F-211-1
TFM–115–02–L–S
TFM–110–02–L–D–LC
™
(1,27mm) .050"
TFM, TFML SERIES
SYSTEM
TFML–125–02–L–D–LC
TFML–115–12–L–D
SMT HIGH RELIABILITY HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?TFM or
www.samtec.com?TFML
Insulator Material:
Black Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over 50µ" (1,27µm) Ni
Voltage Rating:
350 VAC mated with SFM
Operating Temp Range:
-55°C to +125°C
RoHS Compliant:
Yes
CURRENT RATING
AMBIENT TEMP TFM/SFM
20°C
5A
40°C
4.5A
60°C
3.9A
95°C
2.6A
6 POSITIONS (2x3) POWERED
TFM
Mates with:
SFM, SFMC,
SFSD
TFML
Mates with:
SFML, SFSD
(–XL option),
SFSDT
(–XL option)
Shrouded body for
blind mating
(1,27mm x 1,27mm)
.050" x .050"
micro pitch
MATED HEIGHT
LEAD STYLE
TFM
SFM
MATED
HEIGHT*
(6,35) .250
–02
(8,13) .320
(9,91) .390
(11,81) .465
*Processing conditions will
affect mated height.
–02
–12
–22
–32
• Passes 10 Year MFG
• Locking option
• Locking clip option
• Weld tab option
• Solder nail option
for up to 25Gs
1,27mm SFM/TFM
Rated @ 3dB Insertion Loss
6,35mm Stack Height
Single-Ended Signaling
6.0 GHz / 12 Gbps
Differential Pair Signaling
7.0 GHz / 14 Gbps
Performance data for other stack heights and complete
test data available at www.samtec.com?TFM or
contact sig@samtec.com
Choice of four
body heights
TM
COST-SAVING APPLICATIONS
See TFC Series for lower cost plating options.
Surface
Mount
EXTENDED LIFE PRODUCT
10 year Mixed Flowing Gas with 30µ" Gold
1,000 cycles when mated with SFM
Processing:
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10mm) .004" max (05-25)
(0,15mm) .006" max (30-50)
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OPTION
APPLICATION
SPECIFIC
OPTION
Solder nail option for
(2,36mm) .093"
thick board available.
Call Samtec.
TFM
= Standard
TFML
= Locking
(Lead style
–02 only)
05,
07,10,
15, 20,
25, 30,
35, 40,
45, 50
(Call Samtec
for other sizes)
–L
= 10µ"
(0,25µm)
Gold
on post,
Matte Tin
on tail
–S
= Single Row
(TFM only)
–A
= Alignment Pin
(N/A with –LC, –SN, –WT, –DH)
–D
= Double
Row
–LC
= Locking Clip
(N/A with –A, –SN, –WT, –DH)
(Manual placement required)
A
ALSO
AVAILABLE
(1,27) .050 x
No. of Positions + (3,18) .125
(See website for –WT & –SN OAL)
(2,79) .110
(4,45)
.175
(1,27) .050
(5,72) .225
(7,49) .295
(9,27) .365
(11,18).440
* N/A with 07, -DH or
-S row option
–02
–12*
–22*
–32*
–S
= 30µ"
(0,76µm)
Gold
on post,
Matte Tin
on tail
–DH
= Double
Horizontal
(TFM only)
–SN
= Solder Nail
(N/A with –A, –LC, –WT, –DH)
(–02 lead style & –D row only)
–WT
(1,14)
.045
(5,72)
.225 (1,27)
.050
DIA
–A
(1,27)
.050
(2,26)
.089
(0,76)
.030
= Weld Tab
–02 & 05 thru 50 pos. only
(N/A with –A, –LC, –SN, TFML)
(Standard with –DH)
–K
= Polyimide Film
Pick & Place Pad
(N/A with –P, –DH)
–DH
SINGLE ROW
DOUBLE ROW
(0,46) .018 DIA
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(1,40)
.055
–P
= Plastic Pick & Place Pad
(N/A with –K, –DH)
A
(0,36) .014
(0,66)
.026
DIA
–SN
(0,64)
.025
–WT
(2,35)
.093 (1,42)
.056
–TR
–LC
= Tape & Reel
(Specify Last)
WWW.SAMTEC.COM
