KWM-50581XY SERIES
5 x 8 Dot Matrix (5.0mm Dot)
Multi-Color
LED Display
COL 1
2
3
4
5
1
2
7.62*7=53.34(2.100)
DESCRIPTION:
The KWM-50581XY series is 60.60mm (2.39") height 5 x 8 multi-color dot
matrix display.
This multi-color series is suitable for use in single/multi-line message display,
large area graphics display and electronic games.
All devices are available as either common row anode or common row cathode.
PACKAGE DIMENSIONS
3
60.60(2.86)
4
5
6
7
8
PIN1
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Parameter
Max
Reverse Voltage per segment
5V
Reverse Current per segment (Vr = 5V)
100µA
Derating Linear from 25
o
C per segment
0.4mA/
o
C
Operating Temperature Range
-40
o
C To 85
o
C
o
o
Storage Temperature Range
-40 C To 100 C
o
Soldering Temperature 1.6mm(1/16") from body for 5 sec. at 260 C
NOTES : 1. All dimensions are in millimeters (inches).
2. Tolerance is +0.25mm(0.010) unless otherwise specified.
3. Specifications are subject to change without notice.
4. NP: No Pin.
5. NC: No Connect.
o
7.62*4=30.48(1.200)
37.80(1.488)
φ5.0(0.197)
ROW
8.80(0.346)
6.30(0.248)
2.54*8=20.32
φ0.5(0.020)
45.72(1.800)
INTERNAL CIRCUIT DIAGRAM
ROW CATHODE
COL 1
PIN
1 18
NO.
ROW ANODE
3
4
5
ROW
1
2
3
4
5
6
7
8
COL 1
PIN
1 18
NO.
PIN
NO.
2
2
3
4
5
2 3 13 4 12 7 10 11
2 3 13 4 12 7 10 11
ROW
1
2
3
PIN
NO.
16
16
15
17
14
8
5
6
9
15
17
14
8
5
6
9
TESTING CONDITION FOR EACH PARAMETER :
Parameter
Forward Voltage
Peak Emission Wave Length
Spectral Line Half-Width
Reverse Current
Average Luminous Intensity
Symbol
Vf
λρ
∆λ
Ir
Iv
Unit
V
nm
nm
µA
µ
cd
Test Condition
If=20mA
If=20mA
If=20mA
Vr=5V
If=10mA
4
5
6
7
8
GREEN
RED
GREEN
RED
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Chip
Part No.
Raw
Material
GaAsP/GaP
GaP
KWM-50581ASG
GaAlAs
GaP
KWM-50581A26
GaAsP/GaP
GaP
KWM-50581C32
GaAsP/GaP
GaP
KWM-50581CSG
GaAlAs
GaP
KWM-50581C26
GaAsP/GaP
GaP
Emitted
Color
Hi-Eff Red
Green
Super Red
Super Green
Yellow
Green
Hi-Eff Red
Green
Super Red
Common
Common
Anode
C.C
or
C.A
Wave
Length
λρ
(nm)
635
565
660
570
585
565
635
565
660
570
585
565
Absolute Maximum Ratings
∆λ
Pd
If
Electro-optical Characteristic
o
If
If
Vf (V)
Iv (µcd)
(Peak)
(Rec)
Per Dot
Per Dot
(nm) (mW) (mA) (mA) Min. Typ. Max. mA Min. Typ.
45
30
20
30
30
30
45
30
20
30
30
30
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
100
100
100
100
100
100
100
100
100
100
100
100
1.7
1.7
1.5
1.7
1.7
1.7
1.7
1.7
1.5
1.7
1.7
1.7
1.9
2.2
1.9
2.2
1.9
2.2
1.9
2.2
1.9
2.2
1.9
2.2
2.6 10-20 900
2.6 10-20 800
1800
1700
KWM-50581A32
2.6 10-20 1600 3000
2.6 10-20 850
2.6 10-20 800
2.6 10-20 800
2.6 10-20 900
2.6 10-20 800
1850
1700
1700
1800
1700
2.6 10-20 1600 3000
2.6 10-20 850
2.6 10-20 800
2.6 10-20 800
1850
1700
1700
Super Green Cathode
Yellow
Green
REMARKS : 1. The average luminous intensity is obtained by summing the luminous intensity of each segment and dividing by the total number of segments.
2. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE (International Commission on Illumination) eye-response curve.
3. Clean only by pure water, isopropanol, ethanol, Freon TF (or equivalent).
