2SK1579
Silicon N Channel MOS FET
REJ03G0956-0200
(Previous: ADE-208-1296)
Rev.2.00
Sep 07, 2005
Application
High speed power switching
Features
•
Low on-resistance
•
High speed switching
•
Suitable for low voltage operation
Outline
RENESAS Package code: PLZZ0004CA-A
(Package name: UPAK
R
)
3
2 1
4
G
D
1. Gate
2. Drain
3. Source
4. Drain
S
Note:
Marking is “DY”.
*UPAK is a trademark of Renesas Technology Corp.
Rev.2.00 Sep 07, 2005 page 1 of 5
2SK1579
Absolute Maximum Ratings
(Ta = 25°C)
Item
Drain to source voltage
Gate to source voltage
Drain current
Drain peak current
Body to drain diode reverse drain current
Channel power dissipation
Channel temperature
Symbol
V
DSS
V
GSS
I
D
I
D(pulse)
I
DR
Pch
Tch
*1
Ratings
12
±7
2
4
2
1
150
–55 to +150
Unit
V
V
A
A
A
W
°
C
*2
Storage temperature
Tstg
Notes: 1. PW
≤
100 µs, duty cycle
≤
10%
2. Value on the alumina ceramic board (12.5
×
20
×
0.7 mm)
°
C
Electrical Characteristics
(Ta = 25°C)
Item
Drain to source cutoff current
Gate to source cutoff current
Gate to source cutoff voltage
Drain to source on resistance (1)
Drain to source on resistance (2)
DC forward transfer admittance
Input capacitance
Reverse transfer capacitance
Output capacitance
Turn-on time
Turn-off time
Note:
3. Pulse Test
Symbol
I
DSS
I
GSS
V
GS(off)
R
DS(on)
1
R
DS(on)
2
|y
fs
|
Ciss
Crss
Coss
t
(on)
t
(off)
Min
—
—
0.4
—
—
1
—
—
—
—
—
Typ
—
—
—
0.36
0.25
2.5
110
30
150
500
1500
Max
1
±5
1.4
0.7
0.35
—
—
—
—
—
—
Unit
µA
µA
V
Ω
Ω
S
pF
pF
pF
ns
ns
Test conditions
V
DS
= 8 V, V
GS
= 0
V
GS
=
±6.5
V, V
DS
= 0
V
DS
= 5 V, I
D
= 100
µA
V
GS
= 2.2 V, I
D
= 0.5 A
*3
V
GS
= 4 V, I
D
= 1 A
V
DS
= 5 V, I
D
= 1 A,
*3
∆V
GS
= 0.1 V
V
DS
= 5 V, V
GS
= 0,
f = 1 MHz
I
D
= 0.2 A, V
GS
= 0,
*3
Vin = 4 V, R
L
= 51
Ω
*3
Rev.2.00 Sep 07, 2005 page 2 of 5
2SK1579
Main Characteristics
Maximum Channel Power
Dissipation Curve
1.6
Channel Power Dissipation Pch** (W)
(** on the almina ceramic board)
Maximum Safe Operation Area
50
20
Drain Current I
D
(A)
0.8
2
1
0.5
0.2
O
is per
lim ati
ite on
d b in
y R this
DS
DC
(o
n)
5
ar
ea
1.2
10
Op
era
PW = 10 ms
1 Shot
tio
n(
T
C
0.4
=2
5
°
C)
0
50
100
150
200
Ta = 25
°
C
0.05
0.1 0.2 0.5 1
0.1
2
5
10 20
50 100
Ambient Temperature
Ta (°C)
Drain to Source Voltage V
DS
(V)
Typical Output Characteristics
5
4V
3.5 V
3V
2.5 V
3
5
Ta = 25°C
Pulse Test
Typical Transfer Characteristics
Drain Current I
D
(A)
Drain Current I
D
(A)
4
4
3
2
1
Ta = –25°C
25°C
75°C
2
2V
1
V
GS
= 1.5 V
0
2
4
6
8
10
V
DS
= 5 V
Pulse Test
0
1
2
3
4
5
Drain to Source Voltage V
DS
(V)
Drain to Source on State Resistance
vs. Gate to Source Voltage
0.5
Gate to Source Voltage V
GS
(V)
Static Drain to Source on State
Resistance vs. Drain Current
5
2
1
0.5
0.2
0.1
0.05
0.2
4V
Ta = 25°C
Pulse Test
2V
V
GS
= 3 V
Drain to Source on State Resistance R
DS (on)
(Ω)
0.4
I
D
= 0.1 A
0.2 A
0.3
0.5 A 1 A
Ta = 25°C
Pulse Test
0.2
0.1
0
1
2
3
4
5
Static Drain to Source on State Resistance
R
DS (on)
(Ω)
0.5
1
2
5
10
20
Gate to Source Voltage V
GS
(V)
Drain Current I
D
(A)
Rev.2.00 Sep 07, 2005 page 3 of 5
2SK1579
Static Drain to Source on State
Resistance vs. Temperature
1.0
Pulse Test
Static Drain to Source on State Resistance
R
DS (on)
(Ω)
Forward Transfer Admittance
vs. Drain Current
Forward Transfer Admittance
y
fs
(S)
50
V
DS
= 5 V
Pulse Test
20
10
5
Ta = –25°C
25°C
75°C
0.8
0.6
I
D
= 1 A
0.5 A
I
D
= 0.5 A
V
GS
= 2 V
0.4
V
GS
= 4 V
2
1
0.05
0.2
0.2
1A
0
–25
2A
0
25
50
75
100
0.5
1
2
5
10
20
Case Temperature T
C
(°C)
Reverse Drain Current vs.
Source to Drain Voltage
5
500
Pulse Test
Drain Current I
D
(A)
Typical Capacitance vs.
Drain to Source Voltage
Reverse Drain Current I
DR
(A)
Coss
Capacitance C (pF)
4
200
Ciss
100
50
Crss
3
2
V
GS
= 2 V
V
GS
= 0
20
10
5
0.1
V
GS
= 0
f = 1 MHz
0.2
0.5
1
2
5
10
1
0
0
1.0
2.0
Source to Drain Voltage V
SD
(V)
Drain to Source Voltage V
DS
(V)
Switching Characteristics
5,000
Switching Time t (ns)
V
GS
= 4 V, V
DD
= 10 V
PW = 2
µs,
Duty cycle = 1%
2,000
1,000
500
tf
tr
td(on)
0.2
0.5
1
2
5
td(off)
200
100
50
0.05 0.1
Drain Current I
D
(A)
Rev.2.00 Sep 07, 2005 page 4 of 5
2SK1579
Package Dimensions
JEITA Package Code
SC-62
RENESAS Code
PLZZ0004CA-A
Package Name
UPAK / UPAKV
MASS[Typ.]
0.050g
Unit: mm
4.5 ± 0.1
1.5 1.5
3.0
Ordering Information
Part Name
2SK1579DY
3000 pcs
Quantity
Shipping Container
Taping,
φ178
mm Reel
Note: For some grades, production may be terminated. Please contact the Renesas sales office to check the state of
production before ordering the product.
Rev.2.00 Sep 07, 2005 page 5 of 5
0.8 Min
0.44 Max
(0.4)
0.53 Max
0.48 Max
(2.5)
φ
1
2.5 ± 0.1
4.25 Max
0.4
1.8 Max
1.5 ± 0.1
0.44 Max
(1.5)
(0.2)
