DZM1306-1R3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> DZM1306-1R3

DZM1306-1R3: Description1 ELEMENT, 1.3uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT; CategoryPassive components inductor; File Size111KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

DZM1306-1R3 Overview

1 ELEMENT, 1.3uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

DZM1306-1R3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	unknown
ECCN code	EAR99
DC Resistance	0.0033 Ω
Nominal inductance(L)	1.3 µH
Inductor Applications	HIGH CURRENT INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	DXM1306
Number of functions	1
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-40 °C
Maximum rated current	29 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

C ircuit Protection Devices

Product Feature Selector

> Product Details

DZM1306-1R3 Product Details

Live Product Chat

Product View

Magnetics

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

DZM1306-1R3

T E I nternal N umber: D ZM 1 3 0 6 - 1 R3

Product Highlights:

Magnetics C ircuit Protection Device

Magnetics Device Type = High C urrent Inductor

Power Series

Surface Mount C ontact Termination Type

Inductance = 1.3 ?H

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

DZM1306 Series

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Magnetics C ircuit Protection Device

Magnetics Device Type = High C urrent Inductor

Package = DZM1306

Resistance (?) = .0033

Electrical Characteristics:

Inductance (?H) = 1.3

C urrent Rating (Amps.) = 29

Termination Related Features:

Height (mm [in]) = 6.99 [0.274]

Body Related Features:

Series = Power

Length (mm [in]) = 13.26 [0.522]

Width (mm [in]) = 13.13 [0.517]

Contact Related Features:

C ontact Termination Type

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Other:

Brand = C oEv Magnetics
