XP132A1275SR
Power MOSFET
ETR1108_001
■GENERAL
DESCRIPTION
The XP132A1275SR is a P-channel Power MOSFET with low on-state resistance and ultra high-speed switching
characteristics.
Because high-speed switching is possible, the IC can be efficiently set thereby saving energy.
The small SOP-8 package makes high density mounting possible.
■APPLICATIONS
●Notebook
PCs
●Cellular
and portable phones
●On-board
power supplies
●Li-ion
battery systems
■FEATURES
Low On-State Resistance
: Rds(on)=0.075Ω (Vgs=-4.5V)
: Rds(on)=0.115Ω (Vgs=-2.5V)
Ultra High-Speed Switching
Driving Voltage
DMOS Structure
Package
: SOP-8
: -2.5V
P-Channel Power MOSFET
■PIN
CONFIGURATION
■PIN
ASSIGNMENT
PIN NUMBER
1~3
4
5~8
PIN NAME
S
G
D
FUNCTION
Source
Gate
Drain
■EQUIVALENT
CIRCUIT
■ABSOLUTE
MAXIMUM RATINGS
Ta = 25℃
PARAMETER
Drain-Source Voltage
Gate-Source Voltage
Drain Current (DC)
Drain Current (Pulse)
Reverse Drain Current
Channel Power Dissipation *
Channel Temperature
Storage Temperature Range
SYMBOL RATINGS UNITS
Vdss
Vgss
Id
Idp
Idr
Pd
Tch
Tstg
-20
±12
-5
-20
-5
2.5
150
-55~150
V
V
A
A
A
W
℃
℃
* When implemented on a glass epoxy PCB
1/5
XP132A1275SR
■ELECTRICAL
CHARACTERISTICS
DC Characteristics
PARAMETER
Drain Cut-Off Current
Gate-Source Leak Current
Gate-Source Cut-Off Voltage
Drain-Source On-State Resistance *
Forward Transfer Admittance *
Body Drain Diode
Forward Voltage
SYMBOL
Idss
Igss
Vgs(off)
Rds(on)
| Yfs |
Vf
CONDITIONS
Vds=-20V, Vgs=0V
Vgs=±12V, Vds=0V
Id=-1mA, Vds=-10V
Id=-3A, Vgs=-4.5V
Id=-3A, Vgs=-2.5V
Id=-3A, Vds=-10V
If=-5A, Vgs=0V
MIN.
-
-
-0.5
-
-
-
-
TYP.
-
-
-
0.06
0.092
8
-0.85
MAX.
-10
±1
-1.2
0.075
0.115
-
-1.1
T
a = 25℃
UNITS
μA
μA
V
Ω
Ω
S
V
* Effective during pulse test.
Dynamic Characteristics
PARAMETER
Input Capacitance
Output Capacitance
Feedback Capacitance
SYMBOL
Ciss
Coss
Crss
Vds=-10V, Vgs=0V
f=1MHz
CONDITIONS
MIN.
-
-
-
TYP.
770
440
180
MAX.
-
-
-
T
a = 25℃
UNITS
pF
pF
pF
Switching Characteristics
PARAMETER
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
Fall Time
SYMBOL
td (on)
tr
td (off)
tf
Vgs=-5V, Id=-3A
Vdd=-10V
CONDITIONS
MIN.
-
-
-
-
TYP.
10
25
45
40
MAX.
-
-
-
-
T
a = 25℃
UNITS
ns
ns
ns
ns
Thermal Characteristics
PARAMETER
Thermal Resistance
(Channel-Ambience)
SYMBOL
Rth (ch-a)
CONDITIONS
Implement on a glass epoxy
resin PCB
MIN.
-
TYP.
50
MAX.
-
UNITS
℃/W
2/5
