SIPAT Co.,Ltd
Specifications
Parameter
Center Frequency
Insertion Loss
3 dB Bandwidth
15 dB Bandwidth
40 dB Bandwidth
50 dB Bandwidth
Passband Variation
Absolute Delay
Ultimate Rejection
Subatrate Material
Ambient Temperature
Package Size
°C
DIP2712
www.sipatsaw.com
China Electronics Technology Group Corporation No.26 Research Institute
LBN07081 SAW Filter Electrical Characteristic
Unit
MHz
dB
MHz
MHz
MHz
MHz
dB
usec
dB
Minimum
69.9
-
19.2
-
-
-
-
-
50
Typical
70
25.1
19.30
19.94
20.44
20.54
0.6
2.37
53
128 LiNbO3
25
(27.2x12.7x5.2mm
3
)
Maximum
70.1
26
-
20.0
23.0
-
1.0
4.0
-
Typical Performance
Type performance
-25.1611
-35.1611
-45.1611
Magnitude(dB)
-55.1611
-65.1611
-75.1611
-85.1611
-95.1611
-105.1611
46
52
58
64
70
76
Frequency(MHz)
82
88
94
Package Outline
Matching Configuration
L1=100nH
L2=82nH
C1=36pF
Source/Load Impedance=50 ohm
Notes - Component values may change depending
on board layout.
P.O. Box 2513 Chongqing, China 400060 Tel:+86-23-62920684 Fax:62805284 E-mail: sawmkt@sipat.com
