RD74LVC1G17

Schmitt-trigger Buffer

REJ03D0722–0100

Rev.1.00

Feb 23, 2006

Description

The RD74LVC1G17 has a Schmitt-trigger buffer in a 5-pin package. Low voltage and high-speed operation is suitable

for the battery powered products (e.g., notebook computers), and the low power consumption extends the battery life.

Features

The basic gate function is lined up as Renesas uni logic series.

Supply voltage range : 1.65 to 5.5 V

Operating temperature range: –40 to +85°C

All inputs: V

(Max.) = 5.5 V (@V

= 0 V to 5.5 V)

All outputs: V

(Max.) = 5.5 V (@V

= 0 V)

Output current:

±4 mA (@V

= 1.65 V)

±8 mA (@V

= 2.3 V)

±24 mA (@V

= 3.0 V)

±32 mA (@V

= 4.5 V)

•

Ordering Information

Part Name

RD74LVC1G17WPE

Package Type

WCSP-5 pin

Package Code

(Previous Code)

SXBG0005LB–A

(TBS-5CV)

Package

Abbreviation

Taping Abbreviation

(Quantity)

E (3,000 pcs/reel)

•

Article Indication

Marking

Year code

Month code

EKYM

Rev.1.00 Feb 23, 2006 page 1 of 7
