Issue Number │001
March 2015
Announcement
New Product
AH8500/1 & AH8502/3
AH8500/1 & AH8502/3 – Micropower Linear Hall Effect Sensor Family
with Enable/Control Pin and High Accuracy Options
The AH850/1/2/3 is a family of low
power/micropower linear hall effect
sensors with output voltage
ratiometric to supply and magnetic
field sense range of +/-400G for
battery powered consumer , home
appliances and industrial
applications.
The high performance AH8501 and
AH8503 have trimmed sensitivity
accuracy of 3% with a null voltage
offset below 1% of supply voltage.
Designed for a wide range of
applications,
they are optimized for
The Diodes’ Advantage
The AH8500/1/2/3/4 provide a high performance and low power/micropower
solutions for a wide range of applications requiring magnetic flux
measurements.
Low Voltage, Low Power Linear Halls – With Miicropower Mode
-
Supply voltage of 1.6V to 3.6V is ideal for interfacing with ADC
-
Typical current consumption of 8.9uA in sleep mode (AH8500/1), 13uA at
micropower mode (AH8502/3) and 1.16mA at 7.14kHz sampling rate.
-
Supports battery powered consumer/home appliances and industrial
applications
the supply range of 1.6V to 3.6V
consuming only 8.9uA in sleep
mode (AH8500/AH8501) and 13uA
in micropower mode
(AH8502/AH8503).
The sensors have a ESD rating of
6kV for robustness.
For system flexibility the enable pin
in the AH8500/1 and CNTRL pin on
the the AH8502/3 allow operating
modes and sampling rate to
minimize current consumption. In
default modes, the AH8500/1 are in
sleep mode while AH8502/3 operate
in micropower mode.
High Sensitivity with High Accuracy (Trimmed) Options
-
High accuracy AH8501/3 have a sensitivity of 2.25mV/G and 3.8mV/G at 1.8V
and 3V respectively with accuracy of 3% at 25
o
C
-
AH8500/2: Sensitivity of 2.1mV/G at 1.8V with accuracy of +/-15% at 25
o
C
High Performance, Reliability and Robustness
-
Chopper stabilize with internal ADC and DAC architecture with low input
referred noise of 0.36G and null voltage offset less than 1% of V
DD
-
Low temperature coefficient for sensitivity - effect of +/-3% over -40
o
C to 85
o
C
-
High linearity – Span linearity of 99.9% +B and 100.1% for -B fields at 1.8V
-
High ESD of 6kV
The family of sensors are available
in the small low profile U-
DFN2020-6.
Operating temperature range -40
o
C to +85
o
C
-
Suitable for a wide range of consumer and industrial applications.
Applications
Position and proximity sensing
Magnetic flux density measurements
Liquid level sensing
Valve position sensing
Multi position button detect
Joysticks
Smart meters
Smart phone accessories detect
Rotary encoder
www.diodes.com
Issue Number │001
March 2015
Announcement
New Product
AH8500/1 & AH8502/3
AH8500/1 & AH8502/3 – Micropower Linear Hall Effect Sensor Family
with Enable/Control Pin and High Accuracy Options
Linear Hall Portfolio
Typical
IC Supply Current
Typical
Sensitivity
Output
Linear
V Null Operating
Voltage
Accuracy
(B = 0G)
Temp.
Magnetic
Span
at 25C
Range
(%)
(G)
±1000
(V)
0.8 to
Vcc-0.8
0.8 to
Vcc-0.8
0.8 to
Vcc-0.8
(V)
Vcc/2
(
o
C)
-40 to 85
TO92S
SOT23
Operating
Part
Number Voltage
(V)
AH49E
3 to 6.5
Typical
Sensitivity
Package
(mA)
3.5
(mV/G)
1.6
AH49F
3 to 8
3
2.1
±19%
±800
Vcc/2
TO92S
-40 to 105
SOT23
U-DFN2020-6
-40 to 105
TO92S
SOT23
AH49H
3 to8
2
8.9uA in Sleep Mode
12uA at 20Hz
1.0mA in Auto-Run Mode
8.9uA in Sleep Mode
12uA at 20Hz
1.0mA Auto-Run Mode
13uA in Micropower Mode
1.0mA in Turbo Mode
13uA Micropower Mode
1.0mA in Turbo Mode
0.33
2.10 @ 1.8V
3.55 @ 3V
3.82 @ 3.3V
2.25 @1.8V
3.80 @ 3V
4.11 @ 3.3V
2.10 @ 1.8V
3.55 @ 3V
3.82 @ 3.3
2.25 @1.8V
3.80 @ 3V
4.11 @ 3.3V
±3000
Vcc/2
AH8500
1.6 to 3.6
±15%
±430
0 to V
DD
V
DD
/2
-40 to 85 U-DFN2020-6
AH8501
1.6 to 3.6
±3%
±430
0 to V
DD
V
DD
/2
-40 to 85 U-DFN2020-6
AH8502
1.6 to 3.6
±15%
±430
0 to V
DD
V
DD
/2
-40 to 85 U-DFN2020-6
AH8503
1.6 to 3.6
±3%
±430
0 to V
DD
V
DD
/2
-40 to 85 U-DFN2020-6
To find out more information:
Linear Hall Portfolio page:
AH8500 Datasheet:
AH8501 Datasheet:
AH8502 Datasheet:
AH8503 Datasheet:
http://www.diodes.com/products/catalog/browse.php?parent-id=198
http://www.diodes.com/datasheets/AH8500.pdf
http://www.diodes.com/datasheets/AH8501.pdf
http://www.diodes.com/datasheets/AH8502.pdf
http://www.diodes.com/datasheets/AH8503.pdf
