ASMT-JW11-NTV01 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> ASMT-JW11-NTV01

ASMT-JW11-NTV01: DescriptionSINGLE COLOR LED, COOL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6; CategoryLED optoelectronic/LED photoelectric; File Size370KB，16 Pages; ManufacturerAVAGO; Websitehttp://www.avagotech.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ASMT-JW11-NTV01 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ASMT-JW11-NTV01	-	-	View	Buy Now

ASMT-JW11-NTV01 Overview

SINGLE COLOR LED, COOL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6

ASMT-JW11-NTV01 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT PACKAGE-6
Reach Compliance Code	compliant
ECCN code	EAR99
color	COOL WHITE
Configuration	SINGLE
Maximum forward current	0.5 A
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	6
Maximum operating temperature	135 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.85 mm
method of packing	TAPE AND REEL 7"
shape	ROUND
size	3.7 mm
surface mount	YES
Terminal surface	Silver (Ag)
Terminal pitch	4.35 mm
perspective	165 deg
Base Number Matches	1

Preview

Download Datasheet

View All

ASMT-Jx1x

1W Mini Power LED Light Source

Data Sheet

Description

This 1W Mini Power LED Light Source is a high perfor-

mance energy efficient device which can handle high

thermal and high driving current. Option with electrically

isolated metal slug is also available.

The White Mini Power LED is available in the range of color

temperature from 2700K to 10000K.

The low profile package design and ultra small footprint is

suitable for a wide variety of applications especially where

space and height is a constraint.

The package is compatible with reflow soldering process.

To facilitate easy pick & place assembly, the LEDs are

packed in EIA-compliant tape and reel.

Features

•

Available in Red, Red Orange, Amber, Blue, Royal Blue,

Cyan, Green, Cool White, Neutral White and Warm

White color

•

Small footprint

Energy efficient

Direct heat transfer from metal slug to mother board

Compatible with reflow soldering process

High current operation

Long operation life

Wide viewing angle

Silicone encapsulation

Non-ESD sensitive (threshold > 16kV)

MSL 1 products

Applications

•

Architectural lighting

Garden lighting

Decorative lighting

Sign backlight

Safety, exit and emergency sign lightings

Specialty lighting such as task lighting and reading

lights

Retail display

Commercial lighting

Accent or marker lightings, strip or step lightings

Portable lightings, bicycle head lamp, torch lights.

Pathway lighting

Street lighting

Tunnel lighting

CAUTION:

Customer is advised to keep the LEDs in the MBB when not in use as prolonged exposure to

environment might cause the silver plated leads to tarnish, which might cause difficulties in soldering.

ASMT-JW11-NTV01 Related Products

	ASMT-JW11-NTV01	ASMT-JC11-NST01	ASMT-JW11-NTT01	ASMT-JB11-NLN01	ASMT-JN11-NST01	ASMT-JY11-NST01	ASMT-JN11-NTV01
Description	SINGLE COLOR LED, COOL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6	SINGLE COLOR LED, CYAN, 3.7mm, ROHS COMPLIANT PACKAGE-6	T-3/4 SINGLE COLOR LED, COOL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6	T-3/4 SINGLE COLOR LED, BLUE, 3.7mm, ROHS COMPLIANT PACKAGE-6	T-3/4 SINGLE COLOR LED, NEUTRAL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6	T-3/4 SINGLE COLOR LED, WARM WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6	SINGLE COLOR LED, NEUTRAL WHITE, 3.7mm, ROHS COMPLIANT PACKAGE-6
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6	ROHS COMPLIANT PACKAGE-6
Reach Compliance Code	compliant	unknown	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
color	COOL WHITE	CYAN	COOL WHITE	BLUE	NEUTRAL WHITE	WARM WHITE	NEUTRAL WHITE
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Maximum forward current	0.5 A	0.5 A	0.5 A	0.35 A	0.35 A	0.5 A	0.5 A
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	1	1	1	1	1	1	1
Number of terminals	6	6	6	6	6	6	6
Optoelectronic device types	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
total height	1.85 mm	1.85 mm	1.85 mm	1.85 mm	1.85 mm	1.85 mm	1.85 mm
method of packing	TAPE AND REEL 7"	TAPE AND REEL 7"	TAPE AND REEL 7\"	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL 7\"	TAPE AND REEL 7\"
shape	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
size	3.7 mm	3.7 mm	3.7 mm	3.7 mm	3.7 mm	3.7 mm	3.7 mm
surface mount	YES	YES	YES	YES	YES	YES	YES
Terminal pitch	4.35 mm	4.35 mm	4.35 mm	4.35 mm	4.35 mm	4.35 mm	4.35 mm
perspective	165 deg	165 deg	165 deg	165 deg	140 deg	165 deg	165 deg
Is it lead-free?	Lead free	-	Lead free	Lead free	Lead free	Lead free	Lead free
Maximum operating temperature	135 °C	135 °C	135 °C	-	-	135 °C	135 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-	-	-40 °C	-40 °C
Maker	-	AVAGO	AVAGO	AVAGO	AVAGO	AVAGO	AVAGO
T code	-	-	T-3/4	T-3/4	T-3/4	T-3/4	-
