SR540: DescriptionRECTIFIER DIODE; CategoryDiscrete semiconductor diode; File Size39KB，2 Pages; ManufacturerHY Electronic; Websitehttp://www.hygroup.com.tw

Download Datasheet Parametric Compare View All

SR540 Overview

RECTIFIER DIODE

SR540 Parametric

Parameter Name	Attribute value
Maker	HY Electronic
package instruction	O-PALF-W2
Reach Compliance Code	unknow
Samacsys Descripti	HY Electronic Corp SR540, Rectifier Schottky Diode, 40V 5A, 2-Pin DO-27
Other features	FREE WHEELING DIODE
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.55 V
JEDEC-95 code	DO-27
JESD-30 code	O-PALF-W2
Maximum non-repetitive peak forward current	150 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	5 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Maximum repetitive peak reverse voltage	40 V
Maximum reverse current	1000 µA
surface mount	NO
technology	SCHOTTKY
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

SR520 thru SR5100

SCHOTTKY BARRIER RECTIFIERS

REVERSE VOLTAGE

- 20

to

100

Volts

FORWARD CURRENT

- 5.0

Amperes

DO- 27

FEATURES

●

Metal-Semiconductor junction with gard ring

●

Epitaxial construction

●

Low forward voltage drop

●

High current capability

●

The plastic material carries UL recognition 94V-0

●

For use in low vlotage, high frequency inverters,

.052(1.3)

.048(1.2) DIA.

1.0(25.4)

MI

free wheeling, and polarity protection applications

.375(9.5)

.335(8.5)

210

MECHANICAL DATA

●

Case: JEDEC DO-27 molded plastic

●

Polarity: Color band denotes cathode

●

Weight: 0.04ounces , 1.1grams

●

Mounting position: Any

.220(5.6)

.197(5.0) DIA.

1.0(25.4)

MI

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave ,60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

CHARACTERISTICS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

0.375″（9.5mm) Lead Lengths

Peak Forward Surage Current

8.3ms Single Half Sine-Wave

Super Imposed on Rated Load(JEDEC Method)

Maximum Forward Voltage at 5.0A DC

Maximum DC Reverse Current

at Rated DC Bolcking Voltage

Typical Junction Capacitance (Note1)

Typical Thermal Resistance (Note2)

Operating Temperature Range

Storage Temperature Range

@T

J

=25℃

@T

J

=100℃

@T

L

=95

℃

SYMBOL

V

RRM

V

RMS

V

DC

I

(AV)

SR520

20

14

20

SR530

30

21

30

SR540

40

28

40

SR550

50

35

50

5.0

SR560

60

42

60

SR580

80

56

80

SR5100

100

70

100

UNIT

V

A

I

FSM

V

F

I

R

C

J

R

θJA

T

J

T

STG

500

15

0.45

0.55

0.6

150

0.7

1.0

50

350

10

-55 to +150

0.85

A

V

mA

pF

℃/W

℃

NOTES: 1.Measured at 1.0 MHz and applied reverse voltage of 4.0V DC

2.Thermal resistance junction to ambient,

~ 171 ~

SR540 Related Products

	SR540	SR520	SR530	SR550
Description	RECTIFIER DIODE	5 A, 200 V, SILICON, RECTIFIER DIODE, DO-201AD	5 A, 200 V, SILICON, RECTIFIER DIODE, DO-201AD	5 A, 200 V, SILICON, RECTIFIER DIODE, DO-201AD
Maker	HY Electronic	HY Electronic	HY Electronic	HY Electronic
package instruction	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Reach Compliance Code	unknow	unknow	unknow	unknow
Other features	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE
application	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell connection	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	0.55 V	0.55 V	0.55 V	0.7 V
JEDEC-95 code	DO-27	DO-27	DO-27	DO-27
JESD-30 code	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Maximum non-repetitive peak forward current	150 A	150 A	150 A	150 A
Number of components	1	1	1	1
Phase	1	1	1	1
Number of terminals	2	2	2	2
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
Maximum output current	5 A	5 A	5 A	5 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	ROUND	ROUND	ROUND
Package form	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Maximum repetitive peak reverse voltage	40 V	20 V	30 V	50 V
Maximum reverse current	1000 µA	1000 µA	1000 µA	1000 µA
surface mount	NO	NO	NO	NO
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	WIRE	WIRE	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL	AXIAL
