METALLIZED POLYESTER FILM CAPACITORS
MACA
MACA
♦
FEATURES
SERIES
•
This capacitors provide self-healing.
•
For motor starting and phase compensation.
•
Wax impregnated with flame-retardant (UL 94V-0) plastic case.
♦
SPECIFICATIONS
Category temperture
Rated voltage (U
R
)
Capacitance tolerance
tan
δ
Voltage proof
Insulation resistance
Reference standard
♦
DIMENSIONS (mm)
-25°C~+60°C
AC220, 250V, 300V, 400V
±5%(J), ±10%(K)
0.004 max at 50/60Hz
U
R
x175% 10s
1000ΩF min
JIS C 4908
A max
D max
C max
B max
♦
TERMINAL FORM
B type (double faston)
8.5±0.5
10±2
S type (faston)
L type (lug)
H type (covered wire)
100±5
♦
STANDARD PRODUCTS
Part No.
MACA 105
MACA 155
MACA 205
MACA 255
MACA 305
MACA 355
MACA 405
MACA 455
MACA 505
MACA 605
MACA 705
MACA 805
MACA 905
MACA 106
MACA 126
MACA 146
MACA 166
MACA 206
cap(µF)
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
6.0
7.0
8.0
9.0
10.0
12.0
14.0
16.0
20.0
A
32.0
32.0
32.0
32.0
38.0
38.0
38.0
38.0
38.0
38.0
38.0
38.0
38.0
49.0
49.0
49.0
49.0
49.0
10±2
: Rated voltage
: Capacitance tolerance
: Terminal form
AC 220V
AC 250V
AC 300V
A
B
C
A
B
C
D
B
C
D
13.5 26.0 23.5 32.0 13.5 26.0 23.5 32.0 13.5 26.0
13.5 26.0 23.5 32.0 13.5 26.0 23.5 32.0 13.5 26.0
13.5 26.0 23.5 32.0 13.5 26.0 23.5 38.0 14.5 29.0
13.5 26.0 23.5 38.0 14.5 29.0 24.5 38.0 14.5 29.0
14.5 29.0 24.5 38.0 14.5 29.0 24.5 38.0 18.5 32.0
14.5 29.0 24.5 38.0 14.5 29.0 24.5 38.0 18.5 32.0
14.5 29.0 24.5 38.0 18.5 32.0 28.5 38.0 18.5 32.0
14.5 29.0 24.5 38.0 18.5 32.0 28.5 49.0 19.5 31.0
14.5 29.0 24.5 38.0 18.5 32.0 28.5 49.0 19.5 31.0
18.5 32.0 28.5 38.0 18.5 32.0 28.5 49.0 22.5 36.0
18.5 32.0 28.5 49.0 19.5 31.0 29.5 49.0 22.5 36.0
18.5 32.0 28.5 49.0 19.5 31.0 29.5 49.0 22.5 36.0
18.5 32.0 28.5 49.0 22.5 36.0 32.5
19.5 31.0 29.5 49.0 22.5 36.0 32.5
19.5 31.0 29.5 49.0 22.5 36.0 32.5
22.5 36.0 32.5
22.5 36.0 32.5
25.0 39.0 32.5
10±2
D
23.5
23.5
24.5
24.5
28.5
28.5
28.5
29.5
29.5
32.5
32.5
32.5
A
38.0
38.0
38.0
49.0
49.0
49.0
49.0
49.0
49.0
AC 400V
B
C
14.5 29.0
18.5 32.0
18.5 32.0
19.5 31.0
19.5 31.0
22.5 36.0
22.5 36.0
25.0 39.0
25.0 39.0
D
24.5
28.5
28.5
29.5
29.5
32.5
32.5
35.0
35.0
∗A
type using as dielectric a metallized polypropylene film is available. For details, consult our sales office.
