MAU200 Series
1W, High Isolation SIP, Single & Dual Output DC/DC Converters
Key Features
Efficiency up to 81%
3000VDC Isolation
MTBF > 2,000,000 Hours
Low Cost
Input 5, 12 and 24VDC
Output 3.3,5,9,12,15,{5,{9,{12 and {15VDC
Temperature Performance -40] to +85]
UL 94V-0 Package Material
Internal SMD Construction
Industry Standard Pinout
Minmax's MAU200 1W DC/DC's are specially designed to
provide high levels of isolation 3000VDC in a miniature SIP
package.
The series consists of 27 models with input voltages of
5V, 12V and 24VDC which offers standard output voltages of
3.3V, 5V, 9V, 12V, 15V, ±5V, ±9V, ±12V and ±15VDC for a
wide choice.
The MAU200 series is an excellent selection for a variety
of applications including distributed power systems, mixed
analog/digital subsystems, portable test equipments, local
power networks and battery backed systems.
$
Low Cost
3000
VDC
I/O Isolation
Low Profile
Block Diagram
Single Output
Dual Output
+Vo
+Vin
Bipolar
Push-Pull
Inverter
-Vin
-Vo
-Vin
+Vin
Bipolar
Push-Pull
Inverter
+Vo
Com.
-Vo
1
MINMAX
REV:0 2005/04
MAU200 Series
Model Selection Guide
Model
Number
Input
Voltage
Output
Voltage
Output Current
Input Current
Load
Regulation
Efficiency
VDC
MAU201
MAU202
MAU203
MAU204
MAU205
MAU206
MAU207
MAU208
MAU209
MAU211
MAU212
MAU213
MAU214
MAU215
MAU216
MAU217
MAU218
MAU219
MAU221
MAU222
MAU223
MAU224
MAU225
MAU226
MAU227
MAU228
MAU229
5
(4.5 ~ 5.5)
12
(10.8 ~ 13.2)
24
(21.6 ~ 26.4)
VDC
3.3
5
9
12
15
{5
{9
{12
{15
3.3
5
9
12
15
{5
{9
{12
{15
3.3
5
9
12
15
{5
{9
{12
{15
Max.
mA
260
200
110
84
67
{100
{56
{42
{34
260
200
110
84
67
{100
{56
{42
{34
260
200
110
84
67
{100
{56
{42
{34
Min.
mA
5
4
2
1.5
1
{2
{1
{0.8
{0.7
5
4
2
1.5
1
{2
{1
{0.8
{0.7
5
4
2
1.5
1
{2
{1
{0.8
{0.7
@Max. Load
mA (Typ.)
235
281
260
258
258
278
262
258
258
96
114
106
105
104
113
106
104
105
49
59
54
54
53
58
55
53
53
@No Load
mA (Typ.)
30
12
7
% (Max.)
10
10
8
7
7
10
8
7
7
8
8
5
5
5
8
5
5
5
8
8
5
5
5
8
5
5
5
@Max. Load
% (Typ.)
73
71
76
78
78
72
77
78
79
74
73
78
80
80
74
79
81
81
73
71
76
78
79
72
76
79
80
Absolute Maximum Ratings
Parameter
5VDC Input Models
Input Surge Voltage
12VDC Input Models
( 1000 mS )
24VDC Input Models
Lead Temperature (1.5mm from case for 10 Sec.)
Internal Power Dissipation
Min.
-0.7
-0.7
-0.7
---
---
Max.
9
18
30
260
450
Unit
VDC
VDC
VDC
]
mW
Notes :
1. Specifications typical at Ta=+25], resistive load,
nominal input voltage, rated output current unless
otherwise noted.
2. Ripple & Noise measurement bandwidth is 0-20
MHz.
3. These power converters require a minimum
output loading to maintain specified regulation.
4. Operation under no-load conditions will not
damage these modules; however, they may not
meet all specifications listed.
5. All DC/DC converters should be externally fused at
the front end for protection.
Min.
Max.
-40
+85
-40
+90
-40
+125
---
95
Free-Air Convection
Unit
]
]
]
%
6. Other input and output voltage may be available,
please contact factory.
7. Specifications subject to change without notice.
Exceeding the absolute maximum ratings of the unit could cause damage.
These are not continuous operating ratings.
Environmental Specifications
Parameter
Operating Temperature
Operating Temperature
Storage Temperature
Humidity
Cooling
Conditions
Ambient
Case
REV:0 2005/04
MINMAX
2
MAU200 Series
Input Specifications
Parameter
Input Voltage Range
Model
5V Input Models
12V Input Models
24V Input Models
Reverse Polarity Input Current
Input Filter
All Models
Min.
4.5
10.8
21.6
---
Typ.
5
12
24
---
Max.
5.5
13.2
26.4
0.3
A
VDC
Unit
Internal Capacitor
Output Specifications
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Over Load
Temperature Coefficient
Output Short Circuit
Over Line, Load & Temp.
Dual Output, Balanced Loads
For Vin Change of 1%
Io=20% to 100%
Conditions
Min.
---
---
---
---
---
---
120
---
0.5 Second Max.
Typ.
{1.0
{0.1
{1.2
65
---
---
---
{0.01
Max.
