February, 28th 2011
Automotive grade
AUIPS1011(
S
)(
R
)
INTELLIGENT POWER LOW SIDE SWITCH
Features
Over temperature shutdown
Over current shutdown
Active clamp
Low current & logic level input
ESD protection
Optimized Turn On/Off for EMI
Diagnostic on the input current
Product Summary
Rds(on)
13m
(
max.)
Vclamp
39V
Ishutdown
85A (typ.)
Packages
Description
The AUIPS1011(S)(R) is a three terminal Intelligent Power
Switch (IPS) that features a low side MOSFET with over-
current, over-temperature, ESD protection and drain to
source active clamp. This device offers protections and
the high reliability required in harsh environments. The
switch provides efficient protection by turning OFF the
power MOSFET when the temperature exceeds 165°C or
when the drain current reaches 85A. The device restarts
once the input is cycled. A serial resistance connected to
the input provides the diagnostic. The avalanche capability
is significantly enhanced by the active clamp and covers
most inductive load demagnetizations.
TO-220
AUIPS1011
D²Pak
AUIPS1011S
D-Pak
AUIPS1011R
Typical Connection
+Bat
Load
D
1
Input R
Input Signal
V Diag
IN
S
3
2
Control
www.irf.com
1
AUIPS1011(
S
)(
R
)
Qualification Information
†
Qualification Level
Automotive
(per AEC-Q100
††
)
Comments: This family of ICs has passed an Automotive qualification. IR’s Industrial and
Consumer qualification level is granted by extension of the higher Automotive level.
DPAK-3L
MSL1, 260°C
(per IPC/JEDEC J-STD-020)
MSL1, 260°C
(per IPC/JEDEC J-STD-020)
Not applicable
Class M4 (+/-450V)
(per AEC-Q100-003)
Class H2 (+/-2500V)
(per AEC-Q100-002)
Class C4 (+/-1000V)
(per AEC-Q100-011)
Class II, Level A
(per AEC-Q100-004)
Yes
Moisture Sensitivity Level
D2PAK-3L
TO220-5L
Machine Model
ESD
Human Body Model
Charged Device Model
IC Latch-Up Test
RoHS Compliant
†
††
Qualification standards can be found at International Rectifier’s web site
http://www.irf.com/
Exceptions to AEC-Q100 requirements are noted in the qualification report.
www.irf.com
2
AUIPS1011(
S
)(
R
)
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. (Tj= -40°C..150°C,
Vcc=6..36V unless otherwise specified).
Symbol
Vds
Vds cont.
Vin
Isd cont.
Pd
Tj max.
Parameter
Maximum drain to source voltage
Maximum continuous drain to source voltage
Maximum input voltage
Max diode continuous current (limited by thermal dissipation)
Maximum power dissipation (internally limited by thermal protection)
Rth=5°C/W AUIPS1011
Rth=40°C/W AUIPS1011S 1” sqr. footprint
Rth=50°C/W AUIPS1011R 1” sqr. footprint
Max. storage & operating temperature junction temperature
Min.
-0.3
-
-0.3
Max.
36
28
6
5
25
3.1
2.5
150
Units
V
V
V
A
W
°C
-40
Thermal Characteristics
Symbol
Rth1
Rth2
Rth1
Rth2
Rth3
Rth1
Rth2
Rth3
Parameter
Thermal resistance junction to ambient AUIPS1011 TO-220 free air
Thermal resistance junction to case AUIPS1011 TO-220
Thermal resistance junction to ambient AUIPS1011S D²Pak std. footprint
Thermal resistance junction to ambient AUIPS1011S D²Pak 1” sqr. footprint
Thermal resistance junction to case AUIPS1011S D²Pak
Thermal resistance junction to ambient AUIPS1011R D-Pak std. footprint
Thermal resistance junction to ambient AUIPS1011R D-Pak 1” sqr. footprint
Thermal resistance junction to case AUIPS1011R D-Pak
Typ.
