CVHD-960 Model
9X14 mm SMD,
3.3V, CMOS
Frequency Range:
Frequency Stability:
Frequency Pulling:
(Blank)
(Option
(Option
Temperature Range:
(Option
(Option
Storage:
Input Voltage:
Control Voltage:
Input Current:
Output:
Symmetry:
Rise/Fall Time:
Linearity:
Logic:
Load:
Jitter:
12KHz to 80MHz
Phase Noise Floor:
Sub-Harmonics:
Aging:
14MHz to 49.152MHz
±30ppm
A)
B)
M)
X)
ree
dF S
a
Le oH ant
R pli
m
Co
±100ppm Min (Std)
±150ppm Min
±200ppm Min
0°C to 70°C
-20°C to 70°C
-40°C to 85°C
-55°C to 120°C
3.3V ±0.3V
1.65V ±1.65V
25mA Typ, 40mA Max
CMOS
45/55% Max @ 50% Vdd
3ns Max @ 20% to 80% Vdd
±10% Max
"0" = 10% Vdd Max
"1" = 90% Vdd Min
30pF
0.5psec Typ., 1psec RMS Max
-145dBc/hz Typ., -140dBc/hz Max Guaranteed
None
<3ppm 1st/yr, <1ppm every year thereafter
Low Jitter, High Pull
Voltage Controlled
Crystal Oscillator
Designed using fundamental
UM-1 crystal to achieve Low
Jitter and High Pull
performance. Perfect for any
application requiring high pull
but extremely low jitter.
Available in 5 Volt version, see
CVHD-965 Model.
Bottom View
0.560
(14.2)
0.560
(14.2)
0.210
(5.3)
SUGGESTED PAD LAYOUT
0.040
(1.01)
0.050
(1.27)
0.360
(9.14)
CRYSTEK
P/N
Frequency
Date Code
1
4
0.200
(5.08)
2
3
0.070
(1.77)
0.090
(2.28)
0.280
(7.11)
0.200
(5.08)
Part Number Example:
CVHD-960(Temp)(Pull)-Freq.
CVHD-960-49.152
= 3.3V, 45/55, 0/70°C, 100ppm, 49.152 MHz
CVHD-960B-49.152
= 3.3V, 45/55, 0/70°C, 200ppm, 49.152 MHz
CVHD-960MA-49.152
= 3.3V, 45/55, -20/70°C, 150ppm , 49.152 MHz
CVHD-960XB-49.152
= 3.3V, 45/55, -40/85°C, 200ppm, 49.152 MHz
RECOMMENDED REFLOW SOLDERING PROFILE
TEMPERATURE
Pad
1
2
3
4
Connection
Volt Cont.
GND
OUT
Vdd
260°C
217°C
200°C
150°C
Ramp-Up
3°C/Sec Max.
Critical Temperature
Zone
Ramp-Down
6°C/Sec.
Preheat
180 Secs. Max.
8 Minutes Max.
90 Secs. Max.
260°C for
10 Secs. Max.
NOTE: Reflow Profile with 240°C peak also acceptable.
Specifications subject to change without notice.
TD-030602 Rev. C
