1260 POWER INDUCTORS
High Reliability Power Inductors
MS590PNB
■
High current, low DCR shielded power inductors
■
High temperature materials allow operation in ambient
temperatures up to 165°C.
■
Tin-lead (Sn-Pb) terminations for the best possible board
adhesion
Core material
Ferrite
Terminations
Tin-lead (63/37) over tin over nickel over phos bronze.
Weight:
2.8 g – 3.3 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
500/13″ reel; Plastic
tape: 24 mm wide, 0.35 mm thick, 16 mm pocket spacing,
6.6 mm pocket depth
DCR
3
Inductance
2
(mOhms)
(µH)
typ max
1.0 ±30%
5.8
6.5
1.5 ±30%
8.8
9.8
2.2 ±30% 11.5 12.8
3.3 ±30% 12.6 14.0
4.7 ±20% 13.9 15.5
5.6 ±20% 14.9 16.6
6.8 ±20% 16.6 18.5
8.2 ±20% 20.2 22.5
10 ±20%
21.5 23.9
12 ±20%
24.5 27.3
15 ±20%
30.7 34.2
18 ±20%
35.4 39.4
22 ±20%
36.6 40.7
27 ±20%
51.3 57.0
33 ±20%
54.9 61.0
39 ±20%
58.0 64.5
47 ±20%
80.1 89.0
56 ±20%
82.5 91.7
68 ±20%
94.5 105.0
82 ±20%
131.6 146.3
100 ±20%
141.8 157.6
120 ±10%
193.3 214.8
150 ±10%
215.4 239.4
180 ±10%
254.2 282.5
220 ±10%
314.1 349.0
270 ±10%
368.8 409.8
330 ±10%
481.3 534.8
390 ±10%
517.5 575.0
470 ±10%
721.2 801.4
560 ±10%
773.1 859.0
680 ±10%
867.6 964.0
820 ±10% 1158 1287
1000 ±10% 1273 1415
®
Part number
1
MS590PNB102NSZ
MS590PNB152NSZ
MS590PNB222NSZ
MS590PNB332NSZ
MS590PNB472MSZ
MS590PNB562MSZ
MS590PNB682MSZ
MS590PNB822MSZ
MS590PNB103MSZ
MS590PNB123MSZ
MS590PNB153MSZ
MS590PNB183MSZ
MS590PNB223MSZ
MS590PNB273MSZ
MS590PNB333MSZ
MS590PNB393MSZ
MS590PNB473MSZ
MS590PNB563MSZ
MS590PNB683MSZ
MS590PNB823MSZ
MS590PNB104MSZ
MS590PNB124KSZ
MS590PNB154KSZ
MS590PNB184KSZ
MS590PNB224KSZ
MS590PNB274KSZ
MS590PNB334KSZ
MS590PNB394KSZ
MS590PNB474KSZ
MS590PNB564KSZ
MS590PNB684KSZ
MS590PNB824KSZ
MS590PNB105KSZ
SRF
(MHz)
4
min typ
70 100
56
80.0
39
55.0
29
42.0
27
38.0
21
30.0
19.0 27.0
18.0 26.0
15.0 22.0
14.0 20.0
12.6 18.0
11.2 16.0
10.5 15.0
9.0 13.0
8.7 12.4
8.4 12.0
8.0 11.6
7.3 10.5
7.0 10.0
6.0
8.6
5.5
7.8
4.8
6.8
4.5
6.4
4.3
6.1
3.9
5.5
3.0
4.3
2.8
4.0
2.5
3.6
2.1
3.0
2.0
2.8
1.8
2.6
1.7
2.5
1.6
2.4
Isat
(A)
5
Irms
(A)
6
10% 20% 30% 20°C 40°C
drop drop drop rise rise
19.12 21.18 22.76 6.00 8.00
14.44 16.40 17.64 5.30 7.60
12.32 14.00 15.08 5.20 7.30
10.88 12.22 13.12 5.00 7.00
9.92 11.10 12.00 4.50 7.00
8.54 9.60 10.38 4.00 6.40
7.80 8.80 9.44 3.80 5.90
6.44 7.38 7.98 3.40 4.80
6.00 6.92 7.48 3.00 4.00
5.68 6.56 7.08 2.80 3.70
5.34 6.04 6.54 2.60 3.50
4.82 5.54 6.00 2.50 3.30
4.42 5.04 5.44 2.30 3.10
3.78 4.32 4.68 2.10 2.90
3.50 4.00 4.34 2.00 2.70
3.32 3.80 4.14 1.90 2.60
2.84 3.26 3.54 1.85 2.50
2.64 3.04 3.28 1.75 2.40
2.46 2.82 3.04 1.70 2.30
2.24 2.54 2.74 1.60 2.20
2.06 2.34 2.54 1.50 2.10
1.84 2.08 2.28 1.38 1.85
1.64 1.90 2.06 1.20 1.66
1.46 1.70 1.84 1.14 1.58
1.30 1.48 1.60 1.00 1.42
1.18 1.38 1.48 0.90 1.45
1.04 1.20 1.30 0.84 1.16
1.00 1.16 1.28 0.78 1.08
0.906 1.00 1.10 0.70 0.96
0.872 0.980 1.02 0.64 0.88
0.782 0.886 0.956 0.58 0.80
0.692 0.784 0.854 0.53 0.73
0.588 0.672 0.726 0.48 0.68
1. When ordering, please specify
testing
code:
MS590PNB824KSZ
Testing: Z
= COTS
H
= Screening per Coilcraft
CP-SA-10001
N
= Screening per Coilcraft
CP-SA-10004
C
= Custom screening (please
specify when ordering)
2. Inductance tested at 100 kHz, 0.1 Vrms,
0 Adc using an Agilent/HP 4263B LCR
meter or equivalent.
3. DCR measured on a micro-ohmmeter and a
Coilcraft CCF858 test fixture.
4. SRF measured using an Agilent/HP 8753D
network analyzer.
5. DC current at which the inductance drops
the specified amount from its value without
current.
6. Current that causes the specified tempera-
ture rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount
Components” before soldering.
These parts are preproduction products for electrical evaluation only.
Document MS599-1
Specification subject to change without notice.
Revised 06/15/10
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2010
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
