e-mail: sales@freqdev.com • Web Address: http://www.freqdev.com
424 Series
Specification
(25°C and Vs ± 15 Vdc)
Analog Input Characteristics
1
Impedance
Voltage Range
Max. Safe Voltage
Analog Output Characteristics
Impedance (Closed Loop)
Linear Operating Range
Maximum Current
2
Offset Voltage
3
Offset Temp. Coeff.
Power Supply (
±
V)
Rated Voltage
Operating Range
Maximum Safe Voltage
Quiescent Current
4-Pole
Temperature
Operating
Storage
Notes:
1. Input and output signal voltage referenced to supply common.
2. Output is short circuit protected to common.
DO NOT CONNECT TO ±Vs.
3. Adjustable to zero.
4. Units operate with or without offset pin connected.
Pin-Out and Package Data
Ordering Information
Pin-Out & Package Data
0.30
424
0.00
0.025 Dia.
All dimensions are in inches
All dimensions are in inches
All case
dimensions ±0.02
All case
dimensions ±0.02"
10 k
W
min.
±
10 Vpeak
±
Vs
11
W
typ.
10
W
max.
±
10V
±
2 mA
22
mV typ.
20 mV max.
50
mV/°C
(Side View)
0.15 min.
0.80
0.70
Out
D0
0.10
0.00
Bottom View
Gnd Os
4
-Vs +Vs
D1
+5V
D2 D3
In
0.80
0.90
1.00
1.10
0.00
±
15 Vdc
±
12 to
±
18 Vdc
±
18 Vdc
±
13 mA typ.
±
20 mA max.
-20
to +70°C
-25 to +85°C
Filter Mounting Assembly-See FMA-02A
Ordering Information
Filter Type
L
- Low Pass
H
- High Pass
424 Transfer Function
B
- Butterworth
L
- Bessel
Y2
- 0.2 Ripple Chebychev
Y5
- 0.5 Ripple Chebychev
424 L4L-7
Model Number
Binary Tuning Ranges
DC Offset Adjustment
± Vs
Do not connect
if trim is not
required.
20 k
W
(Cermet)
OS
Model
Tuning
*Minimum
Number Range (Hz) Step (Hz)
1
10-160
10
2
25-400
25
3
50-800
50
4
100-1.60k
100
5
250-4.00k
250
6
500-8.00k
500
7
1.00k-16.0k
1.00k
8
2.50k-40.0k
2.50k
9
5.00k-80.0k
5.00k
10
6.40k-102.4k
6.40k
*Contact factory for custom step frequency. Maximum step 6.40 kHz.
Discrete Frequency’s
Customer must specify f
1
,f
2
,f
3
, f
4
,f
5
. Maximum span f
1
fi
f
5
1,000:1.
- Vs
We hope the information given here will be helpful. The information is based on data and our best knowledge, and we consider the information to be true and accurate. Please read all statements,
recommendations or suggestions herein in conjunction with our conditions of sale which apply to all goods supplied by us. We assume no responsibility for the use of these statements,
recommendations or suggestions, nor do we intend them as a recommendation for any use which would infringe any patent or copyright.
