MAX™ 20 Cell Series
HIGH CURRENT TRANSIENT VOLTAGE SUPPRESSOR (TVS) DIODE
VOLTAGE - 5.0 to 150 Volts
20000 Watt Peak Pulse Power
FEATURES
• Glass passivated junction
• Bidirectional
• 20000W Peak Pulse Power
capability on 10/1000 µsec waveform
• Excellent clamping capability
• Repetition rate (duty cycle):0.05%
• Sharp breakdown voltage
• Low incremental surge resistance
• Fast response time: typically less
than 1.0 ps from 0 volts to BV
• Typical IR less than 20µA above 10V
• High temperature soldering performance.
0.051 ± 0.005
(1.29 ± 0.13)
0.37 ± 0.04
(9.45 ± 0.95)
UNIT: Inch
(mm)
MECHANICAL DATA
Terminals: Solderable per MIL-STD-750. Method 2026
Mounting Position: Any
Weight: 1.49 ± 0.149g (0.053 ± 0.005 ounces)
DEVICES FOR BIPOLAR APPLICATIONS
Bidirectional use C or CA Suffix. Electrical characteristics apply in both directions.
MAXIMUM RATINGS AND CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
RATING
Peak Pulse Power Dissipation on 10x1000 µsec
waveform
Peak Pulse Current of on 10-1000 µsec waveform
SYMBOL
Pppm
Ippm
VALUE
Minimum 20000
SEE CURVE
UNITS
Watts
Amps
Cell
8/6/2002
MDE Semiconductor, Inc.
78-150 Calle Tampico, Unit 210, La Quinta, CA. U.S.A. Tel: 760-564-8656 • Fax 760-564-2414
1-800-831-4881 Email: sales@mdesemiconductor.com Web: www.mdesemiconductor.com
MAX-20™ Series
BI-DIRECTIONAL
PART NUNBER
MAX 20-5.0C
MAX 20-5.0CA
MAX 20-6.0C
MAX 20-6.0CA
MAX 20-6.5C
MAX 20-6.5CA
MAX 20-7.0C
MAX 20-7.0CA
MAX 20-7.5C
MAX 20-7.5CA
MAX 20-8.0C
MAX 20-8.0CA
MAX 20-8.5C
MAX 20-8.5CA
MAX 20-9.0C
MAX 20-9.0CA
MAX 20-10.0C
MAX 20-10.0CA
MAX 20-11.0C
MAX 20-11.0CA
MAX 20-12.0C
MAX 20-12.0CA
MAX 20-13.0C
MAX 20-13.0CA
MAX 20-14.0C
MAX 20-14.0CA
MAX 20-15.0C
MAX 20-15.0CA
MAX 20-16.0C
MAX 20-16.0CA
MAX 20-17.0C
MAX 20-17.0CA
MAX 20-18.0C
MAX 20-18.0CA
MAX 20-20.0C
MAX 20-20.0CA
MAX 20-22.0C
MAX 20-22.0CA
MAX 20-24.0C
MAX 20-24.0CA
MAX 20-26.0C
MAX 20-26.0CA
MAX 20-28.0C
MAX 20-28.0CA
REVERSE
STAND-OFF
VOLTAGE
VRWM(V)
5.00
5.00
6.00
6.00
6.50
6.50
7.00
7.00
7.50
7.50
8.00
8.00
8.50
8.50
9.00
9.00
10.00
10.00
11.00
11.00
12.00
12.00
13.00
13.00
14.00
14.00
15.00
15.00
16.00
16.00
17.00
17.00
18.00
18.00
20.00
20.00
22.00
22.00
24.00
24.00
26.00
26.00
28.00
28.00
BREAKDOWN
VOLTAGE
VBR(V)
MIN@IT
6.40
6.40
6.67
6.67
7.22
7.22
7.78
7.78
8.33
8.33
8.89
8.89
9.44
9.44
10.00
10.00
11.10
11.10
12.20
12.20
13.30
13.30
14.40
14.40
15.60
15.60
16.70
16.70
17.80
17.80
18.90
18.90
20.00
20.00
22.20
22.20
24.40
24.40
26.70
26.70
28.90
28.90
31.10
31.10
BREAKDOWN
VOLTAGE
VBR(V)
MAX@IT
7.30
7.00
8.15
7.37
8.82
7.98
9.51
8.60
10.20
9.21
10.90
9.83
11.50
10.40
12.20
11.10
13.60
12.30
14.90
13.50
16.30
14.70
17.60
15.90
19.10
17.20
20.40
18.50
21.80
19.70
23.10
20.90
24.40
22.10
27.10
24.50
29.80
26.90
32.60
29.50
35.30
31.90
38.00
34.40
TEST
CURRENT
IT
(mA)
50
50
50
50
50
50
50
50
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
MAXIMUM
CLAMPING
VOLTAGE
@Ipp Vc (V)
9.6
9.2
11.4
10.3
12.3
11.2
13.3
12.0
14.3
12.9
15.0
13.6
15.9
14.4
16.9
15.4
18.8
17.0
20.1
18.2
22.0
19.9
23.8
21.5
25.8
23.2
26.9
24.4
28.8
26.0
30.5
27.6
32.2
29.2
35.8
32.4
39.4
35.5
43.0
38.9
46.6
42.1
50.1
45.4
PEAK
PULSE
CURRENT
IPP(A)
2083.30
2173.90
1754.40
1941.70
1626.00
1785.70
1503.80
1666.70
1398.60
1550.40
1333.30
1470.60
1257.90
1388.90
1183.40
1298.70
1063.80
1176.50
995.02
1098.90
909.09
1005.00
840.34
930.23
775.19
862.07
743.49
819.67
694.44
769.23
655.74
724.64
621.12
684.93
558.66
617.28
507.51
563.38
465.12
514.14
429.18
475.06
399.20
440.53
REVERSE
LEAKAGE
@VRWM
IR(µA)
5000
5000
5000
5000
5000
5000
2000
2000
500
500
200
200
50
50
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
8/6/2002
MDE Semiconductor, Inc.
