3-827753-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 3-827753-0

3-827753-0: Description30 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT; CategoryThe connector The connector; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-827753-0 Overview

30 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT

3-827753-0 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1425243028
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Other features	AMPMODU
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	TIN
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	827753
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	30
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

3-827753-0 Product Details

Live Product Chat

Product Photo

.100 inch AMPMODU Headers

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3-827753-0

T E I nternal N umber: 3 - 8 2 7 7 5 3 - 0

Product Highlights:

Header

Header Type = Standard

Number of Rows = Single

Number of Positions = 30

Mating Post Length = 5.90 mm

View all Features

Pending Obsolescence

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

AMPMODU II STIFTLEISTE 90 EINREIHIG

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Header

Number of Positions

= 30

Mount Angle

= Right Angle

PC B Retention Feature

= No

Surface Mount C ompatible

= No

Board Standoff

= Without

Mounting Ears

= Without

Mating C onnector Lock

= Without

Profile = Standard

C omment = Headers are side-to-side stackable.

Mechanical Attachment:

Mating Post Length (mm [in]) = 5.90 [0.232]

Panel Attachment

= Without

Termination Related Features:

Termination Post Length (mm [in])

= 5.12 [0.202]

Solder Tail C ontact Plating = Tin

Body Related Features:

Header Type = Standard

Number of Rows

= Single

C enterline, Matrix (mm [in])

= 2.54 [.100]

Selectively Loaded

= No

Mount Type

= Printed C ircuit Board

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Thermoplastic Polyester

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

High Temperature Housing

= No

Operation/Application:

High Speed Serial Data C onnector

= No

Other:

Brand = AMP

Additional Information:

Product Line Information
