L-1513SRC-DU datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> L-1513SRC-DU

L-1513SRC-DU: DescriptionSingle Color LED, Super Bright Red, Water Clear, T-1 3/4, 5mm,; CategoryLED optoelectronic/LED photoelectric; File Size548KB，3 Pages; ManufacturerKingbright; Websitehttp://www.us.kingbright.com; Environmental Compliance

Download Datasheet Parametric View All

L-1513SRC-DU Overview

Single Color LED, Super Bright Red, Water Clear, T-1 3/4, 5mm,

L-1513SRC-DU Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	IC COMPATIBLE
color	SUPER BRIGHT RED
Configuration	SINGLE
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	1150 mcd
Installation features	RADIAL MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	9.6 mm
method of packing	BULK
peak wavelength	660 nm
shape	ROUND
size	5 mm
surface mount	NO
T code	T-1 3/4
Terminal pitch	2.54 mm
perspective	20 deg
Base Number Matches	1

Preview

Download Datasheet

View All

Kingbright

Features

ULTRA

T-1 3/4(5mm) SUPER BRIGHT LED LAMPS

L-1513SG SUPER BRIGHT GREEN

L-1513SR SUPER BRIGHT RED

Package Dimensions

BRIGHTNESS.

SMALL VIEWING ANGLE.

IC COMPATIBLE/LOW CURRENT CAPABILITY.

T-1 3/4 DIAMETER PACKAGE, TAPERED TYPE.

RELIABLE AND RUGGED.

Description

The Super Bright Green source color deivecs are made with Gallium

Phosphide Green Light Emitting Diode.

The Super Bright Red source color devices are made with Gallium

Aluminum Arsenide Red Light Emitting Diode .

Selection Guide

Part No.

Dice

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

0.25(0.01") unless otherwise noted.

3. Lead spacing is measured where the lead emer-

ge package.

4. Specifications are subjected to change without notice.

Lens Type

Iv (mcd)

@ 20 mA

Min.

Max.

200

300

1000

1300

2000

3500

4500

500

Viewing

Angle

2θ1/2

20°

30°

L-1513SGT

L-1513SGC

L-1513SRC-C

L-1513SRC-DU

L-1513SRC-D

L-1513SRC-E

L-1513SRC-F

L-1513SRD

SUPER BRIGHT GREEN (GaP)

GREEN TRANSPARENT

WATER CLEAR

100

500

1000

SUPER BRIGHT RED (GaAlAs)

WATER CLEAR

1000

2000

3500

RED DIFFUSED

100

Note:

1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.

2-L1513SR-1
