5962-9063501M2A

Description
8-CHANNEL, SGL ENDED MULTIPLEXER, CQCC20, CERAMIC, LCC-20
CategoryAnalog mixed-signal IC    The signal circuit
File Size872KB,10 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

5962-9063501M2A Overview

8-CHANNEL, SGL ENDED MULTIPLEXER, CQCC20, CERAMIC, LCC-20

5962-9063501M2A Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeQLCC
package instructionQCCN,
Contacts20
Reach Compliance Codeunknown
Analog Integrated Circuits - Other TypesSINGLE-ENDED MULTIPLEXER
JESD-30 codeS-CQCC-N20
JESD-609 codee0
length8.89 mm
Humidity sensitivity levelNOT SPECIFIED
Nominal Negative Supply Voltage (Vsup)-15 V
Number of channels8
Number of functions1
Number of terminals20
Nominal off-state isolation50 dB
Maximum on-state resistance (Ron)300 Ω
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC, METAL-SEALED COFIRED
encapsulated codeQCCN
Package shapeSQUARE
Package formCHIP CARRIER
Peak Reflow Temperature (Celsius)220
Certification statusMILITARY
Filter levelMIL-STD-883
Maximum seat height2.54 mm
Nominal supply voltage (Vsup)15 V
surface mountYES
Maximum disconnect time400 ns
Maximum connection time400 ns
technologyCMOS
Temperature levelMILITARY
Terminal surfaceTIN LEAD
Terminal formNO LEAD
Terminal pitch1.27 mm
Terminal locationQUAD
Maximum time at peak reflow temperature30
width8.89 mm
Base Number Matches1
