LTA201-TR-B/125N: DescriptionRocker Switch, SPST, On-off, Latched, Quick Connect Terminal, Rocker Actuator, Panel Mount,; CategoryMechanical and electronic products switch; File Size601KB，4 Pages; ManufacturerCarling Technologies

Download Datasheet Parametric View All

LTA201-TR-B/125N Overview

Rocker Switch, SPST, On-off, Latched, Quick Connect Terminal, Rocker Actuator, Panel Mount,

LTA201-TR-B/125N Parametric

Parameter Name	Attribute value
Reach Compliance Code	compli
ECCN code	EAR99
Factory Lead Time	7 weeks 3 days
Actuator color	RED
Actuator length	0.3 inch
Actuator type	ROCKER
body width	13.81 mm
Body color	BLACK
body height	21.84 mm
Body length or diameter	28.44 mm
Contact (AC) maximum rated power R load	0.75HP@250VAC
Contact (AC) maximum rated load M	15A@125VAC
Contact (AC) maximum rated R load	15A@125VAC
Maximum contact current (AC)	15 A
Contact function	ON-OFF
Maximum contact voltage (AC)	125 V
Dielectric withstand voltage	1000VAC V
Electrical life	100000 Cycle(s)
illumination	LAMP
Insulation resistance	100000000 Ω
insulator material	NYLON
Installation features	PANEL MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature
surface mount	NO
Switch action	LATCHED
switch function	SPST
Switch type	ROCKER SWITCH
Terminal length	0.375 inch
Termination type	QUICK CONNECT
Base Number Matches	1

Preview

Download Datasheet

View All

LTA-Series

SINGLE POLE LIGHTED ROCKER SWITCHES

The illuminated predecessor to the Curvette series whose versatility has allowed it to stand the test of time.

Traditional styling coupled with self cleaning contacts, integrated wire leads, and various actuator choices

has made the LTA-Series appeal to a wide range of markets.

Product Highlights:

Neon or Incandescent Illumination

Long Paddle, Short Paddle or Rocker Actuators

Good for 125/250VAC or Low Voltage DC

Applications

Integrated Wire Lead Construction

Typical Applications:

Appliance

HVAC

Food Service

Transportation

Carling Technologies, Inc.
