Multi-Color, Common Cathode
10mm Round Type
LED Lamps (3 Pins)
DESCRIPTION:
The 1009 series is three leaded bicolor light sources designed and white
diffused for a variety of applications where dual state illumination is required
in the same package.
There are two different chips mounted on a central common cathode lead.
Colors can be generated by independently pulse width modulating the chips.
The semi-conductor materials used are:
GaP for (H, G)
GaAsP/GaP for (E, Y)
GB-1009 SERIES
PACKAGE DIMENSIONS
Unit: mm
Tol: +/- 0.2mm
φ10.9
φ10.0
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Reverse Voltage
Reverse Current (Vr =5V)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
(1.6mm (1/16)From Body)
5 Volt
100µA
o
-40 C To 85
o
C
-40
o
C To 100
o
C
260
o
C For 5 Seconds
2.0
1.0 Max.
o
11.6
23.0 Min.
0.5
(Cathode)
3
2
1
2.0
4.0
NOTES : 1. All dimensions are in millimeters.
2. Lead spacing is measured where the leads emerge from the package.
3. Protuded resin under flange is 1.5 mm (0.059") Max.
4. Specifications are subject to change without notice.
2.54 2.54
Red
Hi-Eff Red
Yellow
Green
1
2
3
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Emitted
Color
Red
Green
GB-1009EGW
Hi-Eff Red
Green
GB-1009YGW
Yellow
Green
Lens
Color
White Diffused
White Diffused
White Diffused
White Diffused
White Diffused
White Diffused
Peak
Wavelength
λp
(nm)
697
565
635
565
585
565
Vf (v)
Min Max
1.7
1.7
1.7
1.7
1.7
1.7
2.6
2.6
2.6
2.6
2.6
2.6
Rec.
If (mA).
10-20
10-20
10-20
10-20
10-20
10-20
Iv (mcd)
Min Typ.
8.6
17.0
17.0
17.0
17.0
34.0
10.0
20.0
20.0
20.0
20.0
40.0
View
Angle
2θ
1/2
(Deg)
65
65
65
65
65
65
o
Part No.
GB-1009HGW
TESTING CONDITION FOR EACH PARAMETER :
PARAMETER:
REVERSE VOLTAGE
REVERSE CURRENT
FORWARD VOLTAGE
LUMINOUS INTENSITY
VIEWING ANGLE
RECOMMENDED OPERATING CURRENT
SYMBOL
Vr
Ir
Vf
Iv
2θ
1/2
If (Rec)
UNIT
VOLT
µA
VOLT
MCD
DEGREE
mA
TEST CONDITION
Vr = 5.0 Volt
If = 20mA
If = 20mA
If = 20mA
0
o
10
o
20
o
30
o
1.0
0.9
0.8
40
o
50
o
60
o
0.7
70
o
80
o
90
o
0.5
0.3
0.1
0.2
0.4
0.6
SPATIAL DISTRIBUTION