50
1.2
60
40
1.2
70
50
1.2
Max.
Units
°C/W
Recommended Operating Conditions
These values are given for a quick design. For operation outside these conditions, please consult the application notes.
Symbol
VIH
VIL
Ids
Parameter
High level input voltage
Low level input voltage
Continuous drain current, Tambient=85°C, Tj=125°C, Vin=5V
Rth=5°C/W AUIPS1011
Rth=40°C/W AUIPS1011S 1” sqr. Footprint
Rth=50°C/W AUIPS1011R 1” sqr. Footprint
Recommended resistor in series with IN pin to generate a diagnostic
Max recommended load inductance (including line inductance) (1)
Max frequency (switching losses = conduction losses)
Max Input rising time
Min.
4.5
0
Max.
5.5
0.5
18
6.5
6
10
5
200
1
Units
A
Rin
Max L
Max F
Max t rise
0.5
k
µH
Hz
µs
(1) Higher inductance is possible if maximum load current is limited - see figure 11
www.irf.com
3
AUIPS1011(
S
)(
R
)
Static Electrical Characteristics
Tj= -40..150°C, Vcc=6..28V (unless otherwise specified), typical value are given for Tj=25°C
Symbol
Rds(on)
Idss1
Idss2
V clamp1
V clamp2
Vin clamp
Vth
Parameter
ON state resistance Tj=25°C
ON state resistance Tj=150°C (2)
Drain to source leakage current
Drain to source leakage current
Drain to source clamp voltage 1
Drain to source clamp voltage 2
IN to source pin clamp voltage
Input threshold voltage
Min.
Typ.
10
19
0.1
0.2
39
39
6.5
1.7
Max.
13
25
2
4
Units
m
µA
Test Conditions
Vin=5V, Ids=30A
Vcc=14V, Tj=25°C
Vcc=28V, Tj=25°C
Id=20mA
Id=5A
Iin=1mA
Id=10mA
36
5.5
42
7.5
V
Switching Electrical Characteristics
Vcc=14V, Resistive load=0.5, Rinput=50, Vin=5V, Tj=25°C
Symbol
Tdon
Tr
Tdoff
Tf
Eon + Eoff
Parameter
Turn-on delay time to 20%
Rise time 20% to 80%
Turn-off delay time to 80%
Fall time 80% to 20%
Turn on and off energy
Min.
15
20
100
30
Typ.
50
50
330
70
5
Max.
150
100
700
150
Units
µs
mJ
Test Conditions
See figure 2
Protection Characteristics
Tj= -40..150°C, Vcc=6..28V (unless otherwise specified), typical value are given for Tj=25°C
Symbol
Tsd
Isd
OV
Vreset
Treset
Parameter
Over temperature threshold
Over current threshold
Over voltage protection (not active when
the device is ON )
IN protection reset threshold
Time to reset protection
Min.
150(2)
44
34
Typ.
165
85
37
1.7
50
Max.
Units
°C
A
V
V
µs
Test Conditions
See figure 1
See figure 1
120
15(2)
200
Vin=0V
Diagnostic
Tj= -40..150°C, Vcc=6..28V (unless otherwise specified), typical value are given for Tj=25°C
Symbol
Iin, on
Iin, off
Parameter
ON state IN positive current
OFF state IN positive current
(after protection latched )
Min.
15
150
Typ.
32
230
Max.
70
350
Units
µA
Test Conditions
Vin=5V
Vin=5V
(2) Guaranteed by design
www.irf.com
4
AUIPS1011(
S
)(
R
)
Lead Assignments
2 - Drain
2 - Drain
1- In
2- D
3- S
1 2 3
D²Pak – D Pak
1
2
3
TO220
Functional Block Diagram
All values are typical
DRAIN
37V
IN
75
15k
Vds > O.V.
43V
150k
S
R
Q
6.5V
Tj > 165°C
I > Isd
2k
SOURCE
www.irf.com
5
