PRELIMINARY
Notice: This is not a final specification.
Some parametric limits are subject to change.
3803 Group (Spec.H QzROM version)
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER
REJ03B0166-0110
Rev.1.10
Nov 14, 2005
DESCRIPTION
The 3803 group (Spec.H QzROM version) is the 8-bit
microcomputer based on the 740 family core technology.
The 3803 group (Spec.H QzROM version) is designed for
household products, office automation equipment, and
controlling systems that require analog signal processing,
including the serial interface functions, 8/16-bit timer, A/D
converter and D/A converter.
FEATURES
• Basic machine-language instructions ................................. 71
• Minimum instruction execution time .......................... 0.24
µs
(at 16.8 MHz oscillation frequency)
• Memory size
QzROM .................................................... 16 K to 48 K bytes
RAM ..................................................................... 2048 bytes
• Programmable input/output ports ....................................... 56
• Software pull-up resistors ............................................ Built-in
• Interrupts .............................................. 21 sources, 16 vectors
(external 8, internal 12, software 1)
• Timers ...................................................................... 16-bit × 1
8-bit × 4
(with 8-bit prescaler)
• Serial interface ......... 8-bit × 2 (UART or Clock-synchronized)
8-bit × 1 (Clock-synchronized)
• PWM ....................................... 8-bit × 1 (with 8-bit prescaler)
• A/D converter ........................................ 10-bit × 16 channels
(8-bit reading enabled)
• D/A converter ............................................ 8-bit × 2 channels
• Watchdog timer ....................................................... 16-bit × 1
• LED direct drive port..............................................................8
• Clock generating circuit ............................. Built-in 2 circuits
(connect to external ceramic resonator or quartz-crystal oscillator)
• Power source voltage
[In high-speed mode]
At 16.8 MHz oscillation frequency .................... 4.5 to 5.5 V
At 12.5 MHz oscillation frequency .................... 4.0 to 5.5 V
At 8.4 MHz oscillation frequency ...................... 2.7 to 5.5 V
At 4.2 MHz oscillation frequency ...................... 2.2 to 5.5 V
At 2.1 MHz oscillation frequency ...................... 2.0 to 5.5 V
[In middle-speed mode]
At 16.8 MHz oscillation frequency .................... 4.5 to 5.5 V
At 12.5 MHz oscillation frequency .................... 2.7 to 5.5 V
At 8.4 MHz oscillation frequency ...................... 2.2 to 5.5 V
At 6.3 MHz oscillation frequency ...................... 1.8 to 5.5 V
[In low-speed mode]
At 32 kHz oscillation frequency......................... 1.8 to 5.5 V
• Power dissipation
In high-speed mode ........................................... 40 mW (typ.)
(at 16.8 MHz oscillation frequency, at 5 V power source voltage)
In low-speed mode ............................................ 45
µW
(typ.)
(at 32 kHz oscillation frequency, at 3 V power source voltage)
• Operating temperature range .............................
−20
to 85
°C
• Packages
SP............................. PRDP0064BA-A (64-pin 750 mil SDIP)
HP.................... PLQP0064KB-A (64-pin 10 × 10 mm LQFP)
KP....................PLQP0064GA-A (64-pin 14 × 14 mm LQFP)
APPLICATION
Household products, Consumer electronics, etc.
Rev.1.10 Nov 14, 2005
REJ03B0166-0110
Page 1 of 91
PRELIMINARY
3803 Group (Spec.H QzROM version)
Notice: This is not a final specification.
Some parametric limits are subject to change.
PIN CONFIGURATION (TOP VIEW)
P1
0
/INT
41
P1
1
/INT
01
P0
2
/AN
10
P0
3
/AN
11
P0
4
/AN
12
P0
5
/AN
13
P0
6
/AN
14
P0
7
/AN
15
P0
0
/AN
8
P0
1
/AN
9
P1
2
P1
3
P1
4
P1
5
P1
6
34
43
39
37
35
48
47
46
45
44
42
41
40
38
36
33
P1
7
32
31
30
29
28
27
26
P3
7
/S
RDY3
P3
6
/S
CLK3
P3
5
/T
X
D
3
P3
4
/R
X
D
3
P3
3
P3
2
P3
1
/DA
2
P3
0
/DA
1
V
CC
V
REF
AV
SS
P6
7
/AN
7
P6
6
/AN
6
P6
5
/AN
5
P6
4
/AN
4
P6
3
/AN
3
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
P2
0
(LED
0
)
P2
1
(LED
1
)
P2
2
(LED
2
)
P2
3
(LED
3
)
P2
4
(LED
4
)
P2
5
(LED
5
)
P2
6
(LED
6
)
P2
7
(LED
7
)
V
SS
X
OUT
X
IN
P4
0
/INT
40
/X
COUT
P4
1
/INT
00
/X
CIN
RESET
CNV
SS
P4
2
/INT
1
M38039GXH-XXXHP/KP
M38039GXHHP/KP
25
24
23
22
21
20
19
18
17
10
11
12
13
14
15
P5
1
/S
OUT2
P6
2
/AN
2
P6
1
/AN
1
P6
0
/AN
0
P5
7
/INT
3
P5
5
/CNTR
1
P5
4
/CNTR
0
P5
0
/S
IN2
P4
7
/S
RDY1
/CNTR
2
P4
5
/T
X
D
1
P4
4
/R
X
D
1
P5
2
/S
CLK2
Package type: PLQP0064KB-A (64P6Q-A)
PLQP0064GA-A (64P6U-A)
Fig 1.
Table 2
3803 group (Spec.H QzROM version) pin configuration (PLQP0064KB-A/PLQP0064GA-A)
List of package (Spec.H QzROM version) (PLQP0064KB-A/PLQP0064GA-A)
Product name
M38039G4H-XXXHP
M38039G4HHP
M38039G6H-XXXHP
M38039G6HHP
M38039G8H-XXXHP
M38039G8HHP
M38039GCH-XXXHP
M38039GCHHP
M38039G4H-XXXKP
M38039G4HKP
M38039G6H-XXXKP
M38039G6HKP
M38039G8H-XXXKP
M38039G8HKP
M38039GCH-XXXKP
M38039GCHKP
QzROM size (bytes)
ROM size for User in ( )
16384 (16254)
24576 (24446)
2048
32768 (32638)
49152 (49022)
16384 (16254)
24576 (24446)
2048
32768 (32638)
49152 (49022)
RAM size
(bytes)
Remarks
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
QzROM version (Programmed shipment)
(1)
QzROM version (blank)
(2)
Package
PLQP0064KB-A
PLQP0064GA-A
NOTES:
1. This means a shipment of which User ROM has been programmed.
2. The user ROM area of a blank product is blank.
Rev.1.10 Nov 14, 2005
REJ03B0166-0110
Page 3 of 91
P5
3
/S
RDY2
P4
6
/S
CLK1
P5
6
/PWM
P4
3
/INT
2
16
1
2
3
4
5
6
7
8
9
Analogue and Mixed Signal
