DFDA
Series
Film
Wrapped
Polyester
Radial Lead
High Voltage
100 C
Maximum
Temperature
Actual
Size
FILM - RADIAL LEAD
DFDA
The DFDA series are standard high voltage, general purpose film capacitors from UCC/NCC. These
capacitors have a high capacitance value and are available with a 10% tolerance. The DFDA series
capacitors are ideal for use as filters and noise limiters for high voltage circuits.
Summary of Specifications
Radial lead terminals.
Capacitance range: 0.01 to 4.7µF.
Voltage range: 250 to 1,000VDC; 125 to 350VAC.
Operating temperature range: 40 C to 100 C.
Standard capacitance tolerance: 10%
Nominal case size ( W H T ): 10.5 7.9 4.7mm to 30.0
Rated lifetime: 1,000 hours at 85 C.
30.5 19.2mm.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
59
DFDA Series
DFDA Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Dissipation Factor ( Tan )
Withstand Voltage
40 to
Characteristics
85 C without voltage derating;
40 to 100 C with voltage derating.
200 to 1,000VDC; 125 to 350VAC
0.01 to 4.7 F
10% ( K ) at
≤
0.8% at
20 C, 1kHz
20 C, 1kHz
Terminal-to-Terminal:
In accordance with JIS-C-5102 test conditions, there shall be no capacitor degradation after
applying the DC rated voltage for 1 minute.
Terminal-to-Resin Coating:
In accordance with JIS-C-5102 test conditions, there shall be no capacitor degradation after
applying 200% of the DC rated voltage for 5 seconds.
Insulation Resistance ( IR )
Terminal-to-Terminal in accordance with JIS-C-5102 test conditions.
DC Rated Voltage ( V )
DC Applied Voltage ( V )
Insulation
Resistance
≤
0.33 F
> 0.33 F
250, 400
100
630
500
≥
10,000 MΩ
≥
3,300 C
R
*
= MΩ
1,000
1,000
Low and High Temperature
Characteristics
In accordance with JIS-C-5102 test conditions, the measurements for stability of electrical
performance of capacitors at 40 C, 85 C and 100 C are shown in the following table.
Temperature ( C )
40
7%,
—
—
≤
0.33 F
> 0.33 F
3C
0%
85
—
≥
1,000 MΩ
≥
330 C
R
*
= MΩ
≥
170
2C
100
—
≥
500 MΩ
C
R
*
= MΩ
2C
FILM - RADIAL LEAD
Capacitance Change
Insulation
Resistance
DFDA
Humidity Load Life Test
In accordance with JIS-C-5102 test conditions, the following specifications shall be satisfied
when the capacitors are restored to 20 C after applying the DC rated voltage for 500 24 0
hours at 40 2 C, 90 - 95% RH. After the initial load test, the withstand voltage (terminal-to-
terminal) shall be tested by applying 130% of the DC rated voltage through a series resistor of
20 -1,000
Ω
/volt for 1 minute.
Appearance
: no serious degradation
Capacitance change :
≤
7% of initial measured value
Insulation resistance :
≥
3,000 MΩ for
≤
0.33 F
:
≥
1,000 C
R
*
= MΩ for > 0.33 F
Tan ( DF )
:
≤
1.0%
Load Life Test
In accordance with JIS-C-5102 test conditions, the following specifications shall be satisfied
when the capacitors are restored to 20 C after applying 125% of the DC rated voltage for
1,000 48, 0 hours at 85 2 C. The voltage shall be applied through a series resistor of
20 -1,000
Ω
/volt.
Appearance
: no serious degradation
Capacitance change :
≤
5% of initial measured value
Insulation resistance :
≥
3,000 MΩ for
≤
0.33 F
:
≥
1,000 C
R
*
= MΩ for > 0.33 F
Tan ( DF )
:
≤
1.0%
Standard
*
C
R
= Nominal Capacitance in F
Satisfies JIS-C-5115 unless otherwise specified.
