UPD72851GT-E1 Overview

Serial I/O Controller, 4 Channel(s), 50MBps, CMOS, PDSO48, 9.53 MM, PLASTIC, SSOP-48

UPD72851GT-E1 Parametric

Parameter Name	Attribute value
Parts packaging code	SSOP
package instruction	SSOP,
Contacts	48
Reach Compliance Code	unknown
Other features	ALSO OPERATES WITH 3.3V SUPPLY
Address bus width
boundary scan	YES
maximum clock frequency	24.576 MHz
Maximum data transfer rate	50 MBps
External data bus width	8
JESD-30 code	R-PDSO-G48
low power mode	NO
Number of serial I/Os	4
Number of terminals	48
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Certification status	Not Qualified
Maximum seat height	2 mm
Maximum supply voltage	3.6 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	8 mm
uPs/uCs/peripheral integrated circuit type	SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Base Number Matches	1

Preview

Download Datasheet

View All

DATA SHEET

MOS INTEGRATED CIRCUIT

PD72851

IEEE1394a-2000 COMPLIANT 400 Mbps ONE-PORT PHY LSI

The

PD72851 is a one-port physical layer LSI that complies with the IEEE1394a-2000 specifications.

The

PD72851 supports transfers of up to 400 Mbps and consumes less power than the

PD72850B. The

PD72851 is suitable for battery systems with an IEEE1394 interface.

FEATURES

• The one-port physical layer LSI complies with IEEE1394a-2000

• Fully interoperable with IEEE1394 std 1394 Link (FireWire

, i.LINK

)

• Meets Intel

Mobile Power Guideline 2000

• Full IEEE1394a-2000 support includes: Suspend/Resume, connection debounce, arbitrated short bus reset, multi-

speed concatenation, arbitration acceleration, fly-by concatenation

• Fully compliant with OHCI requirements

• Small package: 48-pin plastic SSOP

• Super low power: 52 mA (Operating mode)

: 115

A (Suspend mode)

• Data rate: 400/200/100 Mbps

• Supports PHY pinging and remote PHY access packets

• 3.3 V single power supply (if power not supplied via node: 3.0 V single power supply)

• 24.576 MHz crystal clock generation, 393.216 MHz PLL multiplying frequency

• 64-bit flexible register incorporated in PHY register

• Electrically isolated Link interface

• Supports LPS/Link-on as part of PHY/Link interface

• External filter capacitors for PLL not required

• Extended Resume signaling for compatibility with legacy DV devices

• System power management by signaling of node power class information

• Cable power monitor (CPS) is equipped

ORDERING INFORMATION

Part number

Package

48-pin plastic SSOP (9.53 mm (375))

PD72851GT-E1

PD72851GT-E2

The information in this document is subject to change without notice. Before using this document, please

confirm that this is the latest version.

Not all devices/types available in every country. Please check with local NEC representative for

availability and additional information.

Document No. S15262EJ1V0DS00 (1st edition)

Date Published January 2001 NS CP(K)

Printed in Japan

2001

PD72851

CONTENTS

1. PIN

1.1

1.2

1.3

1.4

1.5

1.6

FUNCTIONS..................................................................................................................................... 7

Cable Interface Pins ........................................................................................................................ 7

Link Interface Pins........................................................................................................................... 7

Control Pins ..................................................................................................................................... 8

IC ....................................................................................................................................................... 8

Power Supply Pins .......................................................................................................................... 8

Other Pins ........................................................................................................................................ 8

2. PHY REGISTERS..................................................................................................................................... 9

2.1 Complete Structure for PHY Registers.......................................................................................... 9

2.2 Port Status Page (Page 000)......................................................................................................... 12

2.3 Vendor ID Page (Page 001) ........................................................................................................... 13

2.4 Vendor Dependent Page (Page 111 : Port_select 0001) ............................................................ 13

3. INTERNAL FUNCTION.......................................................................................................................... 14

3.1 Link Interface ................................................................................................................................. 14

3.1.1 Connection Method............................................................................................................................... 14

3.1.2 LPS (Link Power Status)....................................................................................................................... 14

3.1.3 LREQ, CTL0, CTL1 and D0-D7 Pins .................................................................................................... 14

3.1.4 SCLK..................................................................................................................................................... 14

3.1.5 LKON .................................................................................................................................................... 15

3.1.6 DIRECT................................................................................................................................................. 15

3.1.7 Isolation Barrier..................................................................................................................................... 15

3.2 Cable Interface............................................................................................................................... 17

3.2.1 Connections .......................................................................................................................................... 17

3.2.2 Cable Interface Circuit .......................................................................................................................... 18

3.2.3 CPS....................................................................................................................................................... 18

3.3 Suspend/Resume .......................................................................................................................... 18

3.3.1 Suspend/Resume On Mode.................................................................................................................. 18

3.4 PLL and Crystal Oscillation Circuit ............................................................................................. 19

3.4.1 Crystal Oscillation Circuit ...................................................................................................................... 19

3.4.2 PLL........................................................................................................................................................ 19

3.5 CMC ................................................................................................................................................ 19

3.6 RESETB .......................................................................................................................................... 19

3.7 RI1 ................................................................................................................................................... 19

4. PHY/LINK INTERFACE ......................................................................................................................... 20

4.1 Initialization of Link Power Status (LPS) and PHY/Link Interface ............................................ 20

4.2 Link-on Indication.......................................................................................................................... 21

4.3 PHY/Link Interface Operation (CTL0, CTL1, LREQ, D0-D7)....................................................... 22

4.3.1 CTL0, CTL1 .......................................................................................................................................... 22

4.3.2 LREQ .................................................................................................................................................... 22

4.3.3 PHY/Link Interface Timing .................................................................................................................... 26

4.4 Acceleration Control ..................................................................................................................... 27

4.5 Transmit Status ............................................................................................................................. 28

4.6 Transmit ......................................................................................................................................... 29

Data Sheet S15262EJ1V0DS
