1N-SS254
HIGH-SPEED SWITCHING DIODE
Features
•
•
•
Ultra-high speed.
High withstand voltage.
Low leakage and high voltage.
Weight approx. 0.092g
Absolute Maximum Ratings (T
a
= 25
o
C)
Symbol
Peak reverse voltage
Reverse voltage
Average rectified current
Peak forward current
Non-Repetitive peak forward surge current
Junction temperature
Storage temperature range
Note: Within 1s forward surge current.
V
RM
V
R
Io
I
FM
I
FSM
*
T
j
T
S
Value
40
35
110
300
400
175
-65 to +175
Unit
V
V
mA
mA
mA
O
O
C
C
Characteristics at T
a
= 25
o
C
Symbol
Forward Voltage
at I
F
= 100mA
Reverse current
at V
R
= 35V
Capacitance
at V
R
= 0.5V, f = 1MHz
Reverse recovery time
at I
F
= 10mA V
R
= 6V
V
F
I
R
C
T
t
rr
Min.
-
-
-
-
Typ.
-
-
-
-
Max.
1.2
0.5
3
4
Unit
V
µA
pF
ns
SEMTECH ELECTRONICS LTD.
( Wholly owned subsidiary of Honey Technology Ltd.)
®
Dated : 31/12/2002
1N-SS254
Packing Specification of 52mm Ammo Pack
1.The method of inner box packing is shown in figure 1.
2.Dimension and Quantity of inner box and taping.
Product outline
A
B
C
Quantity
b
52.25
±0.25
mm
c
6.25
±0.25
mm
f
5.00
±0.30
mm
g
1.0
mm
max.
h
1.0
mm
max.
l
1
~l
2
1.0
mm
max.
m
0.8
mm
max.
DO-34
262
mm
77
mm
71
mm
5kpcs/box
3. Carton Dimension
C
Product outline
B
A(mm)
Dimension
B(mm)
C(mm)
GW…
A
3
.1
DO-34
404
273
165
Carton Label
10 box / carton
5 box / layer
2 layer / carton
4. Quantity of Carton Pack.
Product outline
Quantity
DO-34
50kpcs
5. Label
5.1 The information of inner box label must be listed:
5.1.1 TYPE
5.1.2 QTY
5.1.3 CODE
5.1.4 RMK
5.2 The information of carton label must be listed:
5.2.1 TYPE
5.2.2
QTY
figure 1
b/2
b/2
m
C
h
g
f
e
A
B
1
d
b
a
d
2
c
SEMTECH ELECTRONICS LTD.
( Wholly owned subsidiary of Honey Technology Ltd.)
®
Dated : 31/12/2002
