FUJITSU MICROELECTRONICS
DATA SHEET
DS07-12555-1Ea
8-bit Proprietary Microcontroller
CMOS
F MC-8L MB89560A Series
MB89567A/567AC/P568/PV560
■
DESCRIPTION
The MB89560A series has been developed as a general-purpose version of the F
2
MC*
1
-8L family consisting of
proprietary 8-bit, single-chip microcontrollers.
In addition to a compact instruction set, the microcontroller contains a variety of peripheral functions such as I
2
C
interface*
2
, timers, 2 ch 8-bit PWM timers, 8/16-bit timer, 21-bit timebase timer, 8-bit PWC timer, 17-bit Watch
prescaler, Watch-dog timer, High speed UART, 8-bit SIO, UART/SIO, LCD controller/driver (optional booster),
Two type Programmable Pulse Generators (PPG), an A/D converter, and external interrupt.
*1 : F
2
MC stands for FUJITSU Flexible Microcontroller.
*2 : I
2
C of this product is complied to Intel Corp. System Management Bus Rev. 1.0 specification and to the Philips
I
2
C specification.
2
■
FEATURES
•
•
•
•
F
2
MC-8L family CPU core
Low-voltage operation (when an A/D converter is not used)
Low current consumption (applicable to the dual-clock system)
Minimum execution time: 0.32
µs
at 12.5 MHz /3.5 V to 5.5 V
(Continued)
■
PACKAGES
80-pin Plastic LQFP
80-pin Plastic QFP
80-pin Plastic LQFP
80-pin Ceramic MQFP
FPT-80P-M05
FPT-80P-M06
FPT-80P-M11
MQP-80C-P01
Copyright©2002-2008 FUJITSU MICROELECTRONICS LIMITED All rights reserved
2002.8
MB89560A Series
(Continued)
• I
2
C interface circuit
• LCD controller/driver: 24 segments x 4 commons (Max 96 pixels, duty LCD mode and Static LCD mode)
• LCD booster function (option)
• Wild register (Max 6 different address locations)
• 10-bit A/D converter: 8 channels
• Three types of Serial Interface:
High Speed UART (
Transfer rate from 300 bps to 192000 bps /10 MHz main clock)
8-bit Serial I/O (SIO)
UART/SIO
• Two type of Programmable Pulse Generator(PPG): 6-bit PPG and 12-bit PPG
• Six types of timer
8-bit PWM 2 channels timers
8/16-bit timer/counter (8 bits x 2 channels or 16 bits x 1 channel)
21-bit timebase timer
8-bit PWC timer operation
17-bit Watch prescaler
Watch-dog timer
• I/O ports: Max 50 channels
• External interrupt 1: 8 channels
• External interrupt 2 (wake-up function): 4 channels
• Low-power consumption modes (stop mode, sleep mode, and watch mode)
• LQFP-80 and QFP-80 package
• CMOS technology
2
MB89560A Series
■
PRODUCT LINEUP
Part number
MB89567A
Parameter
Classification
ROM size
RAM size
Mass production products
(mask ROM products)
32 K x 8-bit
(internal mask ROM)
1 K x 8-bit
Number of instructions
Instruction bit length
Instruction length
Data bit length
Minimum execution time
Minimum interrupt processing time
: 136
: 8-bit
: 1 to 3 bytes
: 1-, 8-, 16-bit
: 0.32
µs/12.5
MHz
: 2.88
µs/12.5
MHz
OTP
48 K x 8-bit
(internal PROM)
Piggy-back
56 K x 8-bit
(external ROM)
1 K x 8-bit
MB89567AC
MB89P568
MB89PV560
CPU functions
Ports
General-purpose I/O ports (N-channel open drain): 20 pins (2 shared with I
2
C inputs,
16 shared with LCD, 2 shared with other
resources)
General-purpose I/O ports (CMOS)
: 30 pins (shared with resources)
Total
: 50 pins
21-bit
Interrupt cycle: (2
13
, 2
15
, 2
18
or 2
22
)/F
CH
*
7
Reset generate cycle: Min 2
21
/F
CH
*
7
for main clock, Min 2
14
/F
CL
*
7
for sub clock
17-bit
Interrupt cycle: 31.25 ms, 0.25 s, 0.50 s, 1.00 s, 2.00 s, 4.00 s/32.768 kHz for subclock
Can be operated either as a 2-channel 8-bit timer/counter (Timer 1 and Timer 2, each with its
own independent operating clock cycle), or as one 16-bit timer/counter
In Timer 1 or 16-bit timer/counter operation, event counter operation (external clock-triggered)
and square wave output capable
8-bit interval timer operation (square wave output capable, operating clock cycle: 1 t
inst
, 8 t
inst
,
16 t
inst
, 64 t
inst
)
8-bit resolution PWM operation (conversion cycle: 128 x 1 t
inst
to 256 x 64 t
inst
)
8/16-bit timer/counter output for counter clock selectability
8-bit timer operation (count clock cycle: 1 t
inst
, 4 t
inst
, 32 t
inst
)
8-bit reload timer operation (toggle output possible, operating clock cycle: 1 to 32 t
inst
)
8-bit pulse width measurement (continuous measurement possible: H-width, L-width, rising
edge to rising edge, falling edge to falling edge, and rising edge to falling edge)
10-bit resolution × 8 channels
A/D conversion function (conversion time: 60 t
inst
)
Continuous activation by an 8/16-bit timer/counter output or a timebase timer output capable.