78-150 Calle Tampico, Unit 210, La Quinta, CA. U.S.A. Tel: 760-564-8656 • Fax 760-564-2414
1-800-831-4881 Email: sales@mdesemiconductor.com Web: www.mdesemiconductor.com
MAX-20™ Series
BI-DIRECTIONAL
PART NUNBER
MAX 20-30.0C
MAX 20-30.0CA
MAX 20-33.0C
MAX 20-33.0CA
MAX 20-36.0C
MAX 20-36.0CA
MAX 20-40.0C
MAX 20-40.0CA
MAX 20-43.0C
MAX 20-43.0CA
MAX 20-45.0C
MAX 20-45.0CA
MAX 20-48.0C
MAX 20-48.0CA
MAX 20-51.0C
MAX 20-51.0CA
MAX 20-54.0C
MAX 20-54.0CA
MAX 20-58.0C
MAX 20-58.0CA
MAX 20-60.0C
MAX 20-60.0CA
MAX 20-64.0C
MAX 20-64.0CA
MAX 20-70.0C
MAX 20-70.0CA
MAX 20-75.0C
MAX 20-75.0CA
MAX 20-78.0C
MAX 20-78.0CA
MAX 20-85.0C
MAX 20-85.0CA
MAX 20-90.0C
MAX 20-90.0CA
MAX 20-100.0C
MAX 20-100.0CA
MAX 20-110.0C
MAX 20-110.0CA
MAX 20-120.0C
MAX 20-120.0CA
MAX 20-130.0C
MAX 20-130.0CA
MAX 20-150.0C
MAX 20-150.0CA
REVERSE
STAND-OFF
VOLTAGE
VRWM(V)
30.00
30.00
33.00
33.00
36.00
36.00
40.00
40.00
43.0
43.0
45.0
45.0
48.0
48.0
51.0
51.0
54.0
54.0
58.0
58.0
60.0
60.0
64.0
64.0
70.0
70.0
75.0
75.0
78.0
78.0
85.0
85.0
90.0
90.0
100.0
100.0
110.0
110.0
120.0
120.0
130.0
130.0
150.0
150.0
BREAKDOWN
VOLTAGE
VBR(V)
MIN@IT
33.30
33.30
36.70
36.70
40.00
40.00
44.40
44.40
47.80
47.80
50.00
50.00
53.30
53.30
56.70
56.70
60.00
60.00
64.40
64.40
66.70
66.70
71.10
71.10
77.80
77.80
83.30
83.30
86.70
86.70
94.40
94.40
100.00
100.00
111.00
111.00
122.00
122.00
133.00
133.00
144.00
144.00
167.00
167.00
BREAKDOWN
VOLTAGE
VBR(V)
MAX@IT
40.70
36.80
44.90
40.60
48.90
44.20
54.30
49.10
58.40
52.80
61.10
55.30
65.20
58.90
69.30
62.70
73.30
66.30
78.70
71.20
81.50
73.70
86.90
78.60
95.10
86.00
102.00
92.10
106.00
95.80
115.00
104.00
122.00
111.00
136.00
123.00
149.00
135.00
163.00
147.00
176.00
159.00
204.00
185.00
TEST
CURRENT
IT
(mA)
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
MAXIMUM
CLAMPING
VOLTAGE
@Ipp Vc (V)
53.5
48.4
59.0
53.3
64.3
58.1
71.4
64.5
76.7
69.4
80.3
72.7
85.5
77.4
91.1
82.4
96.3
87.1
103.0
93.6
107.0
96.8
114.0
103.0
125.0
113.0
134.0
121.0
139.0
126.0
151.0
137.0
160.0
146.0
179.0
162.0
196.0
177.0
214.0
193.0
230.0
209.0
268.0
243.0
PEAK
PULSE
CURRENT
IPP(A)
373.83
413.22
338.98
375.23
311.04
344.23
280.11
310.08
260.76
288.18
249.07
275.10
233.92
258.40
219.54
242.72
207.68
229.62
194.17
213.68
186.92
206.61
175.44
194.17
160.00
176.99
149.25
165.29
143.88
158.73
132.45
145.99
125.00
136.99
111.73
123.46
102.04
112.99
93.458
103.63
86.957
95.694
74.627
82.305
REVERSE
LEAKAGE
@VRWM
IR(µA)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
For Bidirectional type having Vrwm of 10 volts and less, the ID limit is double.