{3.0
{1.0
{1.5
100
150
5
---
{0.02
Unit
%
%
%
%
mV P-P
mV P-P
mV rms
%
%/]
See Model Selection Guide
General Specifications
Parameter
Isolation Voltage Rated
Isolation Voltage Test
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
MIL-HDBK-217F @ 25], Ground Benign
Conditions
60 Seconds
Flash Tested for 1 Second
500VDC
100KHz,1V
Min.
3000
3300
10
---
70
2000
Typ.
---
---
---
60
100
---
Max.
---
---
---
100
120
---
Unit
VDC
VDC
G[
pF
KHz
K Hours
Capacitive Load
Models by Vout
Maximum Capacitive Load
# For each output
3.3V
220
5V
220
9V
220
12V
220
15V
220
{5V
#
100
{9V
#
100
{12V
#
100
{15V
#
100
Unit
uF
Input Fuse Selection Guide
5V Input Models
500mA Slow - Blow Type
12V Input Models
200mA Slow - Blow Type
24V Input Models
100mA Slow - Blow Type
3
MINMAX
REV:0 2005/04
MAU200 Series
100
90
Efficiency (%)
80
70
60
50
Efficiency (%)
Low
Nom
Input Voltage (V)
High
100
90
80
70
60
50
Low
Nom
Input Voltage (V)
High
Efficiency vs Input Voltage ( Single Output )
Efficiency vs Input Voltage ( Dual Output )
90
80
Efficiency (%)
Efficiency (%)
10
20
40
60
80
70
60
50
40
30
20
100
90
80
70
60
50
40
30
20
10
20
40
60
80
100
Load Current (%)
Load Current (%)
Efficiency vs Output Load ( Single Output )
Efficiency vs Output Load ( Dual Output )
100
80
Output Power (%)
100LFM
Natural
convection
200LFM
Output Power (%)
100
80
100LFM
400LFM
200LFM
400LFM
60
60
Natural
convection
40
40
20
0
-40
20
0
50
60
70
80
]
90
100
110
-40
〜
〜
50
60
70
80
]
90
100
110
Ambient Temperature
Ambient Temperature
Derating Curve ( 3.3V, 5V & {5V )
Derating Curve ( all other output )
REV:0 2005/04
MINMAX
4
MAU200 Series
Test Configurations
Input Reflected-Ripple Current Test Setup
Input reflected-ripple current is measured with a inductor
Lin (4.7uH) and Cin (220uF, ESR < 1.0[ at 100 KHz) to
simulate source impedance.
Capacitor Cin, offsets possible battery impedance.
Current ripple is measured at the input terminals of the
module, measurement bandwidth is 0-500 KHz.
To Oscilloscope
+
Battery
+
Lin
Current
Probe
+Vin
+Out
Load
In applications where power is supplied over long lines and
output loading is high, it may be necessary to use a capacitor
at the input to ensure startup.
Capacitor mounted close to the power module helps
ensure stability of the unit, it is recommended to use a good
quality low Equivalent Series Resistance (ESR < 1.0[ at 100
KHz) capacitor of a 2.2uF for the 5V input devices, a 1.0uF for
the 12V input devices and a 0.47uF for the 24V devices.
+
DC Power
Source
-
+
Cin
-Vin
-Out
+Vin
DC / DC
Converter
+Out
Load
DC / DC
Converter
-Vin
-Out
Cin
Output Ripple Reduction
Peak-to-Peak Output Noise Measurement Test
Use a Cout 0.33uF ceramic capacitor.
Scope measurement should be made by using a BNC
socket, measurement bandwidth is 0-20 MHz. Position the
load between 50 mm and 75 mm from the DC/DC Converter.
+Vin
Single Output
DC / DC
Converter
-Vin
-Out
+Out
Copper Strip
Cout
Scope
Resistive
Load
A good quality low ESR capacitor placed as close as
practicable across the load will give the best ripple and noise
performance.
To reduce output ripple, it is recommended to use 1.0uF
capacitors at the output.
+
DC Power
Source
-
+Vin
Single Output
DC / DC
Converter
-Vin
+Out
Cout
-Out
Load
+Vin
Dual Output
DC / DC
Converter
-Vin
+Out
Com.
Copper Strip
Cout
Cout
Scope
Resistive
Load
Scope
+
DC Power
Source
-
+Vin
+Out
Dual Output
DC / DC Com.
Converter
Cout
Load
-Vin
-Out
-Out
Design & Feature Considerations
Maximum Capacitive Load
The MAU200 series has limitation of maximum connected
capacitance at the output.
The power module may be operated in current limiting
mode during start-up, affecting the ramp-up and the startup
time.
For optimum performance we recommend 100
u
F
maximum capacitive load for dual outputs and 220
u
F
capacitive load for single outputs.
The maximum capacitance can be found in the data sheet.
Thermal Considerations
Many conditions affect the thermal performance of the
power module, such as orientation, airflow over the module
and board spacing. To avoid exceeding the maximum
temperature rating of the components inside the power
module, the case temperature must be kept below 90°C.
The derating curves are determined from measurements
obtained in an experimental apparatus.
Input Source Impedance
The power module should be connected to a low
ac-impedance input source. Highly inductive source
impedances can affect the stability of the power module.
Position of air velocity
probe and thermocouple
15mm / 0.6in
50mm / 2in
Air Flow
DUT
5
MINMAX
REV:0 2005/04
