Features
■
■
■
■
■
Applications
■
■
IEEE 802.3 Ethernet Compatible
Designed for AMD IC manufacturers
Fully integrated for adapter, hub and
motherboard applications
Lead free version available (see How to
Order)
Lead free version is RoHS compliant*
LAN (Local Area Network)
Ethernet
*R
PT61017L LAN 10Base-T
Electrical Specifications @ 25
°
C
Turns Ratio
TX
±
5% ................................ 1CT*:1CT*
RX
±
5% ............................... 1CT*:1CT*
OCL (uH min) ........................................ 350
Interwinding Capacitance
Cww (pF typ.) .................................... 20
Leakage Inductance Ls (uH max.) ......... 0.5
Hipot 60 sec. (Vrms) ........................... 1500
DCR (Ω max.) ........................................ 0.9
Operating Temperature ....... 0
°C
to +70
°C
*CT: Center tap
Electrical Schematic
RECEIVE
Pri
Sec
Product Dimensions
11.6
±
0.3
(0.457
±
0.012)
16
1
LOGO
2
15
0.46
(0.018)
P/N
3
6
13
14
11
6.9
±
0.3
(.272
±
.012)
9.1
±
0.3
(.358
±
.012)
7
10
8
9
Pri
Material
Termination
PT61017 ........ Phosphor Bronze/Tin-Lead
PT61017L ............... Phosphor Bronze/Tin
12
TRANSMIT
Sec
PIN 1
1.27
(0.05)
DATE CODE
Packaging Specifications
Tube ........................................ 50 pcs./tube
Tape & Reel* .......................... 750 pcs. /reel
*Optional “E” suffix at end of part number
designates tape & reel packaging - e.g.
PT61017E.
0.25
±
0.13
(0.01
±
0.005)
5.6
±
0.3
(.220
±
.012)
How to Order
PT61017 __ __
Model
Packaging
Blank = Packaged in tubes
E = Tape and reel
Termination
Blank = Tin-lead
L = Tin only (lead free)
0˚~8˚
0.25
±
0.10
(0.01
±
0.004)
0.7
±
0.3
(0.028
±
0.012)
Recommended Layout
(
)
8.89
(0.35)
6.86
(0.270)
10.66
(0.420)
0.64
(0.025)
DIMENSIONS:
MILLIMETERS
(INCHES)
1.27
(0.05)
07/05
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
