L9222
QUAD INVERTING TRANSISTOR SWITCH
1
■
■
■
■
■
FEATURES
OUTPUT VOLTAGE TO 50V
OUTPUT CURRENT TO 1.2A
VERY LOW SATURATION VOLTAGE
TTL COMPATIBLE INPUTS
INTEGRAL SUPPRESSION DIODE
Figure 1. Packages
Powerdip (12+2+2)
SO20L
Table 1. Order Codes
Part Number
Package
(PDIP12+2+2)
(SO20L)
L9222
L9222 D
2
DESCRIPTION
The L9222 monolithic quad transistor switch is de-
signed for high current, high voltage switching ap-
plications.
Each of the four switches is controlled by a logic
input and all four are controlled by a common en-
able input. All inputs are TTL-compatible for direct
connection to logic circuits. Each switch consists
of an open-collector transistor plus a clamp diode
for applications with inductive loads.
Figure 2. BLOCK DIAGRAM
The emitters of the four switches are connected to-
gether to GND. The switches of the same device
may be paralled. The device is intended to drive
coils such as relays, solenoids, unipolar stepper
motors, LED etc.
May 2004
REV. 3
1/7
L9222
Table 2. ABSOLUTE MAXIMUM RATINGS
Symbol
V
OUT
V
CC
V
i
T
j
, T
ST
Output Voltage
Logic Supply Voltage
Input Voltage
Junction and Storage Temperature Range
Parameter
Value
– 0.7 to 50
7
– 0.7 to V
CC
+ 0.3
– 55 to 150
Unit
V
V
V
°C
Figure 3. PIN CONNECTION (Top view)
DIP16
SO20L
Table 3. TRUTH TABLE
Enable
H
H
L
For each input :
H= High level
L= Low level
X = Don’t care
Input
L
H
X
Power Out
ON
OFF
OFF
Table 4. THERMAL DATA
Symbol
R
th j-amb
R
th-J-case
Parameter
Thermal Resistance Junction to ambient
Thermal Resistance Junction to case
Max
Max
Value
90
14
Unit
°C/W
°C/W
2/7
L9222
Table 5. ELECTRICAL CHARACTERISTICS
V
CC
= 5Vdc ± 5% V
EN
= 5V – 40
≤
T
j
≤
125°C unless otherwise specified
Symbol
V
CE(sus)
I
CEX
V
Parameter
Output Sustaining Voltage
Output Leakage Current
Test Condition
V
IN
= 2V V
EN
= 2V, I
OUT
= 100mA
V
CE
= 50V V
IN
= 2V, V
EN
= 0.8V
V
IN
≥
0.8V
I
OUT
= 0.1A
I
OUT
= 0.3A
I
OUT
= 0.6A; – 40 + 105 °C
V
IN
= 0.4V
V
IN
≥
2.0V
All Outputs ON I
OUT
= 06A
All Outputs OFF
V
R
= 50V
Diode Reverse Voltage
I
F
= 0.6A
I
F
= 1.2A
V
IN
= 0.4V, R = 10Ω , V
S
= 13V
T
j
= 25°C
I
L
= 600mA
I
L
= 600mA
T
j
= 25°C
V
EN
= 0.4V
V
EN
≥
2.0V
Min.
46
Typ.
Max.
1
0.3
0.5
0.8
0.8
Unit
V
mA
V
V
V
V
µA
V
µA
CE(sat) Collector Emitter Saturation
V
IL
I
IL
V
IH
I
IH
I
S
I
R
V
F
Input Low Voltage
Input Low Current
Input High Voltage
Input High Current
Logic Supply Current
Clamp Diode Leakage Current
Clamp Diode Forward Voltage
Output Current
Propagation Delay Time
(high to low transition)
Propagation Delay Time
(low to high transition)
Low Enable Voltage
Low Enable Current
High Enable Voltage
High Enable Voltage
– 15
2.0
– 15
– 15
2.0
– 15
50
10
90
20
100
1.8
2.0
mA
mA
µA
V
V
A
µs
µs
V
µA
V
I
OUT
T
PHL
T
PHL
V
ENL
I
ENL
V
ENH
I
ENH
0.9
1.2
20
20
0.8
15
µA
3/7
L9222
Figure 5. SO20L Mechanical Data & Package Dimensions
mm
DIM.
MIN.
A
A1
B
C
D
(1)
E
e
H
h
L
k
ddd
10.0
0.25
0.40
2.35
0.10
0.33
0.23
12.60
7.40
1.27
10.65
0.75
1.27
0.394
0.010
0.016
TYP.
MAX.
2.65
0.30
0.51
0.32
13.00
7.60
MIN.
0.093
0.004
0.013
0.009
0.496
0.291
0.050
0.419
0.030
0.050
TYP.
MAX.
0.104
0.012
0.200
0.013
0.512
0.299
inch
OUTLINE AND
MECHANICAL DATA
0˚ (min.), 8˚ (max.)
0.10
0.004
(1) “D” dimension does not include mold flash, protusions or gate
burrs. Mold flash, protusions or gate burrs shall not exceed
0.15mm per side.
SO20
0016022 D
5/7
