EMI Suppression Capacitors (MKP)
Preliminary data
Recommended applications
X1 class for interference suppression
“Across the line” applications.
For apparatus permanently connected to mains and
isolated from direct contact with humidity
Climatic
Maximum operating temperature 110 ºC
Climatic category (IEC 60068-1): 40/110/56
Construction
Dielectric: Polypropylene (MKP)
Plastic case (UL 94 V-0)
Epoxy resin sealing (UL 94 V-0)
Features
Very small dimensions
Good self-healing properties
High voltage capability
Terminals
Parallel wire leads, lead-free tinned
Standard lead lengths: 6 –1 mm
Special lead lengths are available on request
Marking
Manufacturer’s logo and lot number,
date code, rated capacitance (coded),
capacitance tolerance (code letter) and
rated ac voltage (IEC)
Series number, sub-class (X1),
dielectric code (MKP), climatic category,
passive flammability category, approvals.
Delivery mode
Bulk (untaped)
Taped (Ammo pack or Reel)
Technical data
Rated AC voltage (IEC 60384-14)
Maximum continuous DC voltage (V DC)
Maximum operating temperature T
op,max
DC test voltage
Dissipation factor tan
δ
(in 10 )
at 20 °C, (upper limit values)
Insulation resistance R
ins
or time constant
τ
= C
R
·⋅ R
ins
at 100 V DC, 20 °C,
rel. humidity
≤
65% and for 60 s
(minimum “as delivered” values)
Passive flammability category to
IEC 40 (CO) 752
Capacitance tolerances
(measured at 1 kHz)
–3
B3291* Series
X1 / 330 V AC
Dimensional drawing
Dimensions in mm
Lead spacing
±0.4 (mm)
10
15
...
27.5
37.5
Lead diameter
d
1
(mm)
0.6
0.8
1.0
Type
B32911
B32912 ... 14
B32916
Marking examples:
= 10mm
15
≤
≤
27.5 mm
(
C
R
≤
1 µF)
22.5
≤
≤
37.5 mm
(
C
R
>
1 µF)
330 V (50/60 Hz)
760 V
+110 ºC
2500 V, 2 s
at 1 kHz
C
R
≤
0.33 µF
100,000 MΩ
B
±10% (K), ±20% (M)
C
≤
2.2 µF
1
C
R
>
0.33 µF
30,000 s
C > 2.2 µF
2
FK DC PM
Page 2 of 4
May 2007
