KW2-502 SERIES
LED Numeric Display
Dual Digit (0.50")
DESCRIPTION:
The KW2-502 series is 0.50 inch (12.70mm) height dual digit display with
right DPs designed for viewing distances of up to six meters.
This series is suitable for use in instruments, point of sales terminals and
electrical appliances.
All devices are available as either common anode or common cathode.
PACKAGE DIMENSIONS
10.0
o
7.20
1.20
DIG.1
F
E
DIG.2
A
12.70(.5")
19.00
G
B
C
+
PIN 1
12.70
25.00
D
DP
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Parameter
Max
Reverse Voltage per segment
5V
Reverse Current per segment (Vr = 5V)
100µA
Derating Linear from 25
o
C per segment
0.4mA/
o
C
Operating Temperature Range
-40
o
C To 85
o
C
o
o
Storage Temperature Range
-40 C To 100 C
o
Soldering Temperature 1.6mm(1/16") from body for 5 sec. at 260 C
NOTES : 1. All dimensions are in millimeters (inches).
2. Tolerance is +0.25mm(0.010) unless otherwise specified.
3. Specifications are subject to change without notice.
4. NP: No Pin.
5. NC: No Connect.
o
8.00
φ0.50
15.24
2.54*4=10.16
INTERNAL CIRCUIT DIAGRAM
10
DIG.1
5
DIG.2
A B C D E F G DP A B C D E F G DP
TESTING CONDITION FOR EACH PARAMETER :
Parameter
Forward Voltage
Peak Emission Wave Length
Spectral Line Half-Width
Reverse Current
Average Luminous Intensity
Symbol
Vf
λρ
∆λ
Ir
Iv
Unit
V
nm
nm
µA
µ
cd
Test Condition
If=20mA
If=20mA
If=20mA
Vr=5V
If=10mA
7 6 4 1 3 8 9 2
10
DIG.1
5
DIG.2
A B C D E F G DP A B C D E F G DP
7 6 4 1 3 8 9 2
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Chip
Part No.
Raw
Material
GaAsP/GaP
GaAlAs
GaP
GaP
GaAsP/GaP
GaAsP/GaP
GaAlAs
GaP
GaP
GaAsP/GaP
Emitted
Color
Hi-Eff. Red
Super Red
Green
Super Green
Yellow
Hi-Eff Red
Super Red
Green
Super Green
Yellow
Common
Cathode
Common
Anode
C.C
or
C.A
Wave
Length
λρ
(nm)
635
660
565
570
585
635
660
565
570
585
Absolute Maximum Ratings
∆λ
Pd
If
Electro-optical Data(at 10mA)
o
If
If
Vf (V)
Iv (µcd)
(Peak) Per Segment (Rec) Per Segment
(nm) (mW) (mA) (mA) Min. Typ. Max. mA Min. Typ.
45
20
30
30
30
45
20
30
30
30
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
50
50
50
100
100
100
100
100
100
100
100
100
100
1.7
1.5
1.7
1.7
1.7
1.7
1.5
1.7
1.7
1.7
1.9
1.9
2.2
2.2
1.9
1.9
1.9
2.2
2.2
1.9
2.6 10-20 750
2000
KW2-502A3
KW2-502AS
KW2-502A2
KW2-502AG
KW2-502A6
KW2-502C3
KW2-502CS
KW2-502C2
KW2-502CG
KW2-502C6
2.6 10-20 5600 21000
2.6 10-20 750
2.6 10-20 850
2.6 10-20 700
2.6 10-20 750
2000
2200
1600
2000
2.6 10-20 5600 21000
2.6 10-20 750
2.6 10-20 850
2.6 10-20 700
2000
2200
1600
REMARKS : 1. The average luminous intensity is obtained by summing the luminous intensity of each segment and dividing by the total number of segments.
2. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE (International Commission on Illumination) eye-response curve.
3. Clean only by pure water, isopropanol, ethanol, Freon TF (or equivalent).
