LA-301 B / L Series
LED displays
Single Digit LED Numeric Display
LA-301 B / L Series
LA-301 B / L series is developed because of the demand
for small single digit LED Numeric Display. Materials of
emission are GaAsP on GaP, AlGalnP, GaP and GaN.
This is the height of a letter 8mm, single digit LED
Numeric Display that is packed by epoxy resin.
Dimensions
(Unit : mm)
7.0
10˚
1.0
Features
1) The height of a letter is 8mm.
2) The light don’t leak from the segment in spite of the
small package.
3) The package of surface color is black. Color of
segment is colored in emitting color. (Blue color is only
milky white)
4) Each color has anode common and cathode common
respectively.
0.5
+0.1
0
1.0
4.0
φ0.8
(5.3)
Selection guide
Emitting color
Common
Anode
Cathode
Red
LA-301VB
LA-301VL
Red
Orange
Yellow
(High brightness)
(High brightness) (High brightness)
LA-301AB
LA-301AL
LA-301EB
LA-301EL
LA-301XB
LA-301XL
3.8±0.5
0.25
+0.1
0
5.0
Tolerance are
±0.3
unless otherwise noted:
Green
LA-301MB
LA-301ML
Blue
LA-301BB
LA-301BL
Pin assignments
Pin No.
1
+
2
+
3
+
4
+
5
+
e
d
D.P
f
g
c
a
b
+
10
+
9
+
8
+
7
+
6
Pin No.
1
2
3
4
5
6
7
8
9
10
Function
Segment "a"
Segment "f"
Segment "g"
Segment "e"
Segment "d"
D.P Cathode
D.P Anode
Segment "c"
Common
Segment "b"
Equivalent circuit (anode common)
COM
9
7
(cathode common)
COM
9
7
a b c d e f g
1 10 8 5 4 2 3
D.P
6
a b c d e f g
1 10 8 5 4 2 3
D.P
6
Rev.C
(2.0)
(8.0)
11.0
8.0
1/4
LA-301 B / L Series
LED displays
Absolute maximum ratings
(Ta=25°C)
Parameter
Power dissipation
Power dissipation
Forward current
Peak forward current
Reverse voltage
Operating temperature
Storage temperature
∗1
Pulse width 1ms Duty 1 / 5
∗2
Pulse width 0.1ms Duty 1 / 10
Symbol
P
D
P
D
/ seg
I
F
I
FP
V
R
Topr
Tstg
Orange
Yellow
Red
Blue
Green
(High brightness)
(High brightness) (High brightness)
LA-301VB / VL LA-301AB / AL
LA-301EB / EL
LA-301XB / XL LA-301MB / ML LA-301BB / BL
480
336
320
520
520
520
60
42
40
65
65
65
20
10
15
25
25
25
∗1
∗2
∗2
∗2
∗1
60
50
∗2
60
50
50
50
5
5
5
5
5
5
−25
to
+75
−30
to
+85
Red
Unit
mW
mW
mA
mA
V
˚C
˚C
Electrical characteristics
(Ta=25°C)
Parameter
Forward voltage
Reverse current
Peak wavelength
Spectral line half width
Symbol
Conditions
Orange
Yellow
Red
(High brightness)
(High brightness) (High brightness)
Typ. Max. Typ.
Max.
Typ.
Max.
Typ.
Max.
∗
∗
∗
∗
∗
2.0 2.8
2.05
2.6
2.05
2.6
2.05
2.6
∗
100
100
100
100
−
−
−
−
∗
∗
∗
650
626
610
589
−
−
−
−
40
18
∗
17
∗
15
∗
−
−
−
−
Red
Green
Blue
Unit
V
F
I
R
λ
P
∆λ
I
F
=10mA
V
R
=3V
I
F
=10mA
I
F
=10mA
Typ. Max. Typ. Max.
2.1
2.8
3.6
4.2
100
100
−
−
563
470
−
−
40
26
−
−
V
µA
nm
nm
∗
Shows the number on the condition of I
F
=20mA.
The products are not radiations resistant.
Luminous intensity
Color
Red
Red (High brightness)
Orange (High brightness)
Yellow (High brightness)
Green
Blue
λ
P
(nm)
650
626
610
589
563
470
Type
LA-301VB
LA-301VL
LA-301AB
LA-301AL
LA-301EB
LA-301EL
LA-301XB
LA-301XL
LA-301MB
LA-301ML
LA-301BB
LA-301BL
Min.
3.6
36
36
36
3.6
14
Typ.
10
90
90
90
10
56
Unit
mcd
mcd
mcd
mcd
mcd
mcd
A condition of measurement is I
F
=10mA.
Rev.C
2/4
LA-301 B / L Series
LED displays
Electrical and optical characteristic curve
100
Ta=25°C
10.00
Relative Luminous Intensity
Forward Current:I
F
(mA)
10
1
LA-301BB
LA-301BL
LA-301XB
LA-301XL
LA-301EB
LA-301EL
LA-301AB
LA-301AL
LA-301MB
LA-301ML
LA-301VB
LA-301VL
Ta=25°C
1.00
0.10
LA-301BB
LA-301BL
LA-301XB
LA-301XL
LA-301EB
LA-301EL
LA-301AB
LA-301AL
LA-301MB
LA-301ML
LA-301VB
LA-301VL
0.1 1
2
3
4
5
0.01
1
10
Forward Current:I
F
(mA)
100
Forward Voltage:V
F
(V)
Fig.1 Forward Current - Forward Voltage
Fig.2 Relative Luminous Intensity - Forward Current
I
F
=10mA
1.4
Relative Luminous Intensity
1.2
1
0.8
0.6
0.4
-25 -15 -5
5
15 25 35 45 55 65 75
1
1
50kHz
LA-301BB
LA-301BL
LA-301XB
LA-301XL
LA-301EB
LA-301EL
LA-301AB
LA-301AL
LA-301MB
LA-301ML
LA-301VB
LA-301VL
IF peak Max.
Ratio of Maximum Tolerance Peak
IF Max.
Current to Maximum Tolerance DC Current
1.6
)
10
LA-301BB
LA-301BL
500Hz
200Hz
100Hz
10kHz
5kHz
2kHz
20kHz
1kHz
(
5
10
100
1000
10000
Case Temparature (°C)
Pulse Duration tw(µs)
Fig.3 Relative Luminous Intensity - Case Temperature
Fig.4 Ratio of Maximum Tolerable Peak Current - Pulse Duration (
Ι
)
)
IF peak Max.
Ratio of Maximum Tolerance Peak
IF Max.
Current to Maximum Tolerance DC Current
100kHz
LA-301XB
LA-301XL
LA-301EB
LA-301EL
LA-301AB
LA-301AL
I
F
peak Max.
Ratio of Maximum Tolerable peak
I
F
Max.
Current to Maximum Forward Current
10
)
10
LA-301MB
LA-301ML
(
(
300Hz
100Hz
30kHz
10kHz
500Hz
200Hz
100Hz
50kHz
20kHz
10kHz
5kHz
2kHz
1kHz
1
1
10
100
1000
10000
1
1
300kHz
10
100
1000
30Hz
3kHz
1kHz
10000
100000
Pulse Duration : Tw (µs)
Pulse Duration : tw(µs)
Fig.5 Ratio of Maximum Tolerable Peak Current - Pulse Duration (
ΙΙ
)
Fig.6 Ratio of Maximum Tolerable Peak Current - Pulse Duration (
ΙΙΙ
)
Rev.C
3/4
Appendix
