TOROIDAL INDUCTORS
High Current
Cost-effective designs
Semi-encapsulated construction
Maximum operation temperature of
130°C (Ambient + Rise)
A 2:1 inductance swing from zero to
maximum current
Electrical Specifications @ 25°C
Part
Number
R
EFERENCE
O
PERATING
V
ALUES
Inductance
ET
OP
1
I
DC
Typical
(V-µSec)
(AMPS)
(µH)
2
20kHz 40kHz
Energy
Storage
(µJ MIN)
3
Inductance
No DC
(µH)
(±20%)
D
ESIGN
C
ONTROL
V
ALUES
50kHz
DCR
Size
Test mV
(
Ω
MAX)
Code
No DC
5
Lead
Diameter
(in ±.003)
PE-51506
17.0
17.0
190
130
2460
40.0
140
0.0065
3
0.081
PE-51507
32.0
16.0
290
200
4100
70.7
270
0.0092
4
0.081
PE-51508
60.0
16.0
390
270
7700
120.0
470
0.012
5
0.081
PE-51509
14.0
10.0
135
95
700
28.5
73
0.009
1
0.057
PE-51510
23.0
11.0
170
120
1400
43.5
130
0.012
2
0.057
PE-51511
43.0
10.0
280
195
2150
85.5
210
0.018
3
0.057
PE-51512
90.0
10.0
430
300
4500
158.0
420
0.028
4
0.057
PE-51513
144.0
10.0
570
400
7200
262.0
700
0.032
5
0.057
PE-51514
32.0
6.6
200
140
700
60.5
110
0.025
1
0.040
PE-51515
52.0
7.0
230
160
1275
92.0
190
0.032
2
0.040
PE-51516
98.0
6.0
400
280
1765
188.0
310
0.048
3
0.040
PE-51517
175.0
6.0
620
425
3150
315.0
560
0.068
4
0.040
PE-51518
335.0
6.0
840
580
6030
571.0
1000
0.095
5
0.040
PE-51520
400
3.6
600
420
2700
688.0
640
0.130
3
0.036
NOTES:
3.
LI2 rating is the ability of the inductor to store energy.
1.
To prevent excessive temperature rise, limit ET
OP
to the rated ET
OP
specified. This is not a saturation limit. Temperature rise of inductors
2
is 40°C MAX at MAX current and rated ET
OP
.
4.
Design control test voltage is critical. Inductance increases with voltage.
2.
A 2:1 nominal inductance swing from no I
DC
to operating I
DC
gives
5.
RoHS compliant parts are available. Order RoHS compliant parts by adding
improved protection against current discontinuities at light loading.
the suffix "NL" to the part number (i.e. PE-51506 becomes PE-51506NL).
Inductance increases with greater ET
OP
. Reference values occur
at I
DC
and low flux density.
Mechanical
Size
Code
1
1.20/30,48
0.60/15,24
0.40/10,16
0.80/20,32
0.45/11,43
0.20/5,08
.015/0,381
1.20/30,48
2
1.44/36,57
0.80/20,32
0.60/15,24
0.90/22,86
0.70/17,78
0.20/5,08
0.03/0,76
1.44/36,57
3
1.60/40,64
0.80/20,32
0.60/15,24
0.90/22,86
0.70/17,78
0.20/5,08
0.03/0,76
1.72/43,68
4
1.95/49,53
0.91/23,11
0.70/17,78
1.20/30,48
0.90/22,86
0.20/5,08
0.03/0,76
2.00/50,80
5
2.30/58,42
1.11/28,19
0.90/22,85
1.50/38,10
1.00/25,40
0.20/5,08
0.03/0,76
2.30/58,42
A
B
C
D
E
F
G
H
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
H
MAX
E
MIN
G
MAX
1
DATE CODE
COUNTRY OF ORIGIN
PE-515XX
Schematic
1
2
3
B
MAX
± .010
3
D
F
MIN
Lead Dia.
(3 PLCs)
C
± .010
2
