Planar Power Zener Diodes.

• For use in stablilizing and clipping circuits with

high power rating.

• The Zener voltages are graded according to the

international E 24 standard. Smaller voltage toler-

ances are available upon request.

18653

Mechanical Data

Case:

DO-41 PLASTIC (DO-204AM)

molded plastic body

Weight:

approx. 340 mg

Packaging Codes/Options:

TR/ 5 k per 13 " reel (52 mm tape), 25 k/box

Absolute Maximum Ratings

amb

= 25 °C, unless otherwise specified

Parameter

Zener current (see table "Characteristics"

Power dissipation

Test condition

amb

= 60 °C

Symbol

tot

Value

1.5

Unit

Valid provided that leads at a distance of 3/8 " from case are kept at ambient temperature.

Thermal Characteristics

amb

= 25 °C, unless otherwise specified

Parameter

Thermal resistance junction to ambient air

Junction temperature

Storage temperature

Test condition

Symbol

θJA

Value

150

- 55 to + 150

Unit

°C/W

°C

Valid provided that leads at a distance of 3/8 " from case are kept at ambient temperature.

Document Number 85780

Rev. 1.2, 05-Feb-04

www.vishay.com
