LBG1500G3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> LBG1500G3

LBG1500G3: DescriptionSingle Color LED Array, High Efficiency Green, Diffused,; CategoryLED optoelectronic/LED photoelectric; File Size106KB，1 Pages; ManufacturerLEDtronics; Websitehttp://ledtronics.com.my

Download Datasheet Parametric Compare View All

LBG1500G3 Overview

Single Color LED Array, High Efficiency Green, Diffused,

LBG1500G3 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
color	HIGH EFFICIENCY GREEN
Configuration	SEPARATE, 15 ELEMENTS
Lens type	DIFFUSED
Nominal luminous intensity	5 mcd
Installation features	THROUGH HOLE MOUNT
Number of functions	15
Number of terminals	30
Optoelectronic device types	SINGLE COLOR LED ARRAY
total height	6.22 mm
method of packing	BULK
peak wavelength	565 nm
shape	RECTANGULAR
surface mount	NO
Base Number Matches	1

Preview

Download Datasheet

View All



High Intensity Single and Multi Color Arrays

15 LED Circular & Linear Bargraphs

Features

Applications

Options

•

Choice of Single and

Multi Color in Same

Bargraph

Special Colors

•

Uniform LED Appearance

•

Fast Turn On/Off Time

•

Solid-State, High Shock/

•

High On/Off Contrast

Vibration Resistant

•

Linear Bargraphs are Dip

•

Segment Size 1.8 x 5mm Socket Compatible

15 LED Circular Bargraph

CBG1500X3

•

Long Life / 100,000+ Hours

•

Instrumentation

•

Available in Standard and

•

Process Controller

Gages

•

Level Indicators

•

Audio Level Indicators

•

Temperature Indicators

•

Speed Indicators

Part Selection

Part Number

CBG1500R6B

.118

.440

[11.18]

•

Optional Colors:

Orange,

Pure Green, Blue

•

Sunlight Visible LEDs

•

Low Current 2mA LEDs

•

Surface Mount

•

Bi-Color/Tri-Color LEDs

Electrical-Optical

Characteristics (Ta = 25˚C)

typ

typ/max

λP

Color

UL RED

HE RED

Lens Type/

If = mA Iv mcd Vf = V

Color

typ

DIFFUSED

8.0

5.0

4.5

5.0

1.7/2.5 660

1.9/2.5 635

2.0/2.5 585

2.1/2.5 565

CBG1500R3B

CBG1500Y3B YELLOW

CBG1500G3B HE GREEN

R.700

[17.8]

Custom Mixed Color

Part Number Example: CBG1500T3-9G5Y1R

1) Black face bargraphs are illustrated and listed as Part Numbers.

2) Grey face bargraphs are available. When ordering grey , remove the last "B" from

the Part Number in this table's left column.

R.618

R.400

COMMON

CATHODE (–)

REAR VIEW

11 12

13 14 15 16

Note: Segment color is white when off

15 LED Low Profile Linear Bargraph

LBG1500X3

1.50

[38.1]

Part Selection

Electrical-Optical

Part Number

LBG1500R6B

LBG1500R3B

Color

UL RED

HE RED

YELLOW

Lens Type/

Characteristics (Ta = 25˚C)

If = mA Iv mcd Vf = V

Color

λP

typ

typ/max

DIFFUSED

8.0

5.0

4.5

5.0

1.7/2.5 660

1.9/2.5 635

2.0/2.5 585

.400

[10.16]

.245

[6.22]

Pin 1

LBG1500Y3B

2.1/2.5 565

LBG1500G3B HE GREEN

Custom Mixed Color

Part Number Example: LBG1500T3-9G5Y1R

.010

[0.25]

.118

[3.0]

.308

[7.82]

.100 x 14 + 1.400

[35.56]

.020

[0.5]

1) Black face bargraphs are illustrated and listed as Part Numbers.

2) Grey face bargraphs are available. When ordering grey , remove the last "B" from

the Part Number in this table's left column.

29 28

27 26

25 24

23 22

21 20

19 18

17 16

Note: Segment color is white when off

11 12

13 14 15



23105 Kashiwa Court, Torrance, CA 90505

Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424

E-mail: webmaster@ledtronics.com

Website: http://www.ledtronics.com

Log # 075 Rev 8-99
