4
THIS DRAWING IS UNPUBLISHED.
RELEASED FOR PUBLICATION
BY -
ALL RIGHTS RESERVED.
20
3
2
REVISIONS
P
LTR
DESCRIPTION
1
DATE
DWN
APVD
C
COPYRIGHT
20
A1
56.5
REF.
A
INITIAL RELEASE
ECR-16-016026
2SEP2015
14NOV2016
N.P
N.P
X.X
X.X
D
45 $
D
20 REF.
SW18
RECOMMENDED TORQUE O.6 Nm
T4
11
05
1X
02
X-
00
0
T4
11
05
1X
03
X-
00
0
T4
11
05
1X
04
X-
00
0
T4
11
05
1X
05
X-
00
0
1
C
TECHNICAL DATA
C
2
4
RATED VOLTAGE
RATED CURRENT
POLLUTION DEGREE
250V
4A
3
250V
4A
3
250V
4A
II
8m ^
II
3
60V
4A
3
3
OVERVOLTAGE CATEGORY
MATERIAL GROUP
CONTACT RESISTANCE
II
8m ^
II
II
8m ^
IP67
II
II
8m ^
II
INSULATION RESISTANCE
OPERATION TEMPERATURE
DEGREE OF PROTECTION
>100M ^
IP67
>100M ^
>100M ^
IP67
>100M ^
IP67
-40~85 $ C -40~85 $ C -40~85 $ C -40~85 $ C
B
T411051X02X-000
PIN ARRANGEMENT
D-CODE
T411051X03X-000
T411051X04X-000
NOTE:
1. MATERIAL:
ITEM NO.1:NUT
-BRASS
ITEM NO.2:HOUSING
-PA
ITEM NO.3:CONTACT
-BRONZE
ITEM NO.4: HOUSING BODY: BRASS
2. CONTACT FINISH:
GOLD OVER NICKEL OR SILVER OVER NICKEL
3. CABLE WIRES:
18AWG/0.75mm² Max. FOR 2-5 PINS
20AWG/0.50mm² Max. FOR 8 PINS
4. ALLDIMENSIONS ARE FOR NOMINAL REFERENCE ONLY UNLESS OTHERWISE STATED
5. PACKAGEING: 1PIECE IN A BAG
6. PN INFORMATION
T411051XXXX-000
CONTACT FINISH:
1: GOLD OVER NICKEL
2: SILVER OVER NICKEL
NUMBERS OF PINS:
02: 2 PINS
03: 3PINS
04: 4 PINS
05: 5PINS
08: 8 PINS
...
CABLE OUTLET:
1: PG7(CABLE FEED: 4-6mm)
2: PG9(CABLE FEED: 6-8mm)
THIS DRAWING IS A CONTROLLED DOCUMENT.
DIMENSIONS:
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DWN
CHK
B
T4110512051-000
T4110511051-000
T4110512052-000
T4110511052-000
T411051X05X-000
T4110512041-000
T4110511041-000
T4110512042-000
T4110511042-000
T4110512031-000
RPC-M12D-FS-5CON-PG9-SHU
RPC-M12D-FS-5CON-PG7-SHU
RPC-M12D-FS-5CON-PG9-SH
RPC-M12D-FS-5CON-PG7-SH
RPC-M12D-FS-4CON-PG9-SHU
RPC-M12D-FS-4CON-PG7-SHU
RPC-M12D-FS-4CON-PG9-SH
RPC-M12D-FS-4CON-PG7-SH
A
T4110411031-000
T4110512032-000
T4110511032-000
T4110512021-000
T4110511021-000
T4110512022-000
T4110511022-000
TE PN
1471-9 (3/13)
RPC-M12D-FS-3CON-PG9-SHU
RPC-M12D-FS-3CON-PG7-SHU
RPC-M12D-FS-3CON-PG9-SH
RPC-M12D-FS-3CON-PG7-SH
Nick Pan
Kobby Zhao
24AUG2015
24AUG2015
24AUG2015
NAME
TE Connectivity
RPC-M12D-FS-2CON-PG9-SHU
RPC-M12D-FS-2CON-PG7-SHU
RPC-M12D-FS-2CON-PG9-SH
RPC-M12D-FS-2CON-PG7-SH
TYPE
MATERIAL
mm
APVD
A
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
ANGLES
FINISH
-
0.25
0.15
-
-
PRODUCT SPEC
Xiang .Xu
APPLICATION SPEC
108-106140
-
TBD
-
-
-
114-137144
WEIGHT
-
CUSTOMER DRAWING
A2
SIZE
CAGE CODE
M12 FEMALE, D CODE, STRAIGHT
SHIELDED CONNECTOR
SCREW TERMINAL
DRAWING NO
RESTRICTED TO
-
T411051XXXX000
SCALE
1:1
SHEET
1
OF
1
REV
-
A1
