MAX9384EWP+T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> MAX9384EWP+T

MAX9384EWP+T: DescriptionMultiplexer, 2-Func, 2 Line Input, 1 Line Output, Complementary Output, Bipolar, PDSO20, 0.300 INCH, SOIC-20; Categorylogic logic; File Size231KB，10 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html; Environmental Compliance

Download Datasheet Parametric View All

MAX9384EWP+T Overview

Multiplexer, 2-Func, 2 Line Input, 1 Line Output, Complementary Output, Bipolar, PDSO20, 0.300 INCH, SOIC-20

MAX9384EWP+T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	SOP, SOP20,.4
Contacts	20
Reach Compliance Code	compliant
JESD-30 code	R-PDSO-G20
JESD-609 code	e3
length	12.8 mm
Logic integrated circuit type	MULTIPLEXER
Humidity sensitivity level	1
Number of functions	2
Number of entries	2
Output times	1
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output polarity	COMPLEMENTARY
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP20,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	260
power supply	-4.5 V
Maximum supply current (ICC)	24 mA
Prop。Delay @ Nom-Sup	0.58 ns
propagation delay (tpd)	0.55 ns
Certification status	Not Qualified
Maximum seat height	2.65 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

19-2484; Rev 0; 7/02

ECL/PECL Dual Differential 2:1 Multiplexer

General Description

The MAX9384 fully differential dual 2:1 multiplexer

(mux) features extremely low propagation delay (560ps

max) and output-to-output skew (40ps max). The

device is ideal for clock and data multiplexing applica-

tions. The two 2:1 muxes are controlled individually or

simultaneously through mux select inputs COM_SEL,

SEL0, and SEL1. The mux select inputs are compatible

with ECL/PECL logic, and are referenced to on-chip

outputs V

BB0

and V

BB1

, nominally V

- 1.33V.

The differential inputs D,

can be configured to accept

a single-ended signal when the unused complementary

input is connected to the on-chip supply output V

a reference voltage. All the differential inputs have bias

and clamp circuits that force the outputs to a low

default when the inputs are left open or at V

. The sin-

gle-ended mux select inputs have pulldowns to V

providing low default inputs when the select inputs are

left open.

The device operates with a wide supply range (V

) of +3.0V to +5.5V for PECL or -3.0V to -5.5V for

ECL, and is pin compatible with the MC100LVEL56 and

MC100EL56. The MAX9384 is offered in a 20-pin wide

SO package, and is specified for operation from -40°C

to +85°C.

40ps

P-P

Deterministic Jitter

440ps Differential Propagation Delay

12ps Output-to-Output Skew

Individual and Common Select

+3.0V to +5.5V Supplies for Differential

LVPECL/PECL

-3.0V to -5.5V Supplies for Differential LVECL/ECL

Outputs Low for Inputs Open or at V

>2kV ESD Protection (Human Body Model)

Pin Compatible with MC100LVEL56 and

MC100EL56

Features

MAX9384

Ordering Information

PART

MAX9384EWP

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

20 Wide SO

Applications

High-Speed Telecom, Datacom Applications

Central-Office Backplane Clock Distribution

Access Multiplexers (DSLAM/DLC)

Functional Diagram appears at end of data sheet.

TOP VIEW

D0a 1

DOa 2

BB0

D0b 4

DOb 5

D1a 6

D1a 7

BB1

D1b 9

D1b 10

Pin Configuration

20 V

19 Q0

18 Q0

17 SEL0

MAX9384

16 COM_SEL

15 SEL1

14 V

13 Q1

12 Q1

11 V

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
