CMZ5944BPTR13LEADFREE datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> CMZ5944BPTR13LEADFREE

CMZ5944BPTR13LEADFREE: DescriptionZener Diode, 62V V(Z), 5%, 2.5W,; CategoryDiscrete semiconductor diode; File Size295KB，2 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

CMZ5944BPTR13LEADFREE Overview

Zener Diode, 62V V(Z), 5%, 2.5W,

CMZ5944BPTR13LEADFREE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	100 Ω
Number of components	1
Maximum operating temperature	150 °C
Maximum power dissipation	2.5 W
Nominal reference voltage	62 V
surface mount	YES
Maximum voltage tolerance	5%
Working test current	6 mA
Base Number Matches	1

Preview

Download Datasheet

View All

CMZ5913BP THRU CMZ5956BP

SURFACE MOUNT SILICON

ZENER DIODES

2.5 WATT, 3.3 THRU 200 VOLT

±5% TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMZ5913BP

series 2.5 Watt surface mount silicon Zener diodes are

highly reliable components designed for use in all types

of commercial, industrial, entertainment, computer, and

automotive applications. To order devices on 12mm

Tape and Reel (3000/13” Reel), add TR13 suffix to part

number.

SMB CASE

• Device is

Halogen Free

by design

MARKING: SEE MARKING CODE ON

ELECTRICAL CHARACTERISTIC TABLE

FEATURES:

• Low cost

• High reliability

• Superior lot to lot consistency

• “C” bend construction provides strain

relief when mounted on pc board

SYMBOL

TJ, Tstg

2.5

1.0

-65 to +150

125

UNITS

°C

°C/W

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation (TL=75°C)

Power Dissipation (Note 1)

Operating and Storage Junction Temperature

Thermal Resistance

Thermal Resistance (Note 1)

ELECTRICAL CHARACTERISTICS:

(TA=25°C) VF=1.5V MAX @ IF=200mA (for all types)

ZENER

VOLTAGE

TYPE

MIN

CMZ5913BP

CMZ5914BP

CMZ5915BP

CMZ5916BP

CMZ5917BP

CMZ5918BP

CMZ5919BP

CMZ5920BP

CMZ5921BP

CMZ5922BP

CMZ5923BP

CMZ5924BP

CMZ5925BP

CMZ5926BP

CMZ5927BP

CMZ5928BP

CMZ5929BP

3.135

3.420

3.705

4.085

4.465

4.845

5.320

5.890

6.460

7.125

7.790

8.645

9.500

10.45

11.40

12.35

14.25

VZ @ IZT

NOM

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

MAX

3.465

3.780

4.095

4.515

4.935

5.355

5.880

6.510

7.140

7.875

8.610

9.555

10.50

11.55

12.60

13.65

15.75

IZT

113.6

104.2

96.1

87.2

79.8

73.5

66.9

60.5

55.1

50.0

45.7

41.2

37.5

34.1

31.2

28.8

25.0

TEST

CURRENT

MAXIMUM

ZENER

IMPEDANCE

ZZT @ IZT

9.0

7.5

6.0

5.0

4.0

2.0

2.5

3.0

3.5

4.0

4.5

5.5

6.5

7.0

9.0

ZZK @ IZK

500

350

250

200

400

500

550

600

1.0

0.5

0.25

MAXIMUM

REVERSE

CURRENT

IR @ VR

μA

100

5.0

1.0

1.5

2.0

3.0

4.0

5.2

6.0

6.5

7.0

8.0

8.4

9.1

9.9

11.4

MAXIMUM

ZENER

CURRENT

(TL=75°C)

IZM

454

416

384

348

319

294

267

241

221

200

183

165

150

136

125

115

100

C5913BP

C5914BP

C5915BP

C5916BP

C5917BP

C5918BP

C5919BP

C5920BP

C5921BP

C5922BP

C5923BP

C5924BP

C5925BP

C5926BP

C5927BP

C5928BP

C5929BP

MARKING

CODE

Notes: (1) Mounted on 2 inch square FR-4 PCB with minimum recommended SMB copper pad area.
