BCM1111
®
VOICE OVER IP CPE ENGINE
FEATURES
•
The BCM1111 is the most highly-integrated silicon solution for
SUMMARY OF BENEFITS
•
Full SIP client implementation.
•
RFC 3261.
•
Voice codecs.
•
G.711, G.726, G.729A.
•
Support for four simultaneous voice channels.
Ethernet residential gateway, stand-alone media terminal
adapter and wireless router terminal adapter applications.
•
300-MHz MIPS32
®
CPU (600 DMIPS).
•
VoIP optimized instruction set.
•
Large independent data and instruction caches.
•
Read ahead cache and dedicated low-latency access port to
DRAM.
•
Two single-cycle multiply and accumulate engines.
•
Advanced single-channel memory-to-memory DMA controller.
•
DSP-less architecture.
•
Call features:
•
Auto fax/modem detect and voiceband data/T.38.
•
Voice activity detection (VAD).
•
Comfort noise generation (CNG).
•
Echo cancellation (G.168).
•
Message waiting indicator.
•
BroadVoice
®
concealment PLC.
•
LAN features:
•
DHCP server.
•
Network address translation (NAT)/PAT support.
•
Wirespeed NAT throughput.
•
WAN features:
•
PPPoE.
•
DHCP client.
•
ICSA-certified firewall.
•
Two-port audio processor module with;
•
Line analog audio interface DAC/ADC with differential
interfaces for external SLIC devices.
•
Programmable hardware impedance synthesis filter for world
line impedance matching with a single BOM.
•
Two 10/100BASE-T Ethernet MACs.
•
One 10/100BASE-T Ethernet PHY.
•
•
•
•
•
•
Expansion bus supports PCMCIA, PCI, and CardBus.
133-MHz 16-bit DDR support.
SPI master controller.
Integrated 1.2V and 2.5V linear regulator controllers.
0.13u process technology.
Layout-friendly 426-pin PBGA package.
•
Provisioning.
•
Web access to configuration in non-volatile memory.
•
TFTP firmware download.
HARDWARE PLATFORMS
•
BCM91111SMTA reference platform.
•
Ethernet residential gateway reference design.
•
Wireless terminal adapter router reference design.
OVERVIEW
Power-On
Reset
Prog. /
Watchdog
Timers
Boot Memory
for
NAND Flash
UART 1
TDM/
PCM
bus I/F
SPI
Slave &
Master
External
Interrupt
Controller
GPIOs
Voltage
Regulators
133-MHz UBus
MIPS
®
EJTAG
Ring Freq. Gen.
High-Voltage Gen.
16-bit
ADC
CIC Decimator
Decimator
Equalizer
300 MHz 4250
CMT MIPS
®
Core
Dual Thread
DSP Instructions
MMU + Dual MAC
16 KB to I-Cache
32 KB to I-Cache
16 KB to D-Cache
133-MHz UBus
Hybrid Balance
Y-Filter
16-bit
DAC
CIC Interpolator
Meter Pulse Gen.
Interpolator
Equalizer
16-bit
ADC
CIC Decimator
Decimator
Equalizer
Free Pool Manager
16 Kb SRAM
USB 1.1
HOST
Multiprotocol
Interface
Hybrid Balance
Y-Filter
PCI/Mini-PCI
NAND/NOR
Flash
16-bit
DAC
CIC Interpolator
Meter Pulse Gen.
Interpolator
Equalizer
10/100 BASE-T MAC/PHY
10/100 BASE-T MAC
Ethernet LED Driver
DDR or
SDRAM
Interface
DDR or
SDRAM
BCM1111
BCM1111 Block Diagram
The Broadcom BCM1111 VoIP processor offers a high level of system
integration, performance, and features for Ethernet residential gateway
and stand-alone media terminal adapter applications.
The BCM1111 is a highly-integrated VoIP processor based on a MIPS32
300-MHz enhanced processor core (600-DMIPS). The revolutionary
Voice on MIPS
®
technology eliminates the need for a separate DSP for
VoIP applications.
This enhanced processor core utilizes advanced instruction sets, two
single-cycle multiply and accumulate engines, and optimized memory
structures to deliver the highest level of performance on complex
vocoders. Also integrated are dual analog codecs, two 10/100 Ethernet
MACs, one 10/100 PHY, and a 32-bit, 33-MHz PCI/CardBus interface.
DMA
Control
For a four-port LAN, two-port voice terminal adapter router, the
BCM1111, along with the BCM5325E, enables a two-chip solution.
For a Wireless LAN, four-port LAN, two-port voice terminal adapter
router, the BCM1111, along with the BCM4318E and BCM5325E,
enables a three-chip solution.
BCM91111 SMTA Reference Design
To accelerate the product development cycle and time to market, the
BCM1111 comes complete with a reference design that includes
schematics, layout, BOM, and VoIP and 802.11 networking software.
Related Devices
BCM4318E: AirForce™ One with Integrated 802.11b/g Baseband,
MAC, and Radio.
