LSI53C896

ULTRA2 SCSI CONTROLLER

The Communications Company

™

P C I - D U A L C H A N N E L U LT R A 2 S C S I M U LT I F U N C T I O N C O N T R O L L E R

BENEFITS

• Ultra2 SCSI performance up to

160 MBps aggregate throughput

• Two Ultra2 SCSI channels allow

peripherals to be organized to

optimize storage characteristics

and performance

• LVDIink

™

transceivers provide

the data reliability and cable

distances expected from

differential signaling

• Fully supported with Storage

Device Management System

(SDMS

™

) software

• Local memory and expansion

buses reduce PCI overhead

when instructions are fetched

locally

• Supports PC99 and Power

Management 1.1

OVERVIEW

In the fast-growing server and workstation marketplace, higher levels

of performance and integration are required to stay competitive. As a

result, data accessibility and the subsequent performance of the I/O

subsystem are paramount. To meet these market demands, LSI Logic developed

the LSI53C896 controller. This highly integrated single-chip solution provides

compute and data intensive designs a full featured SCSI solution for embedding

on the mainboard or as a host adapter.

APPLICATIONS

•

Servers

– Internet/Intranet network, video, e-mail, printing, database

management, etc.

•

Workstations

– CAD/CAM, industrial simulation, etc.

•

Host attach for RAID and JBOD mass storage subsystems

– Anywhere

data access is the bottleneck

SDMS SOFTWARE FOR THE LSI53C896

Most high-performance storage subsystems require hardware, firmware

and software components to create a total I/O solution. To be of value, the

solution must interoperate across the wide range of operating and computing

systems available. It is for this reason SDMS

™

software supports the

LSI53C896 to provide a complete high-performance SCSI I/O solution.

SDMS software has been certified for, and in most cases bundled with, lead-

ing operating systems. Likewise, the LSI logic BIOS is easily integrated and

coexists with popular industry system BIOS offerings as well as providing

boot capabilities for nontraditional boot devices like CD-ROMS.
