IMC-0402
Vishay Dale
High Frequency, Surface Mount, Laser Spiral,
Coated Inductors
FEATURES
•
•
•
•
•
•
Very small in size
High self-resonant frequency values
High Q values relative to size at higher frequencies
Coated coil provides protection and moisture resistance
Compatible with vapor phase and infrared reflow soldering
Tape and reel packaging for automatic handling,
10,000/reel, EIA-481
• L and Q value not affected by mounting orientation
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0nH to 100nH
Inductance and Tolerance:
±
0.3nH for 1.0 - 5.6nH
±
5% for 6.8nH to 100nH
Operating Temperature:
- 40°C to + 100°C
Core Material:
Ceramic
TEST EQUIPMENT
•
Inductance and Q measured on HP4291B
•
SRF measured on HP8753E
•
DCR measured on HP4338B
STANDARD ELECTRICAL SPECIFICATIONS
TEST
FREQUENCY
INDUCTANCE
L
Q
(nH)
TOLERANCE
(MHz)
MINIMUM
1.0
±
0.3nH, 0.15nH
100
21
1.2
±
0.3nH, 0.15nH
100
21
1.5
±
0.3nH, 0.15nH
100
21
1.8
±
0.3nH, 0.15nH
100
21
2.2
±
0.3nH, 0.15nH
100
21
2.7
±
0.3nH, 0.15nH
100
21
3.3
±
0.3nH, 0.15nH
100
21
3.9
±
0.3nH, 0.15nH
100
20
4.7
±
0.3nH, 0.15nH
100
20
5.6
±
0.3nH, 0.15nH
100
20
6.8
±
5%, 2%
100
19
8.2
±
5%, 2%
100
19
10
±
5%, 2%
100
19
12
±
5%, 2%
100
19
15
±
5%, 2%
100
19
18
±
5%, 2%
100
19
22
±
5%, 2%
100
19
27
±
5%, 2%
100
19
33
±
5%, 2%
100
18
39
±
5%, 2%
100
18
47
±
5%, 2%
100
17
56
±
5%, 2%
100
17
68
±
5%, 2%
100
15
82
±
5%, 2%
100
15
100
±
5%, 2%
100
14
*Value obtained when current flows and temperature has risen 15°C
TEST
FREQUENCY
Q
(MHz)
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
SELF-RESONANT
FREQUENCY
MINIMUM
(MHz)
6000
6000
6000
6000
6000
5500
5500
5200
4800
4600
4000
3500
2800
2800
2500
2200
2000
1800
1800
1800
1800
1500
1500
1400
1200
DCR
MAXIMUM
(Ohms)
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.19
0.30
0.35
0.41
0.45
0.60
0.70
0.80
1.20
1.40
1.70
2.10
2.50
4.00
4.50
5.50
RATED
DC*
CURRENT
(mA)
400
400
400
400
400
400
400
360
360
340
320
320
320
320
240
240
200
200
170
150
140
130
120
110
90
DIMENSIONS
in inches [millimeters]
0.008
[0.2]
0.020
±
0.004
[0.5
±
0.1]
0.039
±
0.004
[1.0
±
0.1]
0.020
±
0.004
[0.5
±
0.1]
Solder Pad Layout
0.02 [0.50]
0.020 [0.50]
0.063 [1.60]
90/10 Sn/Pb Termination
DESCRIPTION
IMC-0402
MODEL
10nH
INDUCTANCE VALUE
±
5%
INDUCTANCE TOLERANCE
SAP PART NUMBERING GUIDELINES (INTERNAL)
I
M
C
0
4
SIZE
0
2
R
K
1
0
N
J
TOL.
PRODUCT FAMILY
See the end of this data book for conversion tables
PACKAGE
CODE
INDUCTANCE
VALUE
www.vishay.com
48
For technical questions, contact Magnetics@vishay.com
Document Number 34038
Revision 10-Sep-02