Part Numbering System for DFDA Series
DFDA
2E
105
K
When ordering, always specify complete catalog number for DFDA Series.
Capacitance Tolerance: K = 10%
Capacitance Value: Expressed in picofarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
following these figures ( e.g. 105 = 1,000,000pF = 1 F ).
Voltage Code: 2E = 250VDC; 2G = 400VDC; 2J = 630VDC; 3A = 1,000VDC
Series Name: Indicates Basic Capacitor Design.
60
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
DFDA Series
Diagram of Dimensions
Film /Radial Lead
Unit: mm
W
Max.
T
Max.
H
Max.
Dipped
Epoxy
Resin
Coating
Refer to Standard Ratings Tables for
H and T dimensions.
Lead Specifications
W max.
P 1.5
7.5
10.0
15.0
16.5
*
21.5
*
22.5
26.5
*
27.5
Ø
d
3
Max.
25
Min.
Solder
Plated
Copper
Clad
Steel
P
1.5
Ø
d
10.5
12.5
18.0
20.0
25.0
25.0
30.0
30.0
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
*
Lead spacing for 1,000 VDC products.
Standard Voltage Ratings - Film/Radial Lead
FILM - RADIAL LEAD
Rated
Voltage
( WVDC)
Capacitance
(µF )
Catalog
Part Number
P 1.5*
Lead Spacing
(mm)
W max.*
Width
(mm)
H max.*
Height
(mm)
T max.*
Thickness
(mm)
DFDA
250 Volts
0.47
0.68
1.0
1.5
2.2
3.3
4.7
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
DFDA2E474K
DFDA2E684K
DFDA2E105K
DFDA2E155K
DFDA2E225K
DFDA2E335K
DFDA2E475K
DFDA2G153K
DFDA2G223K
DFDA2G333K
DFDA2G473K
DFDA2G683K
DFDA2G104K
DFDA2G154K
DFDA2G224K
DFDA2G334K
DFDA2G474K
DFDA2G684K
DFDA2G105K
DFDA2G155K
DFDA2G225K
DFDA2J103K
DFDA2J153K
DFDA2J223K
DFDA2J333K
DFDA2J473K
DFDA2J683K
DFDA2J104K
DFDA2J154K
DFDA2J224K
DFDA2J334K
15.0
15.0
15.0
15.0
22.5
22.5
22.5
7.5
7.5
7.5
10.0
10.0
10.0
15.0
15.0
15.0
15.0
22.5
22.5
27.5
27.5
10.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
15.0
22.5
18.0
18.0
18.0
18.0
25.0
25.0
25.0
10.5
10.5
10.5
12.5
12.5
12.5
18.0
18.0
18.0
18.0
25.0
25.0
30.0
30.0
12.5
12.5
12.5
12.5
12.5
18.0
18.0
18.0
18.0
25.0
11.1
12.3
13.9
17.0
16.0
18.4
22.9
7.9
8.4
9.1
8.7
10.4
11.3
10.5
11.4
12.7
14.3
14.5
16.3
17.0
21.4
8.7
9.4
11.2
12.4
13.8
11.3
12.4
14.0
16.9
15.6
6.4
7.5
9.0
10.3
9.4
11.6
12.5
4.7
5.2
6.0
5.5
5.7
6.6
5.8
6.7
8.0
9.4
8.0
9.6
10.3
11.2
5.6
6.3
6.5
7.7
8.9
6.6
7.7
9.2
10.2
9.0
400 Volts
630 Volts
*
See diagram of dimensions.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
61
DFDA Series
Standard Voltage Ratings - Film/Radial Lead
Rated
Voltage
( WVDC)
Capacitance
(µF )
Catalog
Part Number
P 1.5*
Lead Spacing
(mm)
W max.*
Width
(mm)
H max.*
Height
(mm)
T max.*
Thickness
(mm)
630 Volts
0.47
0.68
1.0
1.5
2.2
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
DFDA2J474K
DFDA2J684K
DFDA2J105K
DFDA2J155K
DFDA2J225K
DFDA3A153K
DFDA3A223K
DFDA3A333K
DFDA3A473K
DFDA3A683K
DFDA3A104K
DFDA3A154K
DFDA3A224K
DFDA3A334K
DFDA3A474K
22.5
22.5
27.5
27.5
27.5
16.5
16.5
16.5
16.5
21.5
21.5
21.5
26.5
26.5
26.5
25.0
25.0
30.0
30.0
30.0
20.0
20.0
20.0
20.0
25.0
25.0
25.0
30.0
30.0
30.0
17.5
19.8
22.4
26.1
30.5
9.7
10.8
11.8
13.3
13.6
15.3
17.6
19.9
22.6
26.0
10.7
12.9
12.0
15.3
19.2
4.9
5.9
7.1
8.5
7.2
8.8
10.9
9.5
12.4
15.4
1000 Volts
*
See diagram of dimensions.