Internal 6-bit counter
Pulse width and cycle are program selectable
Internal 12-bit counter
Pulse width and cycle are program selectable
(Continued)
21-bit timebase
timer
Watchdog timer
Watch prescaler
8/16-bit timer/
counter
8-bit PWM 2 ch
timer
PWC timer
10-bit A/D
converter *
2
6-bit PPG
12-bit PPG
3
MB89560A Series
(Continued)
Part number
MB89567A
Parameter
I
2
C interface*
4
Not
Available
1 channel
MB89567AC
MB89P568
MB89PV560
Transfer data length: 4-, 6-, 7-, 8-bit
High speed UART Transfer rate (300 bps to 192000 bps /9.216 MHz main clock)
support sub-clock mode
UART/SIO
Transfer data length: 7-, 8-bit for UART, 8-bit for SIO
Transfer rate (1201 bps to 78125 bps / 10 MHz main clock)
support sub-clock mode
8-bit, LSB first/MSB first selectability
Transfer clocks (one external shift clock, three internal shift clocks: 2 t
inst
, 8 t
inst
, 32 t
inst
) *
5
Common output: 4 (Max)
Segment output: 24 (Max)
LCD driving power (bias) pins: 4
LCD display RAM size: 12 bytes (24 × 4 bits, Max 96 pixels)
Duty LCD mode and Static LCD mode
Booster for LCD driving: option*
1
Dividing resistor for LCD driving: option
Maximum of 6-byte data can be assigned in 6 different address.
Used to replace any data in the ROM when specific address and data are assigned in Wild
register.
Wild register can be set up by using different communication methods through the device.
8 independent channels (interrupt vector, request flag, request output enable)
Edge selectability (rising/falling)
Used also for wake-up from stop/sleep mode. (edge detection is also permitted in stop mode.)
4 channels (“L” level interrupts, independent input enable).
Used also for wake-up from stop/sleep mode. (Low-level detection is also permitted in stop
mode.)
Sub clock mode, sleep mode, stop mode and clock mode
CMOS
2.2 V to 5.5 V
2.7 V to 5.5 V
2.7 V to 5.5 V*
3
8-bit serial I/O
LCD
Wild register
External interrupt
1 (wake-up
function)
External interrupt
2 (wake-up
function)
Standby mode
Process
Operating voltage *
6
*1 : When booster is used, the bias is reduced by 1/3. It can be selected by mask option.
*2 : Voltage varies with product.
*3 : When external ROM is used, EPROM: MBM27C512-20 should be used, the operating voltage: 4.5 V to 5.5 V.
*4 : I
2
C is complied to Intel Corp. System Management Bus Rev. 1.0 specification and to the Philips I
2
C specification.
*5 : 1 t
inst
= one instruction cycle (execution time) which can be selected as 1/4, 1/8, 1/16, or 1/64 of main clock
if main clock mode is selected, or 1/2 of the subclock if subclock mode is selected.
*6 : Varies with conditions such as the operating frequency. (See “■ELECTRICAL CHARACTERISTICS.”)
*7 : F
CH
: main clock source oscillation, F
CL
: sub clock source oscillation
4
MB89560A Series
■
PACKAGE AND CORRESPONDING PRODUCTS
Package
FPT-80P-M05
FPT-80P-M06
FPT-80P-M11
MQP-80C-P01
MB89567A
MB89567AC
MB89P568-101
MB89P568-102
MB89PV560-101
MB89PV560-102
■
DIFFERENCES AMONG PRODUCTS
1. Memory Size
Before evaluating using the OTPROM (one-time PROM) products, verify its differences from the product that
will actually be used. Take particular care on the following points:
• The stack area, etc., is set at the upper limit of the RAM.
2. Current Consumption
• For the MB89PV560, add the current consumed by the EPROM mounted in the piggy-back socket.
• When operating at low speed, the current consumed by the one-time PROM product is greater than that for
the mask ROM product. However, the current consumption is roughly the same in sleep or stop mode.
• For more information, see “
■
ELECTRICAL CHARACTERISTICS.”
3. Mask Options
The functions available as options and the method of specifying options differ between products.
Before using options check “
■
MASK OPTIONS.”
4. Wild register function
The Wild Register can be used in the following address spaces.
Device
MB89PV560
MB89P568
MB89567A/567AC
4000
H
to FFFF
H
4000
H
to FFFF
H
8000
H
to FFFF
H
Address Space
5. P40, P41
It will take about 64 count clock of external oscillation to initialize P40 and P41 pins in MB89PV560/P568.
Therefore, these ports will be unstable for a while during power-on. For MB89567A/567AC, these ports will be
in High-Z during power-on.
5
