3AI75 Overview

75MHZ, LVCMOS, LVPECL DUAL OUTPUT OSCILLATOR

Integrated
Circuit
Systems, Inc.
ICS843-106
106.25MH
Z
, LVCMOS, LVPECL
D
UAL
O
UTPUT
O
SCILLATOR
F
EATURES
One LVCMOS/LVTTL output, 15Ω output impedance
One LVPECL output pair
Crystal oscillator interface designed for 25MHz,
18pF parallel resonant crystal
Output frequency: 106.25MHz
Random jitter: 3ps (typical)
Deterministic jitter: 0.24ps (typical)
3.3V operating supply
0°C to 70°C ambient operating temperature
Available in both standard and lead-free RoHS-compliant
packages
G
ENERAL
D
ESCRIPTION
The ICS843-106 is a Fibre Channel Dual
Output Oscillator and a member of the
HiPerClockS™
HiPerClocks
TM
family of high perfor mance
devices from ICS. The ICS843-106 uses a
25MHz crystal to synthesize 106.25MHz.
The ICS843-106 has excellent jitter performance. The
ICS843-106 is packaged in a small 8-pin TSSOP,
making it ideal for use in systems with limited board space.
IC
S
B
LOCK
D
IAGRAM
LVCMOS
106.25MHz
25MHz
P
IN
A
SSIGNMENT
Q0
V
CC
XTAL_IN
XTAL_OUT
V
EE
1
2
3
4
8
7
6
5
Q1
nQ1
V
CCO
Q0
XTAL_IN
Clock
Synthesizer
LVPECL
106.25MHz
XTAL_OUT
Q1
nQ1
ICS843-106
8-Lead TSSOP
4.40mm x 3.0mm x 0.925mm
package body
G Package
Top View
ICS843-106
8-Lead SOIC
3.90mm x 4.92mm x 1.37mm body package
M Package
Top View
843AG-106
www.icst.com/products/hiperclocks.html
1
REV. A JANUARY 10, 2006