FILM - RADIAL LEAD
DFDA
62
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
DFDA Series Technical Data
1. Storage
The DFDA series film capacitors must be stored between
40 C to 100 C.
5. Voltage Derating for Pulse Waves
The voltage derating rate for pulse waves at a maximum
operating temperature of 85 C is shown in
Figure 3.
A
pulse wave and the formula for determining the sinusoidal
AC voltage (Ep-p) are shown in
Figure 4.
Refer to
Section 7
for sine wave values.
Figure 3.
Voltage Derating Rate for Pulse Waves at
t =
250
µ
s
s
0
µ
10
µ
s
50
µ
s
25
2. Operating Temperature
Generally, the operating temperature is the ambient tem-
perature; however, the operating temperature will be the
surface temperature of the capacitor if self-heating occurs
due to ripple current or a charge-discharge current, or if
surface heating is caused by other components.
85 C.
µ
s
10
s
5
µ
3. Rated AC Voltage
If the DFDA series capacitors are used in an AC circuit, 50
to 60 Hz and within an operating temperature of 40 C to
85 C (including self-heating), the rated AC voltage must
not exceed the values shown in
Table 1.
Table 1.
Rated AC Voltage.
Rated Voltage VDC
Rated Voltage VAC
250
125
400
200
630
250
1000
350
Vp-p/Ep-p (%)
100
60
1
µ
40
30
20
s
s
µ
0.5
µ
s
0.2
µ
s
0.1
10
0.1
0.2
0.5
1
2
5
10
20
50
100
Frequency (kHz)
4. AC and DC Voltage Derating
If the operating temperature of the DFDA series capacitors
exceeds 85 C, the applied voltage should be derated as
specified in
Figure 1
for DC or
Figure 2
for AC voltage. This
will prevent capacitor damage and reduce the failure rate.
Note: If the applied voltage contains both AC and DC, the
peak voltage must not exceed the rated voltage.
Figure 1.
DC Voltage Derating Rate.
Percentage (%)
100
t
T
Figure 4.
Pulse Wave at
85 C.
Vp-p
FILM - RADIAL LEAD
Ep-p
Vrms
2 2
DFDA
6. Maximum Pulse Voltage Moving Rate
90
For the DFDA series film capacitors, the maximum pulse
voltage moving rate (permissible dv/dt), not repeatable, is
specified in
Table 2.
If there is a possibility of exceeding the
spike surge indicated, please connect a resistor in series.
Table 2.
Maximum Pulse Voltage Moving Rate.
Lead Spacing
(mm)
80
90
100
7.5
10
Maximum Pulse Moving Rate ( V/µs)
250VDC
70
50
25
25
15
15
—
—
400VDC
190
130
70
70
35
35
25
25
630VDC
210
170
90
90
45
45
35
35
1000VDC
—
—
330
330
190
190
135
135
80
70
Temperature ( C)
Figure 2.
AC Voltage Derating Rate.
Percentage (%)
100
15
16.5
*
21.5
*
22.5
80
26.5
*
27.5
*
Lead spacing for 1,000 VDC products.
60
40
80
90
100
Temperature ( C)
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
63
