BL
FEATURES
Low cost
GALAXY ELECTRICAL
UGP30A - - - UGP30K
VOLTAGE RANGE: 50 --- 800 V
CURRENT: 3.0 A
SUPER FAST RECTIFIER
DO - 27
Diffusde junction
low leakage current
Easily cleaned with alcohol,Isopropanol
and similar solvents
z
Plastic package has underwriters laboratory
flammability classification 94v-0
MECHANICAL DATA
Case:JEDEC DO--27,molded plastic
Terminals: Axial lead ,solderable per
MIL- STD-202,Method 208
Polarity: Color band denotes cathode
Weight: 0.041 ounces,1.15 grams
Mounting position: Any
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
ambient temperature unless otherwise specified.
Single phase,half wave,60Hz,resistive or inductive load. For capacitive load,derate by 20%.
UGP30 UGP30 UGP30 UGP30 UGP30 UGP30 UGP30
UNITS
A
B
D
F
G
J
K
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forw ard rectified current
9.5mm lead length,
@T
A
=75
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
100
70
100
200
140
200
300
210
300
3.0
400
280
400
600
420
600
800
560
800
V
V
V
A
Peak forw ard surge current
8.3ms single half-sine-w ave
superimposed on rated load
@T
J
=125
I
FSM
125.0
115.0
A
Maximum instantaneous forw ard voltage
@ 3.0A
Maximum reverse current
@T
A
=25
V
F
I
R
t
rr
C
J
R
θ
JA
T
J
T
STG
0.95
5.0
1.25
1.7
2.2
V
A
ns
pF
／Ｗ
at rated DC blocking voltage @T
A
=100
Maximum reverse recovery time (Note1)
Typical junction capacitance
Typical thermal resistance
(Note2)
(Note3)
120.0
35
35
20
- 55 ----- + 150
- 55 ----- + 150
Operating junction temperature range
Storage temperature range
NOTE: 1. Measured with I
F
=0.5A, I
R
=1A, I
rr
=0.25A.
www.galaxycn.com
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3.Thermal resistance junction to ambient
Document Number 0264026
BL
GALAXY ELECTRICAL
1.
RATINGS AND CHARACTERISTIC CURVES
FIG.1 -- FORWARD DERATING CURVE
PEAK FORWARD SURGE CURRENT
AMPERES
AVERAGE FORWARD CURRENT
AMPERES
3.0
UGP30A - - - UGP30K
FIG.2 --PEAK FORWARD SURGE CURRENT
125
2.5
2.0
1.5
100
8.3ms Single Half
Sine-W
ave
75
UGP30A-UGP30G
1.0
0.5
0
0
Single Phase
Half Wave 60HZ
Resistive or
Inductive Load
0.375"(9.5mm)Lead Length
25
50
75
100
125
150
175
50
UGP30J-UGP30K
25
0
1
5
10
50
100
AMBIENT TEMPERATURE,
NUMBER OF CYCLES AT 60Hz
FIG.4--TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE LEAKAGE
CURRENT,MICROAMPERES
100
FIG.3 --TYPECAL FORWARD CHARACTERISTIC
INSTANTANEOUS FORWARD CURRENT
AMPERES
10
D
30
GP
-U
-U
GP
4
P3
30
G
0A
0F
0J
P3
P3
UG
UG
1
0.4
0.2
0.1
0.04
0.02
0.01
0.2
U
UG
2
G
P3
0K
10
1
T
J
=25
Pulse W idth=300
µ
s
T
J
=100
T
J
=125
℃
0.1
0.2
0.6
1.0
1.4
1.8
2.2
0.6
1.0
1.4
1.8
2.2
INSTANTANEOUS FORWARD VOLTAGE,VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE,%
FIG.5--TYPICAL JUNCTION CAPACITANCE
JUNCTION CAPACITANCE,pF
100
60
40
20
10
6
4
2
T
J
=25
f=1.0MH
Z
1
0.1 0.2
0.4
1
2
4
10
20
40
100
REVERSE VOLTAGE,VOLTS
www.galaxycn.com
Document Number 0264026
BL
GALAXY ELECTRICAL
